Cordless Lawn Mower
Please read and retain these instructions for future reference
IMPORTANT: Read and understand this manual before assembling or operating this appliance.
Improper use of this appliance can cause severe injury.
Description
11018
Battery pack
Battery type:
Charger time:
No-load speed:
Height adjustments:
Upper handle adjustments: 4 positions
Cutting Length:
(working width)
Unit weight
(without battery):
Allowable charging
temperature range:
Volume of grass
catcher
Parts List:
1. Bail lever
2. Safety Lock-out button
3. Upper handle
4. Locking knobs
5. Grass catcher box
6. Grass box
7. Rear cover
8. Key
9. Height adjustment handle
10. Battery door
11. Battery door button
12. Wheels
13. Battery
14. Charger
15. LED light
Instructions for Use
v001: 31/10/17
2000mAh
40V Lithium-Ion
Approx. 3hours
3700/min
30mm-65mm
320mm
11Kg
0-50°C
25L
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford 11018
Summary of Contents for Coopers of Stortford 11018
-
Page 1: Description
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Battery pack 2000mAh Battery type: 40V Lithium-Ion Charger time: Approx. 3hours No-load speed: 3700/min Height adjustments: 30mm-65mm Upper handle adjustments: 4 positions... -
Page 2: Table Of Contents
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Warning: The vibration emission during actual use of the power tool can differ from the declared total value depending on the ways in which the tool is used. - Page 3 Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 • Do not discard the packing material until you have carefully inspected and satisfactorily operated the product. Fig. 1 Mower assembly 1. Insert the lower handle (Fig.1 No.2) into the position hole (Fig.1 No.10) towards the main part. Make sure that the lower handle is in place .
-
Page 4: Operation
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Installing the battery: 1. Press the battery door button (Fig.2 No.1), 2. Lift and hold up the battery door (Fig.2 No.2), 3. Place the battery (Fig.2 No.3) in the mower. - Page 5 Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Cutting height adjustment: When supplied, the wheels on the mower are set to a low position. Before using the mower for the first time, raise the cutting position to the height best suited for your lawn.
-
Page 6: Charging The Battery
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 CHARGING THE BATTERY: The battery needs to be charged before first use and whenever it fails to produce sufficient power to cut grass. -
Page 7: Blade Maintenance
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 2. IMPORTANT CHARGING NOTES. Longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 18-24°C. -
Page 8: Troubleshooting
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Use the following procedure to remove and re-place the blade: While wearing strong padded gloves, wedge a block of wood between the... -
Page 9: After Usage/Storage
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Battery not fully charged Charge battery Key not inserted Machine start, Fit correctly correctly/fully immediately stop Battery not inserted Insert battery (properly) -
Page 10: Safety Instructions
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Remove any build-up of grass and leaves on or around the motor cover (do not use water).Occasionally wipe the mower clean with a dry cloth. If debris builds up on the underside of the mower during use, stop the motor, disconnect it from the battery, and then tilt the mower forward or on its side, and scrape it clean using an appropriate tool. - Page 11 Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 WORKING ON BANKS CAN BE DANGEROUS. DO NOT MOW ON EXCESSIVELY STEEP SLOPES. ALWAYS BE SURE OF YOUR FOOTING ON SLOPES OR WET GRASS.
-
Page 12: Explanation Of Symbols On The Machine
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 When battery is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws, or other small metal objects that can make a connection from one terminal to another. -
Page 13: Care And Cleaning Instructions
Cordless Lawn Mower Instructions for Use 11018 Please read and retain these instructions for future reference v001: 31/10/17 Only use the battery charger indoors. CARE AND CLEANING INSTRUCTIONS: Always switch off and unplug before cleaning. Do NOT immerse in water. Risk of electric shock.
