Coopers of Stortford 9745 Instructions For Use

Hand mower

Hand Mower

Please read and retain these instructions for future reference

9745

PARTS

1. Mower cassette

2. Lower handle

section x1

3. Upper handle

section x2

4. Side bar x2

5. Grass bag x1

6. Bolt A x7 (short

x2, long x5)

7. Bolt B (short x1

and long x1)

8. Strap x1 (pre-

fitted to grass

bag)

9. Handle spacer

Instructions for Use

v002:05/06/17

Table of Contents

Do you have a question about the 9745 and is the answer not in the manual?

Page 1 Hand Mower Instructions for Use 9745 Please read and retain these instructions for future reference v002:05/06/17 PARTS 1. Mower cassette 2. Lower handle section x1 3. Upper handle section x2 4. Side bar x2 5. Grass bag x1 6. Bolt A x7 (short x2, long x5) 7.
Page 2 Hand Mower Instructions for Use 9745 Please read and retain these instructions for future reference v002:05/06/17 ASSEMBLY 1. Attach the lower handle section (2) to the mower cassette (1) by aligning the sprung bars with the lugs on the mower cassette.
Page 3 Hand Mower Instructions for Use 9745 Please read and retain these instructions for future reference v002:05/06/17 • Never cut wet grass. • Always cut with the handle facing towards you. • Always grasp the handle with both hands. • Step forwards while pressing forwards and downwards so that the lawn mower maintains maximum traction with the ground.
