Toro Dingo 323 Installation Instructions Manual

Toro Dingo 323 Installation Instructions Manual

Ce kit, compact tool carrier
Hide thumbs Also See for Dingo 323:

Advertisement

Quick Links

Download this manual See also: Operator's Manual
CE Kit
Dingo
Model No. 22366
Safety
Safety and Instructional
Decals
Safety decals and instructions are
easily visible to the operator and are
located near any area of potential
danger. Replace any decal that is
damaged or missing.
1. Brake engaged
2. Parking brake
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
© 2018—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
323 Compact Tool Carrier
100-1692
3. Brake disengaged
Description
No parts required
No parts required
Brake bar
Brake-bar bracket
Flange-head bolt
Brake-cable bracket
Parking-brake cable
Locking collar with set screw
Large spring
Convoluted cable tube
Bolt (5/16 x 1 inch)
Locknut (5/16 inch)
Register at www.Toro.com.
decal100-1692
Qty.
–
–
2
2
2
2
1
2
1
1
4
4
Form No. 3422-426 Rev A
Installation Instructions
Use
Prepare the machine.
Remove the rear-wheel hubs.
Assemble the parking-brake locking
mechanism.
Install the parking-brake locking
mechanism.
Original Instructions (EN)
All Rights Reserved *3422-426* A
Printed in the USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dingo 323 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toro Dingo 323

Summary of Contents for Toro Dingo 323

  • Page 1 Large spring Convoluted cable tube Install the parking-brake locking Bolt (5/16 x 1 inch) mechanism. Locknut (5/16 inch) © 2018—The Toro® Company Register at www.Toro.com. Original Instructions (EN) All Rights Reserved *3422-426* A 8111 Lyndale Avenue South Printed in the USA...

  • Page 2: Preparing The Machine

    Procedure Description Qty. Parking-brake lever assembly Clevis pin (3/4 inch) Install the parking-brake lever. Cotter pin (3/4 inch) Wheel-hub assembly Install the rear-wheel hubs. Hub locknut – No parts required Adjust the parking brake. Loader-valve lock assembly Self-tapping bolts (1/4 x 5/8 inch) Install the loader-valve lock.
  • Page 3 Assembling the Parking-Brake Locking Mechanism Parts needed for this procedure: g020926 Brake bar Figure 3 Brake-bar bracket 1. Brake-cable bracket 2. Brake cable Flange-head bolt Brake-cable bracket Insert the cable through the right brake-cable bracket (Figure Parking-brake cable Slide the brake-cable bars through the openings Locking collar with set screw in the brake-cable brackets (Figure...
  • Page 4 Installing the Parking-Brake Locking Mechanism Parts needed for this procedure: Convoluted cable tube Bolt (5/16 x 1 inch) g020928 Locknut (5/16 inch) Figure 5 1. Locking collar 2. Set screw Procedure Position the large spring over the cable (Figure Slide the convoluted cable tube over the brake cable (Figure g020929...

  • Page 5: Installing The Parking-Brake Lever

    Installing the Parking-Brake Lever Parts needed for this procedure: Parking-brake lever assembly Clevis pin (3/4 inch) Cotter pin (3/4 inch) Procedure Route the cable across the parking-brake lever assembly (Figure 10). g020932 Figure 9 1. Rear wheel motors 2. Bolts (5/16 x 1 inch) and locknuts (5/16 inch)—fourth bolt and locknut not visible...
  • Page 6 g020935 Figure 12 1. Cable with adjustment 2. Bracket on the parking-brake lever nuts assembly Loosen the nuts securing the air cleaner to the g020934 Figure 11 frame (Figure 13). 1. Parking-brake lever 3. Parking-brake cable 2. Clevis pin (3/4 inch) and cotter pin (3/4 inch) Lightly tighten the nuts on the adjustment collar around the bracket on the lever plate...
  • Page 7 g020938 Figure 15 1. Lever assembly 3. Air-cleaner mounting-bracket 2. Air-cleaner bolts g020937 Figure 14 1. Lever assembly 2. Lever-assembly slots With the slots in the plate positioned over the air-cleaner bolts, tighten the air-cleaner nuts.

  • Page 8: Installing The Rear-Wheel Hubs

    Installing the Rear-Wheel Hubs Parts needed for this procedure: Wheel-hub assembly Hub locknut Procedure Clean the rear-drive shafts and the inside of the tapered bore of the wheel hubs with alcohol or a degreaser (Figure 16). g020940 Figure 17 1. Wheel hub (left side) Secure the hubs with new hub locknuts.

  • Page 9: Adjusting The Parking Brake

    Adjusting the Parking Brake No Parts Required Procedure Push the parking-brake lever up and forward to disengage it. Check the brake bars protruding from either side of the machine. Note: The bars should be about 3 mm (1/8 inch) from the wheel hub and neither bar should g003566 be able to move side to side.
  • Page 10 Rotate the loader-valve lock rearward as shown Figure Installing the CE-Compliant Decals Parts needed for this procedure: CE-information decal Procedure Install the decals on the left side of the machine, near the rear tire. g020941 Figure 20 Clean the area where you will install the decal. 1.
  • Page 11 Notes:...
