Page 1 OWNER’S MANUAL Keep With Vehicle At All Times. Contains Important Information On Safety, Operation & Maintenance. 2008 Part No. 99011-85Z14-03E July, 2007...
Page 2 Prepared by July, 2007 Part No. 99011-85Z14-03E Printed in U.S.A. TP222...
Page 4 INTRODUCTION Thank you for choosing SUZUKI and welcome to our growing family. Your choice was a wise one; SUZUKI products are a great value that will give you years of driving pleasure. This Owner’s Manual was prepared to help you have a safe, enjoyable, and trouble-free experience with your SUZUKI. In it you will learn about the vehicle’s operation, its safety features and maintenance requirements.
Page 5: Service Station
SERVICE STATION GUIDE 1. Fuel (see section 5) 2. Engine hood (see section 5) 3. Tire changing tools (see section 5) 4. Engine oil dipstick <Yellow> (see section 5) 5. Engine coolant (see section 5) 6. Windshield washer fluid (see section 5) 7.
Page 6: Table Of Contents
TABLE OF CONTENTS California Proposition 65 Warning WARNING Engine exhaust, some of its constitu- ents, and certain product compo- nents contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. SEATS AND RESTRAINT SYSTEMS FEATURES AND CONTROLS INSTRUMENT PANEL...
Page 7 Do not remove the messages for any reason. If a label comes off or the messages become difficult to read, have it corrected by your SUZUKI dealer. 1. Air Bag Warning Label 2. Passenger Air Bag Warning Label 3. Rear Center Safety Belt Warning Label 4.
Page 8 In the event you require assistance related to your SUZUKI, while temporarily travel- ling in either the United States or Canada, you may wish to contact the Suzuki Cus- tomer Relations Department directly of the country in which you are temporarily oper- ating your vehicle.
Page 9: Warning
CB (Citizen’s Band) radios may cause electronic interfer- ence with your vehicle’s ignition sys- tem, resulting in vehicle performance problems. Consult your SUZUKI dealer or qualified service technician for advice on installing such mobile communication equipment.
Page 10: Seats And Restraint Systems
Vehicle Symbols Your vehicle has components and labels that use symbols instead of text. Symbols, used on your vehicle, are shown along with the text describing the operation or information relating to a specific component, control, message, gauge or indicator. If you need help figuring out a specific name of a component, gauge or indicator, reference the following topics: •...
Page 12 SEATS AND RESTRAINT SYSTEMS SEATS AND RESTRAINT SYSTEMS Front Seats ... 1-1 Rear Seats ... 1-4 Safety Belts ... 1-5 Child Restraints ... 1-15 Supplemental Restraint System (air bags) ... 1-26 Restraint System Check ... 1-33...
Page 13: Seats And Restraint Systems
SEATS AND RESTRAINT SYSTEMS Front Seats Manual Seats (With Sliding Storage Tray) WARNING Never attempt to adjust the driver’s seat or seatback while driving. The seat or seatback could move unex- pectedly, causing loss of control. Make sure that the driver’s seat and seatback properly adjusted...
Page 14: Driver Seat Height Adjuster
Driver Seat Height Adjuster N4U1003A To adjust the height of the driver’s seat cushion, turn the knobs located on the out- board side of the seat cushion. Turn the front knob to adjust the height of the front portion of the seat cushion. Turn the rear knob to adjust the height of the rear portion of the seat cushion.
Page 15 SEATS AND RESTRAINT SYSTEMS L3U1009A Do not have your a seatback reclined when your vehicle is moving. WARNING All seatbacks should always be in a fairly upright position when driving, or seat belt effectiveness may be reduced. Seat belts are designed to offer maximum protection when seat- backs are in the fully upright posi- tion.
Page 16: Rear Seats
N4U1006A If your vehicle is equipped with the tiltable front head restraints, do the following to adjust it. 1) Place it in its upright position by push- ing it forward fully and releasing it. 2) Push the head restraint forward care- fully until it is adjusted to the desired position.
Page 17: Safety Belts
SEATS AND RESTRAINT SYSTEMS WARNING • Do not stack luggage or other cargo higher than the front seats. • Do not allow passengers to sit on the folded seatbacks while the vehicle is in motion. • Unrestrained luggage or passen- gers on a folded seatback can be thrown about or ejected from the vehicle in a sudden stop or acci-...
Page 18 Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. L3U1015A Take the simplest vehicle. Suppose it’s just a seat on wheels. L3U1016A Put someone on it. L3U1017A Get it up to speed. Then stop the vehicle. The rider doesn’t stop.
