- Page 2 Congratulations on buying a PAC RemoteTrainer. PAC has over 10 years of experience in the design, manufacture and supply of dog training and containment equipment for professionals, enthusiasts and pet owners. Many thousands of PAC clients will testify to our enormous success through innovation,reliability and service. The advanced AXT series are the world’s most versatile and effective digital remote trainers making them the de facto “best of breed”.
-
Page 3: Kit Contents
1. Operating Instructions 6. Dummy Collar (Optional) 2. Training Guide (Optional) 7. Antenna 3. Mains Power Adaptor 8. Transmitter Handset 4. Charging Dock 9. Neon Tester 5. Active Collar 10. Pointed Probes(see p.3) Kit Contents... - Page 4 a. Active Collar b. Dummy Colllar c. Installed Probes for short-haired breeds d. Long probes for hairy breeds Active Collar/Dummy Collar...
- Page 5 A. Active Collar: B. Dummy Collar 1. Status Lamp 2. Positive Probe 3. Reset contact point 4. On/Off contact point 5. Negative Probe Collar Features...
-
Page 6: Handset Features
1 .Battery Indicator, Red and Green 2. Intensity Control 3. Antenna 4. Triggers 5. Collar activator area 6. Model AXT 4 and 6 only 7. Recharging socket Handset Features... -
Page 7: Charging The Collar
1. Plug Power Unit into Mains 2. Plug DC jack into Charging Dock 3. Plug Charging Dock Lead into Handset 4. Plug Collar into Charging Dock. Observe polarity (reverse protected) 5. Press ‘Set Timer’ for 16 hour charge 6. Position of Collar(s) and Handset on Charging Dock Charging the Collar... - Page 8 Match collar to handset trigger(s) using Reset operation 1. Bring the handset arrow into contact with the RESET arrow on the collar. 2. Collar LED will fast flash orange 3. Press handset trigger to match collar to handset. 4. Fast flashing orange changes to slow flashing green Resetting Collar...
-
Page 9: Turning The Collar On And Off
Turn collar on by bringing arrrow at base of handset into close proximity with ON/OFF arrow on collar. A *beep* and green light will show status Do the same to turn OFF the unit. A red light and *beep* will indicate action. Turning the Collar ON and OFF... - Page 10 1. Clip Neon Tester onto probes to test collar impulse. 2. Battery Status Indicator for Handset (green+red=OK, red only=Low) 3. Battery Status Indicator for Collar (Green=OK, Red=Low) Neon Tester and Battery Status...
-
Page 11: Intensity Control
The Intensity Control acts in smooth steps from 75mW up to 500 mW of collar stimulus. The control can have a tone only zone also, explained later. Intensity Control... -
Page 12: Selecting Mode Of Operation
Depending on your handset model, choose the desired operating mode. Mode B: BASIC: Each trigger is multifunction and controls 1 dog -see page 12. Mode E/P: Enhanced/Professional Mode: Each trigger is dedicated to one function- see page 13 Selecting Mode of Operation... - Page 13 Each Handset trigger shares up to three functions and is assigned to an individual collar: 1. Collar Tone (at Lo Intensity level) and either 2. Momentary Collar Stimulation.(Continuous at Hi ) or 3. Continuous Collar Stimulation Pages 14 and 15 for more information Basic Mode (B) Functions...
- Page 14 Each Trigger has a dedicated function, a. Trigger1/3: tone warning from collar and handset and either b. Trigger 2/4: momentary stimulus or 2/4 continuous c. Trigger 5/6: continuous Stimulus (only on AXT 3 and AXT 6) Enhanced/Professional Mode(E/P) Functions...
- Page 15 1. Remove the cover to expose the Dip Switches. Each switch can turn on or off a function. 2. Use a small screwdriver/large needle to slide the switches, referring to guide on pages 15 and 16. 3. Shows the switch for disabling the handset buzzer. Other remaining switches concern collar unit functions.
- Page 16 Mode B assigns a trigger for each Training Collar. Collar Tone Warning: Momentary Stimulus: Continuous Stimulus: Switch Configuration:Mode B...
- Page 17 Mode E/P: Dedicated Function per trigger Collar Tone Warning: Momentary Stimulus: Continuous Stimulus: Mode H: Hybrid function for AXT2, AXT4 Switch Configuration: Mode E/P, H...
- Page 18 1. Ensure collar is positioned correctly on narrowes part of neck. One finger should be able to fit between the probe and the dog’s neck. Skin Irritation-Inspect the dog daily during collar use. A loose collar is a common cause. 2.
-
Page 19: Troubleshooting
a. Temporary radio interference: Try later or try another location b. Metal fencing/buildings are shielding signal: try elsewhere c. Collar strap too loose: Tighten strap d. Antenna Failure? Test without antenna at 2 to 3 metres to confirm. If handset is OK order a replacement antenna e. - Page 20 1.Collar Appears OK (LED flashes green ) but no reaction from dog: a. Incorrect code?-Try RESET (p7). b. Intensity not high enough? Try gradual increase (p10) c. Collar too loose? Tighten (p17) 2.LED’s not illuminating on collar or transmitter? Possible Cause and solution: Batteries fully discharged. Charge for 17 hours. Troubleshooting 2...
-
Page 21: Handling And Storage
Avoid dropping onto hard surfaces. Most circuitry is ruggedised but some have definite limits. Avoid using in rocky, fissured terrain Never leave collar or transmitter in very warm or sunny areas, or behind glass. Storage. 1. Charge fully. 2. Store in cool, dry place. 3. Recharge battery every 60 days. Handling and Storage... - Page 22 Please read the Training Guide for humane and effective use of your PAC Remote Trainer. It is a comprehensive guide that should enable you to train your dog effectively in a short time. It also offers advice and guidance on many related training matters.
- Page 23 PAC Remote Trainers PAC Repairs Graignamanagh, Killeen, Co.Kilkenny, Graignamanagh, Ireland. Co.Kilkenny, Tel Int.+353 51423679 Ireland. Fax Int.+353 51423964 www.pacdog.com made in EU info@pacdog.com printed in EU support@pacdog.com © PAC Products Ltd. 2004 Instruction Manual for your PAC AXT design and layout: phelandesign.co.uk...
