SX840 · SX1040 · SX1240
WIRING DIAGRAM 1 – Anschlussdiagramm 1
SUBWOOFER
4-CHANNEL AMPLIFIER 2 OHMS STABLE
FRONT SPEAKERS
4-Kanal Verstärker 2 Ohm stabil
Frontlautsprecher
4 OHMS ON CH2
4 Ohm auf Kanal 2
–
+
–
+
4 OHMS ON CH1
4 Ohm auf Kanal 1
4 OHMS BRIDGED ON CH3/4
4 Ohm gebrückt auf Kanal 3/4
WIRING DIAGRAM 2 – Anschlussdiagramm 2
SUBWOOFER 1
SUBWOOFER 2
MONO AMPLIFIER 1 OHMS STABLE
Mono Verstärker 1 Ohm stabil
–
+
–
+
–
+
2 OHMS BRIDGED
2 Ohm gebrückt