Page 19: Questions And Answers About Safety Belts
SEATS AND RESTRAINT SYSTEMS strongest bones take the forces. That’s why safety belts make such good sense. Questions and Answers About Safety Belts Question: Won’t I be trapped in the vehicle after an accident if I’m wearing a safety belt? Answer: You could be –...
Page 20 able to unbuckle the safety belt quickly if you ever had to. L3U1022A 5) To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder belt. L3U1023A The lap part of the belt should be worn low and snug on the hips, just touching the thighs.
Page 21 SEATS AND RESTRAINT SYSTEMS WARNING Be sure that the shoulder belt is posi- tioned on the center of the outside shoulder. The belt should be away from your face and neck, but not fall- ing off your shoulder. Misadjustment of the belt could reduce the effective- ness of the safety belt in a crash.
Page 22 In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your SUZUKI dealer to fix it. SEATS AND RESTRAINT SYSTEMS L3U1029A To unlatch the belt, just push the button on the buckle.
Page 23: Right Front Passenger Position
SEATS AND RESTRAINT SYSTEMS L3U1030A A pregnant woman should wear a lap- shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy. The best way to protect the fetus is to pro- tect the mother.
Page 24 L3U1033A Pull up on the latch plate to make sure it is secure. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to. L3U1034A 3) To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part.
Page 25 SEATS AND RESTRAINT SYSTEMS WARNING You can be severely hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body. L3U1067A To unlatch the belt, just push the button on the buckle.
Page 26: Safety Belt Extender
“LOCK” position for at least 60 seconds before performing any electri- cal service work on your SUZUKI. Do not touch pretensioner system components or wiring. The wires are wrapped with yellow tape or yellow tubing, and the couplers are yellow.
Page 27: Child Restraints
SEATS AND RESTRAINT SYSTEMS WARNING Failure to follow these instructions may increase the risk of injury in a crash. • Only use an extender for the per- son, vehicle and seating position it was provided for. • A front safety belt extender must only be used in a front seating position, and a rear safety belt extender must only be used in a...
Page 28 Question: What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? Answer: If the child is sitting in a seat next to a window, move the child toward the center of the vehicle.
Page 29 SEATS AND RESTRAINT SYSTEMS L3U1039A WARNING People should never hold a baby in their arms while riding in a vehicle. A baby doesn’t weigh much – until a crash occurs. During a crash a baby will become so heavy it is not possi- ble to hold it.
Page 30 WARNING Newborn infants need complete sup- port, including support for the head and neck. This is necessary because a newborn infant’s neck is weak and its head weighs so much compared with the rest of its body. In a crash, an infant in a rear-facing seat settles into the restraint, so the crash forces can be distributed across the stron-...
Page 31 SEATS AND RESTRAINT SYSTEMS L3U1043A A forward-facing child seat (C–E) provides restraint for the child’s body with the har- ness and also sometimes with surfaces such as T-shaped or shelf-like shields. 1-19 L3U1044A A booster seat (F–G) is a child restraint designed to improve the fit of the vehicle’s safety belt system.
Page 32 (lap belts or the lap portion of lap- shoulder belts) or by special rigid lower anchor bars built into the seats. Whenever possible, SUZUKI recommends that child restraint systems be installed on the rear seat. According to accident statistics, chil-...
Page 33 SEATS AND RESTRAINT SYSTEMS S4U1010A In Canada, the law requires that forward- facing child restraints have a top strap, and that the strap be anchored. In the United States, some child restraints also have a top strap. If your child restraint has a top strap, it should be anchored.
Page 34 according to the instructions provided by the child restraint system manufac- turer. Be sure to attach the top strap to corresponding anchor located directly behind the child restraint. WARNING Each top tether bracket is designed to anchor only one child restraint. Attaching more than...
Page 35 SEATS AND RESTRAINT SYSTEMS L3U1047A L3U1049A In order to use the system, you need either a forward-facing child restraint that has attaching points (B) at its base and a top tether anchor (C), or a rear-facing child restraint that has attaching points (B), as shown here.
Page 36 Securing a Child Restraint in a Rear Seat Position L3U1031A If your child restraint is equipped with the LATCH system, see “Lower Anchorages and Top Tethers for Children (LATCH Sys- tem)” in this section. See “Top Strap” in this section if the child restraint has one. If your child restraint does not have the LATCH system, you will be using the lap- shoulder belt to secure the child restraint in...
Page 37 SEATS AND RESTRAINT SYSTEMS Securing a Child Restraint in the Right Front Seat Position L3U1068A Your vehicle has a right front passenger air bag. A rear seat is a safer place to secure a child restraint. See “Where to Put the Restraint”...
