- Page 1 TechBook in.stream 2 audio station for spas Awesome sound quality All in one audio system and power supply Full control of your audio from spa side...
-
Page 2: Table Of Contents
Table of contents Safety instructions 2 Warnings 3 Introduction 5 Overview 6 Dimensions 7 Installation 8 - instream 2 positioning 8 - instream 2 installation procedure with standard wall mounting bracket 9 - instream 2 installation procedure with wall mounting Z-bracket 9 Connections - Preparation 10... -
Page 3: Safety Instructions
, and their respective logos are Registered Trademarks of Gecko Alliance Group ® ® instream 2™, ink1000™, ink800™, ink500™ and their respective logos are Trademarks of Gecko Alliance Group All other product or company names that may be mentioned in this publication are tradenames, trademarks or registered trademarks... -
Page 4: Warnings
Warnings WARNINGS: Before installing or connecting the unit, please read the following * DO NOT DISASSEMBLE OR ALTER THE APPARATUS * DO NOT USE FOAM TO ISOLATE THE UNIT * TURN POWER OFF BEFORE SERVICING OR MODIFYING ANY CABLE CONNECTIONS IN THIS UNIT * TO PREVENT ELECTRIC SHOCK HAZARD AND/OR WATER DAMAGE TO THIS APPARATUS, ALL CONDUITS MUST BE PLUGGED WITH THE ATTACHED GASKET * AUDIO/VIDEO COMPONENTS SHALL BE LOCATED ABOVE THE FLOOD ZONE WHERE THEY ARE UNLIKELY TO BE... -
Page 6: Introduction
Introduction instream 2 audio station for spas Instream 2 audio system offers you the perfect means to bring music into your spa The instream 2 is simple to install and compatible with numerous audio sources For example, you may connect the instream 2 to an iPod using the auxiliary audio input or play music wirelessly using a Bluetooth mobile device Listen to music in MP3 format saved on a USB flash disk or tune in to an FM... -
Page 7: Overview
Overview Status LED Auxiliary USB connector inlink keypad FM antenna To CO Acc To CO Pack AC power input Subwoofer ouput Speakers outputs Depending on the chosen configuration, the instream 2 can support up to 4 speakers, 1 subwoofer, an auxiliary input, a USB connection with 1A charging capability, FM radio receiver and Bluetooth streaming The inp4 waterproof enclosure, which provides protection to your iPod or smart phone, is available as an option With a compatible keypad, you will have full control over the instream 2 features from inside of your spa... -
Page 8: Dimensions
Dimensions 9,81" (249 mm) 9" (228 mm) 8,28" (210 mm) 0,22" (5 mm) 2,58" 8,06" (65 mm) (205 mm) Front view Side view... -
Page 9: Installation
4" (100 mm) Note: The in.stream 2 must be installed at least 4" (100mm) above potential flood level. A clearance of at least 0.75" (19 mm) is required to have a free heat circulation at the back of the unit. -
Page 10: InStream 2 Installation Procedure With Standard Wall Mounting Bracket
1/2" OD x 1/16” (12 mm OD x 15 mm) with the supplied screws Note: The in.stream 2 must be installed at least 4" (100 mm) Part number: above potential flood level. If floor is on ground level, pack should Wall mount bracket kit 100 pcs - 9920-101474 be raised at least 4"... -
Page 11: Connections
The speakers and the subwoofer output terminals are located on the 10-pin MATE-N-LOK connector marked "SUB R-R R-L F-R F-L" Caution: The in.stream 2 does not come with speakers and associated wiring. The intercon- To connect your own speaker cable or to connect the... -
Page 12: Speaker Cables
Connections Speaker cables Customer made cable For customer that want to build their own cable, the following parts can be used The required housing connector is a 10 position Universal MATE-N-LOK TE CONNECTIVITY: Part number 926302-3 The suggested crimping contact are for AWG 14-20 TE CONNECTIVITY: Part number 350550-3 Optional adapter cables An optional adapter cable allows you to connect the 10-pin connector from the instream 2 to the 3x4-pin connector... -
Page 13: Connecting The Docking Station InP4 To The InStream 2
Subwoofer (+) Blue Subwoofer (-) Blue-Black Connecting the docking station in.p4 to the in.stream 2 The inp4 docking station features a USB and an 1/8" (3,5 mm) audio input mini jack connector USB connector Auxiliary To connect the docking station into the instream 2, simply insert the USB cable into the USB receptacle and the 1/8"... -
Page 14: Completing The Cabling
Connections Completing the cabling When all the audio cables are connected, put back the foam gaskets and the cover Tighten the cover screws with the Phillips screw driver ensuring you do not overtighten them Complete the cabling as follow: AC Power input To CO Pack Connect the AC power cable of the instream 2 to a direct Connect the CO cable of the instream 2 to the CO... -
Page 15: Bluetooth Overview
2, that it is turned on and that it is set in Bluetooth mode Note: In basic configuration (not connected to a keypad or controller), the in.stream 2 is set in Bluetooth mode. Otherwise, please refer to your specific keypad operating manual for details on the in.stream 2 functions. -
Page 16: Firmware Update
Warning: Do not disconnect power to the in.stream 2 or remove the flash disk during firmware update since this can make the in.stream 2 unbootable and it will be necessary to send it back in for repair. Warning: At anytime, if a flash disk containning sofware update files is inserted into the USB connector, always remove it while the power is ON, wait 5 seconds and then power off the system. -
Page 17: Compatible Keypads
Compatible keypads List of compatible keypads for the in.stream 2 For more information on the compatible keypads for your instream 2 refer to the corresponding Techbook ink500 main keypad ink800 main keypad ink1000 main keypad Color LCD display, 7 keys... -
Page 18: Regulatory Statement
Regulatory statement FCC Compliance Statement Contains Transmitter Module FCC ID: A8TBM23SPKXYC2A This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of... -
Page 19: Specifications
Specifications Environmental ratings Operating temperature: -4 °F (-20 °C) to 140 °F (60 °C) Storage temperature: -22 °F (-30 °C) to 185 °F (85 °C) Humidity: 70% max Water resistance: IPx5 Mechanical Weight: 36 lb (164 Kg) Dimensions (W x H x D): 981'' x 258'' x 888'' (249 x 65 x 226 mm) Line input Input voltage:... - Page 20 Specifications Bluetooth receiver Frequency band: 2400 MHz to 24835 MHz Transmit power: Class 2, 4 dBm Bluetooth version: Bluetooth v41 Antenna type: Modular integrated Profiles supported: A2DP, AVRCP USB player Compatibility: USB 11, 20 and 30 File format support: MP3 (files on the root) Disk size: 8GB to 32GB Disk format:...
