- Page 1 FIR FLY ® FUSE TOOL & VOLTAGE DETECTOR a n d T E S T E R Operating Instruction Manual Making the Invisible Visible 1475 Lakeside Drive • Waukegan, Illinois 60085 U.S.A. • 847.473.4980 f a x 8 4 7 . 4 7 3 . 4 9 8 1 • w e b s i t e : w w w. H D E l e c t r i c C o m p a n y. c o m...
-
Page 2: Table Of Contents
FIR FLY ® FUSE TOOL & VOLTAGE DETECTOR a n d T E S T E R Operating Instruction Manual IMPORTANT SAFETY INFORMATION ............3 DESCRIPTION . -
Page 3: Important Safety Information
Maintain proper work clearances at all times. • Make certain the FireFly Detector is properly rated for use on the system voltages you will test. • Prior to using, make certain to inspect the instrument for any physical damage, cleanliness and check for proper working order using the test button. -
Page 4: Description
The FireFly Detector should be tested both prior to and after line testing to make certain the unit is working properly. The FireFly Voltage Detector has a built-in self-test feature to make certain the unit is working properly. -
Page 5: Voltage Detector Self-Test Operation
Verify both the top and side white lights turn on. Replace the two Lights batteries if the lights do not come on (page 8). NOTE: Never use the self-test if the FireFly Detector is in contact with any voltage source. -
Page 6: Instructions For Use
In this situation the FireFly Detector may indicate live voltage when the conductor being contacted is at ground potential. NOTE: Only use the FireFly Detector within the voltage range specified on the product label. Do not use the FireFly Detector above or below the product label rating. -
Page 7: Operation
2) If the FireFly Detector will be used at night or in the dark, test the Lights before use. The lights will shut off automatically 10 minutes after the most recent voltage detection or self-test, or they can be turned off manually. -
Page 8: Battery Replacement
BATTERY REPLACEMENT Replace the four batteries as needed with IEC type CR17345 including Duracell® 123, Panasonic® CR123A and Energizer® 123. Note: Panasonic® type CR17335 or BR-2/3A are not acceptable replacements. Two of the four batteries power the voltage detector and the other two power the white lights. Always replace the two batteries for each function in pairs, but it is not necessary to replace all four batteries at the same time. -
Page 9: Maintenance And Care
HD Electric Company factory, or other qualified location. Minimal maintenance is required for the FireFly Detector. The carrying bag that is supplied with the unit is recommended for storage of the FireFly Detector when it is not in use. TECHNICAL SPECIFICATIONS ENVIRONMENTAL CONDITIONS CONDITIONS - Indoor and outdoor use ALTITUDE - Up to 6,566 ft. -
Page 10: Optional Accessories
FireFly Voltage Detector. To use, apply the metal plate on the bottom of the FireFly Tester to the right side of the Firefly Detector housing as shown. Press and hold the TEST button on the Proof Tester. A properly operating FireFly Detector will signal the presence of voltage with both the beeper and red lights. -
Page 12: Warranty And Liability
(1) year (ten (10) years for HDE Capacitor Controls) from the date of shipment (the“Warranty Period”). Should any failure to conform with this warranty be found during theWarranty Period, you must notify HD Electric Company of your claim within thirty (30) days of discovery, and within the Warranty Period.