Page 38: Supplemental Restraint System (Air Bags)
L3U1069A 4) Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to. L3U1059A 5) Pull the rest of the shoulder belt all the way out of the retractor to set the lock. L3U1060A L3U1061A 6) To tighten the belt, feed the shoulder...
Page 39 SEATS AND RESTRAINT SYSTEMS 1-27 1. Driver’s air bag 2. Front passenger’s air bag 3. Safety belt pretensioner 4. Air bag controller (SDM) 5. Occupant classification module 6. “PASSENGER AIRBAG OFF” indicator 7. Air bag readiness light 8. Early crash sensor 9.
Page 40 these air bags must inflate very quickly to do their job. Here are the most important things to know about the air bag systems. WARNING You can be severely injured or killed in a crash if you aren’t wearing your safety belt –...
Page 41 SEATS AND RESTRAINT SYSTEMS S4U1015A There is an air bag readiness light on the instrument panel, which shows the air bag symbol. The air bag readiness system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem.
Page 42 Passenger Sensing System Your vehicle has a passenger sensing sys- tem for the right front passenger position. The passenger air bag off indicator will be visible when you turn your ignition key to ON or START. The words “PASSENGER AIR BAG OFF” will be visible in the clock display located in the center of the instru- ment panel during the system check.
Page 43 If it is necessary to modify the advanced air bag system to accommodate a person with disabilities, owners in the continental United States can call Ameri- can Suzuki toll-free at 1-800-934-0934, or write to: American Suzuki Motor Corporation Automotive Customer Relations...
Page 44 or because of what the repair costs were. For frontal air bags, inflation is determined by the angle of the impact and how quickly the vehicle slows down in frontal and near- frontal impacts. For side impact air bags, inflation is determined by the location and severity of the impact.
Page 45: Restraint System Check
• Let only qualified technicians work on your air bag system. Improper service can mean that your air bag system won’t work properly. See your SUZUKI dealer for service. CAUTION If you damage the covering for the driver’s or the right front passenger’s...
Page 46 Replacing Restraint System Parts After a Crash WARNING A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working prop- erly after...
Page 47 SEATS AND RESTRAINT SYSTEMS MEMO 1-35...
Page 48 FEATURES AND CONTROLS FEATURES AND CONTROLS Keys ... 2-1 Doors and Locks ... 2-4 Windows ... 2-7 Theft-Deterrent Systems ... 2-8 Daily Inspection Checklist ... 2-10 Starting and Operating Your Vehicle ... 2-10 Mirrors ... 2-20 Storage Areas ... 2-21 Sunroof ...
Page 49: Keys
The key number is stamped on the key tag (A). The tag has a code on it that tells your SUZUKI dealer or a qualified locksmith how to make extra keys. If you lose your key, you’ll be able to have a new one made easily using the tag.
Page 50: Remote Keyless Entry System Operation
“Battery Replacement” under Remote Keyless Entry System Operation in this section. • If you are still having trouble, see your SUZUKI dealer or a qualified technician for service. Remote Keyless Entry System Operation N4U2002BS The following functions are available if your...
Page 51 FEATURES AND CONTROLS transmitter will not unlock your vehicle. Each vehicle can have a maximum of four transmitters matched to it. Battery Replacement Under normal use, the battery in your remote keyless entry transmitter should last about two years. You can tell the battery is weak if the LED (A) fails to illuminate or if the transmitter won’t work at the normal range in any loca- tion.
Page 52: Doors And Locks
Doors and Locks Door Locks WARNING Unlocked doors can be dangerous. • Passengers – especially children – can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle won’t open it. You increase the chance of being thrown out of the vehicle in a crash if the doors aren’t locked.
Page 53 FEATURES AND CONTROLS manual door lock located on the window sill on each door. From the inside, you can also lock and unlock the doors with the power door lock switches located on the driver’s door trim pad. CAUTION If there is noise when opening or closing the doors or while driving, apply grease to door latch and hinge.
Page 54 Using the Rear Door Security Lock N4U2007B To activate the rear door security lock: 1) Move the lock upward to the lock posi- tion. 2) Close the door. 3) Do the same thing to the other rear door lock. CAUTION Do not pull the inside door handle when the rear door security locks are engaged.
Page 55: Windows
FEATURES AND CONTROLS N4U2026A To open the liftgate from outside of the vehicle, insert the key into the lock cylinder and turn it clockwise. Then pull up the han- dle above the license plate to open the lift- gate. When closing the liftgate, close from the center to ensure it fully latches.
