- Page 1 User manual - Chronomètre à Résonance A unique design based on an exclusive mechanism...
- Page 2 Preface Chronomètre à Résonance An emblematic timekeeper_ With the invention of the pendulum, watchmakers noticed that their beat often interfered with the environment and it was not unusual for a pendulum clock to stop, on its own, when it entered into resonance with the driving-weight hanging from the cords. The first to get the feeling that one might turn this disadvantage into an asset was Antide Janvier, a particularly brilliant watch- maker or “mechanical engineer”...
- Page 3 What is the resonance phenomenon? Two frequencies which get into harmony_ Any animated element transmits a vibration to its environment. When another element picks up this vibration, it absorbs its energy and begins to vibrate at the same frequency. The first is called the “exciter” and the second the “resonator”. This physical phe- nomenon known as “resonance”...
- Page 4 Biography Antide Janvier French master watchmaker, 1751—1835 Antide Janvier is one of the most renowned French watchmakers. He created many horological masterpieces, in particular celestial spheres and planetariums with astronomical indications. Antide Janvier was born on July 1 , 1751 in Briva, near Saint-Claude. He was the son of Claude-Etienne Janvier, a farm plough- man who gave up his plough to dedicate himself to clock making.
- Page 5 Antide Janvier Born 1751 in Briva, Jura. † 1835, Paris.
- Page 7 Préface Tourbillon Souverain À la conquête de la précision_ He remained close to the King and spent many late evenings observing the satellites of Jupiter and other celestial objects with him. In 1792, he presented his Geographic clock to the Queen, tactlessly telling her Majesty: “You see, you can tell the time anywhere;...
- Page 8 In 2004, F.P. Journe introduced a second version of the Chronomètre à Résonance with the introduction of the first movement ever made in 18K rose Gold, a specification that, from then on, applied to all the precision chronometers of the brand.
- Page 10 Operating instructions Tourbillon Souverain À la conquête de la précision_ Crown_ Winding : Keep the crown on position 1 and turn forwards until it stops. The Chronomètre à Résonance features an efficient power reserve of 42 hours. It can nonetheless beat above these 42 hours but in this case, the watch needs to be completely wound until it stops, in order to gain back the total strength of the spring.
- Page 11 Operating instructions Position Position Position Reset both seconds Winding Time setting to zero...
- Page 12 Characteristics Chronomètre à Résonance Mechanism Patented system_ The Chronomètre à Résonance features two specific balances with four long inertia weights for the setting of advance and delay. They have been set in our engineering workshops to beat to a frequency of 21’600 v/h. The two balances enter in sympathy thanks to the resonance effect and naturally begin to beat in opposition.
- Page 13 Functions and indicators Crown Power reserve indicator 18K Gold Polished Steel Hours and minutes Silver Seconds Crown The hour dial in plain silver guilloché is maintained by a polished steel circle screwed* on the 18 K gold face. *Patended system...
- Page 14 Specifications Movement_ Calibre 1499.3 Manual winding / 27 turns of crown Movement in 18K rose gold Dimensions_ Overall diameter: 32.60 mm Casing-up diameter: 32.00 mm Overall height: 4.20 mm Height of winding stem: 2.59 mm Diameter of stem thread: S1.00 mm Diameter of reset to zero stem: S1.20 mm Characteristics_...
- Page 15 Préface Tourbillon Souverain À la conquête de la précision_ Escapement_ 2 x linear escapements, 15 teeth Lateral pallets at 90° Indications_ Double display: Left dial - analogical indicating 24 hours Right dial - analogical indicating 12 hours 2 small seconds at 6h00 Power reserve at 11h00 Power Reserve_ 40 hours ±...
- Page 16 Chronomètre à Résonance European patent — EP 1 760 544 A1 Power reserve indicator This power reserve indicator device includes two coaxial wheels (23, 25), two positive transmissions (21; 22, 24) between the coaxial wheels (23, 25) and the barrel drum (1a), respectively the barrel-arbor (1d), a third wheel (26) coaxial placed between the above mentioned coaxial wheels (23, 25) and in positive transmission with a power reserve indicator (33), these three coaxial wheels (23, 25, 26) pivoting freely around their common rotation axis, the third wheel (26) containing equidistant openings, placed on a concentric circle to its piv- oting axis and sized to receive balls freely (27) with a diameter exceeding the thickness of the third wheel (26) and a medium (28) to exert...
-
Page 18: Maintenance
Important_ Keep the original warranty card supplied with your wristwatch carefully. Your authorized F.P. JOURNE retailer will need this identity card for any after sales servicing. For all maintenance or repair, your wristwatch must be entrusted only to an appointed F.P. JOURNE agent.
