Trotec TTW 25000 S Operating Manual

Trotec TTW 25000 S Operating Manual

Mobile air circulator
Hide thumbs Also See for TTW 25000 S:

Advertisement

Available languages

Available languages

Quick Links

TTW 25000 S / TTW 35000 S
Bedienungsanleitung –Windmaschine . . . . . . . . . . . . . A - 1
DE
Operating manual – Mobile Air Circulator . . . . . . . . . B - 1
EN
FR
Mode d´emploi – Machine à vent . . . . . . . . . . . . . . . . . C - 1
TROTEC GmbH & Co. KG
Tel.: +49 2452 962-400
www.trotec.de
E-Mail: info@trotec.de
Grebbener Straße 7
D-52525 Heinsberg
Fax: +49 2452 962-200

Advertisement

loading
Need help?

Need help?

Do you have a question about the TTW 25000 S and is the answer not in the manual?

Questions and answers

Summary of Contents for Trotec TTW 25000 S

  • Page 1 TTW 25000 S / TTW 35000 S Bedienungsanleitung –Windmaschine . . . . . . . . . . . . . A - 1 Operating manual – Mobile Air Circulator . . . . . . . . . B - 1 Mode d´emploi –...
  • Page 2: Table Of Contents

    Untersuchung oder Reparatur bringen. • Knicken Sie das Kabel nicht und vermeiden Sie jeglichen Kontakt mit Öl, Fett, Chemikalien, heißen Oberflächen oder scharfen oder scheuernden Ge- genständen. A - 1 Bedienungsanleitung – TTW 25000 S / TTW 35000 S...
  • Page 3: Montageanleitung

    Bestimmungen. zen am Boden, indem Sie die Löcher an den Standbeinen mit den Löchern am Rohrrahmen auf gleiche Höhe bringen. 10. Setzen Sie die Schrauben wieder ein. A - 2 Bedienungsanleitung – TTW 25000 S / TTW 35000 S...
  • Page 4: Stückliste

    Schallpegel [dB (A)] Stufe 2 Stromanschluss [A] Anschlussspannung [V/Hz] 230/50 230/50 Stecker CEE 7/7 CEE 7/7 Länge [mm] 1.060 1.230 Breite [mm] Höhe [mm] 1.140 1.140 Gewicht [kg] A - 3 Bedienungsanleitung – TTW 25000 S / TTW 35000 S...
  • Page 5 7. Tilt unit toward opposite end. locations such as flammable, explosive, chemical 8. Remove the screws from the front legs. laden atmospheres. Do not attach ductwork to the air circulator. B - 1 Operating Manual – TTW 25000 S / TTW 35000 S...
  • Page 6 2003 concerning old electrical and electronic equip- ment. At the end of its life please dispose of this in- strument in a manner appropriate to the relevant legal requirements. B - 2 Operating Manual – TTW 25000 S / TTW 35000 S...
  • Page 7 Step 2 Electrical connection [A] Input voltage [V/Hz] 230/50 230/50 Plug CEE 7/7 CEE 7/7 Length [mm] 1.060 1.230 Width [mm] Height [mm] 1.140 1.140 Weight [kg] B - 3 Operating Manual – TTW 25000 S / TTW 35000 S...
  • Page 8 UL, et qu’elles ont le bon calibre et la bonne longueur. Ne jamais utiliser une seule rallonge électrique pour faire fonctionner plus d’un ventilateur. C - 1 Manuel d’utilisation – TTW 25000 S / TTW 35000 S...
  • Page 9 être remplacée si en- dommagée. Le moteur est lubrifié en permanence. m S’assurer que l’hélice est remise en place dans le sens où elle a été installée à l’usine. C - 2 Manuel d’utilisation – TTW 25000 S / TTW 35000 S...
  • Page 10 Niveau 2 Branchement [A] Tension de branchement [V/Hz] 230/50 230/50 Prise CEE 7/7 CEE 7/7 Longueur [mm] 1.060 1.230 Largeur [mm] Hauteur [mm] 1.140 1.140 Poids [kg] C - 3 Manuel d’utilisation – TTW 25000 S / TTW 35000 S...
  • Page 12 TROTEC GmbH & Co. KG Grebbener Straße 7 D-52525 Heinsberg ® • • Tel.: +49 2452 962 - 400 Fax: +49 2452 962 - 200 • www.trotec.de E-Mail: info@trotec.de •...

This manual is also suitable for:

Ttw 35000 s