Page 56: Theft-Deterrent Systems
Express-Down Window The driver’s window also has an express- down feature. This switch is labeled AUTO. Press the switch then release it and the driver’s win- dow will go all the way down. To stop the window while it is lowering, press the switch again.
Page 57 FEATURES AND CONTROLS N4U2012A – The security light (A) will flash once every 0.8 seconds to indicate that the theft-deterrent system is armed. The security light is located on the driver’s door lock. To avoid activating the alarm by accident, do the following: •...
Page 58: Daily Inspection Checklist
Daily Inspection Checklist Before Driving 1) Make sure that windows, mirrors, lights and reflectors are clean and unob- structed. 2) Visually check the tires for the following points: – the depth of the tread groove – abnormal wear, cracks and damage –...
Page 59: Starting Your Engine
FEATURES AND CONTROLS Ignition Positions S4U2015A With the key in the ignition switch, you can turn the key to four different positions. WARNING On manual transmission vehicles, turning the key to LOCK and remov- ing it will lock the steering column and result in a loss of ability to steer the vehicle.
Page 60 If you add electrical parts or accessories, you could change the way the engine operates. Before adding electrical equipment, check with your SUZUKI dealer. If you don’t, your engine might not perform properly. Automatic Transmission Operation...
Page 61 FEATURES AND CONTROLS lever all the way into PARK (P) – as you maintain brake application. Then move the shift lever into the gear you wish. See “Shifting Out of Park (P)” on a later page in this section. REVERSE (R): Use this gear to back up.
Page 62 In this situation, automatic shifting can be canceled or can default to a severe condition mode. You should consult your SUZUKI dealer and have the problem repaired as soon as possible when this condition occurs.
Page 63 FEATURES AND CONTROLS N4U2015A Press the HOLD button on the shift lever to turn on the HOLD mode. While on, the HOLD indicator light on the instrument panel will light up. See “Hold Mode Light” in section 3. Press the button again to turn off the HOLD mode, and return to normal automatic transmission operation.
Page 64 OND (2). Slowly let up on the clutch pedal as you press the accelerator pedal. To stop, let up on the accelerator pedal and press the brake pedal. Just before the vehicle stops, press the clutch pedal and brake pedal, and shift to NEUTRAL. NEUTRAL: Use this position when you start or idle your engine.
Page 65: Shifting Into Park (P)
FEATURES AND CONTROLS Shifting Into Park (P) (Automatic Transmission) WARNING It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set. Your vehicle can roll. Don’t leave your vehicle when the engine is running unless you have to.
Page 66 2) Turn the key to LOCK and remove the key from the ignition switch. 3) Remove the hole cover from the shift lock slot with a screwdriver N4U2017A 4) Insert the key into the shift lock slot and press and hold it. 5) Shift to NEUTRAL (N).
Page 67 FEATURES AND CONTROLS Engine Exhaust WARNING Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you can’t see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: • Your exhaust system sounds strange or different.
Page 68: Mirrors
Mirrors Manual Rearview Mirror When you are sitting in a comfortable driv- ing position, adjust the mirror so you can see clearly behind your vehicle. Grip the mirror in the center to move it up or down and from side to side. L3U2021A The day/night adjustment allows you to adjust the mirror to avoid glare from any...
Page 69: Storage Areas
FEATURES AND CONTROLS Outside Convex Mirror Your passenger’s side mirror is convex. A convex mirror’s surface is curved so you can see more from the driver’s seat. WARNING A convex mirror can make things (like other vehicles) look farther away than they really are.
Page 70: Front Storage Area
Sunglasses Storage Compartment S4U2026A The sunglasses storage compartment is located above the driver’s door. To open the sunglasses storage compart- ment, pull down and hold the upper part of the cover. To close the compartment, let go of the cover and the compartment will automatically close.
Page 71: Sunroof
See your SUZUKI dealer for details. Sunroof If your vehicle has this feature, the switch is located between the map lamp buttons.
Page 72 switch and hold it until the sunroof is closed. The sunroof will stop if the switch is released during operation. In both the vent and fully open positions, the air flow can be adjusted for driving comfort by pushing and holding the switch until the sunroof moves to the desired posi- tion.
Page 73 FEATURES AND CONTROLS MEMO 2-25...
Page 74: Instrument Panel
INSTRUMENT PANEL INSTRUMENT PANEL Instrument Panel Overview ... 3-1 Climate Controls ... 3-12 Warning Lights, Gauges and Indicators ... 3-18 Audio System ... 3-29...
