Summary of Contents for F.P. Journe octa utc
- Page 1 User manual - Octa UTC A unique design based on an exclusive mechanism...
- Page 3 Preface Calibre Octa An Horological Ideal_ While some may think the construction of the Octa calibre has less powerful ties to the history of horology than the constant- force device or resonance phenomenon, it in fact symbolizes an important historical horological ideal: giving timepieces the highest possible degree of precision and autonomy.
- Page 4 Chronology Octa UTC Coordinated Universal Time_ Created in the 19th Century, GMT, Greenwich Mean Time, orig- inally referred to mean solar time at the Royal Observatory in Green- wich, London. Already used by the British navy to calculate their longitude position from the Greenwich meridian, it was introduced in the United Kingdom by the Railway Clearing House in 1847.
- Page 5 F.P. Journe innovates once again with the presentation of the Octa UTC ®, patented system that faithfully takes us back to the modern standards of determining time zones in full hours.
- Page 6 Characteristics Mechanism of the Octa UTC EP Patented system...
- Page 7 Functions and indicators Functions_ Crown : Position 0 , clock wise : Winding of the watch. Position 1 A, clock wise : Setting of the time zone and the 24 hour (gold hand). Position 1 B, anti clock wise : Setting the date.
- Page 8 Functions and indicators Initial setting_ With the crown in position 2, turn anti clock wise to position the hours and minutes blue hands at midnight (date jump). Push the crown back in to position 1 and turn clock wise to position the 24 hours gold hand also at midnight.
- Page 9 Functions and indicators Initial settings_ Correcting pusher : Press the correcting pusher placed at 4h00 with the help of the specific tool included with the watch, in order to align your region on the globe on the 0. Illustration example: Geneva...
- Page 10 Operating instruction Tourbillon Souverain À la conquête de la précision_ Example: You live in Paris. In that case, both time indications are identical.
- Page 11 Operating instruction Example: You travel to Tokyo. Outside of summer daylight saving time, no calculation will be necessary. Pull the crown in position 1, and turn clock wise to set the time zone corresponding to Japan on 0. The corresponding time will be indicated automatically with the gold hand.
- Page 12 Operating instruction Main countries implementing summer time_ Northern Hemisphere : Albany, Andorra, Armenia, Austria, Azerbaijan, Belgium, Bosnia Herzegovina, Bulgaria, Canada, Croatia, Cyprus, Czech Republic, Denmark, Egypt, England, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iraq, Ireland, Israel, Italy, Jordan, Kosovo, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Macedonia, Malta, Mexico, Moldavia, Monaco, Mongolia, Montenegro, Morocco, Netherlands, Norway, Palestine, Poland, Portugal, Romania, Russia, Saint Marin, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Syria, Tunisia, Turkey, Ukraine, United States.
- Page 13 Universal Time Coordinates Northern Hemisphere Norther n Hemispher n Hemispher South Hemisphere South Hemisphere South Hemispher...
-
Page 14: Setting Summer Time
Operating instruction Example: Setting summer time. If you live in Paris, in relation to Tokyo, you are at -8 from Tokyo time. While Paris moves into summer daylight saving time, there is no hour change in Tokyo. Paris will then be at -7 from Tokyo. - Page 15 Operating instruction Example: Setting summer time. If you live in Tokyo, in relation to Paris, you are at +8 hours from Paris. While Paris moves onto summer daylight saving time, Tokyo will be at +7 hours from Paris. Positioning the France time- zone on -1 will indicate the corresponding time automatically.
- Page 16 Specifications Calibre 1300.3 Movement_ Unidirectional automatic winding Movement in 18K rose gold. 30.80 mm Dimensions of the movement_ Overall diameter : Casing-up diameter : 30.40 mm Overall height : 5.70 mm Height of winding stem : 3.00 mm Diameter of stem thread : S 0.90 mm Balance_ Four adjustable inertia weights...
- Page 17 Escapement_ Escapement 15 tooth Indications_ Off centre hours, minutes and time zones 24 time zones disk at 7h30 - summer/winter daylight saving time Small second at 4h30 Large date Power reserve at 9h00 120 ± 12 hours Autonomy_ Decoration_ Circular Côtes on 18K gold bridges Partly circular graining on 18K gold baseplate Polished screw heads with chamfered slots Chamfered and circular grained wheels...
- Page 18 Warranty_ Your F.P. JOURNE “Invenit et Fecit” watch is covered by a warranty against any manufacturing flaws for a period of 24 months as of the date of purchase appearing on the back of the warranty card. The warranty is valid only on presentation of the original certificate, duly filled out by the authorised retailer (series number, date of purchase, retailer’s stamp).