Page 75: Instrument Panel Overview
INSTRUMENT PANEL Instrument Panel Overview The main components of your instrument panel are the following: A. Air Outlet B. Instrument Panel Cluster C. Air Outlet D. Hazard Warning Flashers Button E. Digital Clock F. Audio System G. Instrument Panel Brightness Control H.
Page 76 Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will flash on and off. N4U3002BS The hazard warning flasher button is located on the center of the instrument panel.
Page 77 INSTRUMENT PANEL Tilt Wheel Your vehicle has a tilt wheel which allows you to adjust the steering wheel before you drive. You can raise it to the highest level to give your legs more room when you exit and enter the vehicle. The lever that allows you to tilt the steering wheel is located under the steering col- umn.
Page 78 As you signal a turn or a lane change, if the arrows flash rapidly, a signal bulb may be burned out and other drivers won’t see your turn signal. If a bulb is burned out, replace it to help avoid an accident. If the arrows don’t go on at all when you signal a turn, check for burned-out bulbs and then check the fuse.
Page 79 INSTRUMENT PANEL between wipes. The wiper speed can only be adjusted when the lever is in the INT position. OFF (Off): Move the lever to this position to turn off the windshield wipers. Misting Function Move the lever toward, but not completely in, the INT position for a single wiping cycle.
Page 80 CAUTION To help prevent damage to wind- shield wiper and washer system components, you should take the fol- lowing precautions: • Do not continue to hold in the lever when there windshield washer fluid being sprayed or the washer motor can be damaged. •...
Page 81 INSTRUMENT PANEL Setting Cruise Control WARNING If you leave your cruise control on when you are not using cruise, you might hit a button and go into cruise when you do not want to. You could be startled and even lose control. Keep the cruise control switch off until you want to use cruise control.
Page 82 drivers find this to be too much trouble and do not use cruise control on steep hills. Disengaging Cruise Control There are two ways to turn off the cruise control: • Step lightly on the brake pedal, or depress the clutch pedal, if you have a manual transmission.
Page 83 INSTRUMENT PANEL The DRL system will turn off under the fol- lowing conditions: • The ignition is off, or • the parking brakes are on, or • the high-beam headlamps are on, or • the low-beam headlamps are on, or •...
Page 84 Certain electrical accessories may not be compatible with the accessory power outlet and could result in blown vehicle or adapter fuses. If you experience a prob- lem, see your SUZUKI dealer for additional information on the accessory power outlet. CAUTION Adding some electrical equipment to...
Page 85 INSTRUMENT PANEL CAUTION Power outlets are designed for acces- sory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause dam- age not covered by your warranty. 3-11 Ashtrays and Cigarette Lighter The front ashtray is located at the lower...
Page 86: Climate Controls
Clock The time is displayed in the digital clock when the ignition is on. The clock is located in the center of the instrument panel. There are three adjusting buttons for the digital clock: H (Hour): To go forward one hour, press the “H” but- ton once, with the ignition on.
Page 87 INSTRUMENT PANEL The fan must be turned on to run the air conditioning compressor. Temperature Control You can control the temperature of the air that comes through the air vents by turning the temperature control knob. N4U3023A Turn this knob clockwise or counterclock- wise to manually increase or decrease the temperature inside your vehicle.
Page 88 (Floor): This mode directs most of the air to the floor outlets. Some of the air will also be directed to the windshield, instrument panel side outlets, and rear outlets. Be sure to keep the area under the front seats clear to allow the flow of air to the rear compartment.
Page 89 INSTRUMENT PANEL vehicle to cool down. It also helps the sys- tem to operate more efficiently. For quick cool down on hot days, do the following: 1) Press the recirculation button. 2) Press the A/C button. 3) Select the coolest temperature on the temperature control knob.
Page 90 (Defrost): This mode directs most of the air to the windshield, with some air directed to the side window outlets. When you select this mode, the system runs the air-conditioning compressor. To defrost the windows faster, turn the temperature control knob clock- wise to the warmest setting.
Page 91 • Use of non-SUZUKI approved hood deflectors may adversely affect the per- formance of the system. • Keep the path under the front seats clear of objects to help circulate the air inside of your vehicle more effectively.
Page 92: Warning Lights, Gauges And Indicators
Warning Lights, Gauges and Indicators This section describes the warning lights and gauges that may be on your vehicle. The pictures will help you locate them. Warning lights and gauges can signal that something is wrong before it becomes seri- ous enough to cause an expensive repair or replacement.
Page 93 INSTRUMENT PANEL Tachometer The tachometer shows your engine speed in revolutions per minute (rpm). CAUTION Do not operate the engine with the tachometer in the red area, or engine damage may occur. The damage would not be covered by your war- ranty.
Page 94 Air Bag Readiness Light There is an air bag readiness light on the instrument panel. The air bag readiness system checks the air bag’s electrical sys- tem for malfunctions. The light tells you if there is an electrical problem. The system check includes the air bag sensor, the air bag modules, the wiring and the crash sensing and diagnostic module.
Page 95 The light should go out after several seconds. Contact your SUZUKI dealer for repairs if the ABS warning light does any of the fol- lowing: • Does not come on when the ignition is turned ON.
Page 96 If the warning light stays on, or comes on while you are driving, the SSPS system may not be working. If this happens, see your SUZUKI dealer for service. Hold Mode Light If your vehicle has this feature, this light will come on when the Hold mode is active.
Page 97 10 seconds and restart the engine. If the light remains on steady, see “If the Light Is On Steady” following. If the light is still flashing, see your SUZUKI dealer for service as soon as possible. Fol- low the driving guidelines described above.
Page 98 It will require at least one full tank of the proper fuel to turn the light off. If none of the above steps have made the light turn off, your SUZUKI dealer can check the vehicle. Your SUZUKI dealer has the proper test equipment and diagnostic tools to fix any mechanical or electrical problems that may have developed.
Page 99 INSTRUMENT PANEL • If you’re idling at a stop sign, the light may blink on and then off. • If you make a hard stop, the light may come on for a moment. This is normal. WARNING Don’t keep driving if the oil pressure is low.
Page 100 still have a little fuel left, but you should get more soon. See “Low Fuel Warning Light” in this section for more information. Here are four things that some owners ask about. None of these show a problem with your fuel gauge: •...
Page 101 INSTRUMENT PANEL front passenger’s frontal air bag and side air bag. See “Passenger Sensing System” in Section 1 for more on this, including important safety information. WARNING If the air bag readiness light in the instrument panel cluster ever comes on and stays on, it means that some- thing may be wrong with the air bag system.
Page 102 WARNING (Continued) If the tire pressure monitoring system warning light does not illuminate when the ignition key is turned to the “ON” position, have the system inspected by an authorized service facility. If the warning light flashes while driving, check to see whether the warning light goes off after a few minutes of driving.
Page 103: Audio System
Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts. Please bring the unit to an authorized SUZUKI dealer. Cautions on Handling 52D274 This unit has been designed specifically for playback of compact discs bearing the mark (A).
Page 104 Never touch the surface. 52D347 To remove fingermarks and dust, use a soft cloth, and wipe in a straight line from the center of the compact disc to the cir- cumference. 52D277 New discs may have some roughness around the edges. The unit may not work or the sound may skip if such discs are used.
Page 105 INSTRUMENT PANEL Radio with CD (Double Display, MP3/WMA) (AGC-6380) 1. Power/Volume knob 2. AM button 3. FM button 4. TUNE button 5. SEEK button 6. SCAN/AST button 3-31 7. Preset station buttons •2 RPT: Repeat button •3 RDM: Random button •4 INT: Introduction button 8.
Page 106 To search for the previous receivable lower station, press the down arrows. SCAN/AST button (6): Press this button to scan radio stations. (Scan tuning) Scan The radio will go to a station, play for a few seconds, and then go on to the next sta- tion.
Page 107 INSTRUMENT PANEL knob to change the fade between the front and the rear speakers. The display will show the fade level. When finished making the selection, press this button again to select the fade level. Setting the EQ Press this button until “EQ OFF” appears on the display to select customized equal- ization settings designed for classic, dance, rock, jazz, pop, voice and techno.
Page 108 the CD with each press of the up or down arrows. AM button (2): Press this button to listen to the radio when a CD is playing. The inactive CD will remain safely inside the radio for future lis- tening. FM button (3): Press this button to listen to the radio when a CD is playing.
Page 109 INSTRUMENT PANEL radio displays the name of the folder the radio will display “ROOT”. Order of Play Tracks will be played in the following order: Play will begin from the first track under the root directory. When all tracks from the root directory have been played, play will con- tinue from files according to their numerical listing.
Page 110 If the CD is not playing correctly, for any other reason, try a known good CD. If any error occurs repeatedly or if an error cannot be corrected, contact your SUZUKI dealer. If the radio displays an error mes- sage, write it down and provide it to your SUZUKI dealer when reporting the prob- lem.
Page 111 INSTRUMENT PANEL the portable player. You may need to make additional volume adjustments from the portable device if the volume does not go loud or soft enough. 3-37 STEERING WHEEL REMOTE OPER- ATION (if equipped in the vehicle) Power Button Press this button to turn the system on and off.
Page 112 Radio with Six-Disc CD (Double Display, MP3/WMA) (AGH-6400) 1. Power/Volume knob 2. AM button 3. FM button 4. TUNE button 5. SEEK button 6. SCAN/AST button 7. Preset station buttons •1 DIR: Directory button •2 RPT: Repeat button •3 RDM: Random button •4 INT: Introduction button •5 DSC–: Previous CDC button •6 DSC+: Next CDC button...
Page 113 INSTRUMENT PANEL To search for the previous receivable lower station, press the down arrows. SCAN/AST button (6): Press this button to scan radio stations. (Scan tuning) Scan The radio will go to a station, play for a few seconds, and then go on to the next sta- tion.
Page 114 knob to change the fade between the front and the rear speakers. The display will show the fade level. When finished making the selection, press this button again to select the fade level. Setting the EQ Press this button until “EQ OFF” appears on the display to select customized equal- ization settings designed for classic, dance, rock, jazz, pop, voice and techno.
Page 115 INSTRUMENT PANEL the CD with each press of the up or down arrows. AM button (2): Press this button to listen to the radio when a CD is playing. The inactive CD will remain safely inside the radio for future lis- tening.
Page 116 radio displays the name of the folder the radio will display “ROOT”. Order of Play Tracks will be played in the following order: Play will begin from the first track under the root directory. When all tracks from the root directory have been played, play will con- tinue from files according to their numerical listing.
Page 117 If the CD is not playing correctly, for any other reason, try a known good CD. If any error occurs repeatedly or if an error cannot be corrected, contact your SUZUKI dealer. If the radio displays an error mes- sage, write it down and provide it to your SUZUKI dealer when reporting the prob- lem.
Page 118 the portable player. You may need to make additional volume adjustments from the portable device if the volume does not go loud or soft enough. STEERING WHEEL REMOTE OPER- ATION (if equipped in the vehicle) Power Button Press this button to turn the system on and off.
Page 119 INSTRUMENT PANEL CD CHANGER OPERATION (Optional) The CD changer is installed in the trunk. Up to 6 discs can be stored in the maga- zine of the CD changer. A selection of tracks from the 6 discs stored in the disc magazine can be made and automatically played in the order of your preference.
Page 120 How to Change Discs 86Z013 To remove: 1) Open the sliding door of the CD changer to the right until it is completely latched. 86Z014 2) Press the eject button on the CD changer and remove the magazine. INSTRUMENT PANEL 86Z015 3) Pull a tray out of the magazine by pressing the tray button.
Page 121 INSTRUMENT PANEL Labeled surface upward 86Z016 To load: 1) Put the disc on a tray with its label side upward. 2) Insert the tray into the magazine. 3) Push the magazine into the CD changer until it is locked and a click sound is heard.
Page 122 INSTRUMENT PANEL Track Introduction: To quickly and conveniently scan the track, use the “3 or 4/INT” button. “INTRO” will be displayed in VFD and the audio system will play the first 10 seconds of each track. When the player reaches the desired track, press this button again and normal play will resume.
Page 123 INSTRUMENT PANEL MEMO 3-49...
Page 124: Driving Your Vehicle
DRIVING YOUR VEHICLE DRIVING YOUR VEHICLE Your Driving, the Road, and Your Vehicle ... 4-1 Towing ... 4-16...
Page 125 DRIVING YOUR VEHICLE Your Driving, the Road, and Your Vehicle Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start by using a very important safety device in your vehicle: Your safety belt. Buckle up. See “Safety Belts: They Are for Everyone”...
Page 126 It’s the amount of alcohol that counts. For example, if the same person drank three double martinis (3 ounces or 90 ml of liquor each) within an hour, the person’s BAC would be close to 0.12 percent. A per- son who consumes food just before or dur- ing drinking will have a somewhat lower BAC level.
Page 127 DRIVING YOUR VEHICLE Sometimes, as when you’re driving on snow or ice, it’s easy to ask more of those control systems than the tires and road can provide. That means you can lose con- trol of your vehicle. Braking Braking action involves perception time and reaction time.
Page 128 Let’s say the road is wet and you’re driving safely. Suddenly, an animal jumps out in front of you. You slam on the brakes and continue braking. Here’s what happens with ABS: A computer senses that wheels are slow- ing down. If one of the wheels is about to stop rolling, the computer will separately work the brakes at each front wheel and at both rear wheels.
Page 129 You will still have power steering, but steering will be stiffer than normal at slow speeds. See your SUZUKI dealer for service. Steering Tips Driving on Curves It’s important to take curves at a reason- able speed.
Page 130 Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and find a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 131 DRIVING YOUR VEHICLE gerous move, since the passing vehicle occupies the same lane as oncoming traf- fic for several seconds. A miscalculation, an error in judgment, or a brief surrender to frustration or anger can suddenly put the passing driver face to face with the worst of all traffic accidents –...
Page 132 steer the way you want the vehicle to go. If you start steering quickly enough, your vehicle may straighten out. Always be ready for a second skid if it occurs. Of course, traction is reduced when water, snow, ice, gravel or other material is on the road.
Page 133 DRIVING YOUR VEHICLE Remember that your headlamps light up far less of a roadway when you are in a turn or curve. Keep your eyes moving; that way, it’s easier to pick out dimly lighted objects. Just as your headlamps should be checked regularly for proper aim, so should your eyes be examined regularly.
Page 134 Hydroplaning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you’re going fast enough. When your vehi- cle is hydroplaning, it has little or no con- tact with the road.
Page 135: Freeway Driving
If it needs service, have it done before starting out. Of course, you’ll find experienced and able service experts in SUZUKI dealerships all across North America. They’ll be ready and willing to help if you need it. Here are some things you can check before a trip: •...
Page 136: Hill And Mountain Roads
• Tires: They are vitally important to a safe, trouble-free trip. Is the tread good enough for long-distance driving? Are the tires all inflated to the recommended pressure? • Weather Forecasts: What’s the weather outlook along your route? Should you delay your trip a short time to avoid a major storm system? •...
Page 137 DRIVING YOUR VEHICLE • As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident. • You may see highway signs on moun- tains that warn of special problems. Examples are long grades, passing or no-passing zones, a falling rocks area or winding roads.
Page 138 cle’s stability when you make a hard stop on a slippery road.) Whether you have an anti-lock braking system or not, you’ll want to begin stopping sooner than you would on dry pavement. Without anti-lock brakes, if you feel your vehicle begin to slide, let up on the brakes a little.
Page 139 DRIVING YOUR VEHICLE Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged.
Page 140 Towing Towing Your Vehicle Consult your SUZUKI dealer or a profes- sional towing service if you need to have your disabled vehicle towed. If you want to tow your vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see the fol- lowing section, “Recreational Vehicle Tow-...
Page 141 Contact your SUZUKI dealer for further information.
Page 142 Actual weight of the loaded vehicle and actual loads at the front and rear axles can only be determined by weighing the vehicle using a vehicle scale. To measure the weight and load, try taking your vehicle to a highway weighing station, shipping com- pany or inspection station for trucks, etc.
Page 143 DRIVING YOUR VEHICLE WARNING Things you put inside your vehicle can strike and injure people in a sud- den stop or turn, or in a crash. • Put things in the trunk or rear area of your vehicle. In a trunk, put them as far forward as you can.
Page 144: Service And Appearance Care
SERVICE AND APPEARANCE CARE SERVICE AND APPEARANCE CARE Service ... 5-1 Fuel ... 5-1 Checking Things Under the Hood ... 5-4 Headlamp Aiming ... 5-23 Bulb Replacement ... 5-23 Windshield Wiper Blade Replacement ... 5-27 Tires ... 5-28 Tire Pressure Monitoring System ... 5-32 Appearance Care ...
Page 145: Service
Service Your SUZUKI dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to your SUZUKI dealer for all your service needs. You’ll get genuine SUZUKI parts and SUZUKI trained and supported service people.
Page 146 U.S. Environ- mental Protection Agency regulations. SUZUKI recommends that you buy gaso- lines that are advertised to help keep fuel injectors and intake valves clean. If your vehicle experiences problems due to dirty injectors or valves, try a different brand of gasoline.
Page 147 Leave the area immediately. CAUTION If you need a new fuel cap, be sure to get a genuine SUZUKI cap or its equivalent. Your SUZUKI dealer can get one for you. If you get the improper type, it may not fit properly.
Page 148: Checking Things Under The Hood
Filling a Portable Fuel Container WARNING Never fill a portable fuel container while it is in your vehicle. Static elec- tricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle can be damaged if this occurs. To help avoid injury to you and others: •...
Page 149 SERVICE AND APPEARANCE CARE 2) Then go to the front of the vehicle and lift the bottom of the secondary hood release lever upward. The secondary hood release lever is located near the front center of the hood. 3) Lift the hood, release the hood prop from its retainer and place the hood prop into the slot in the hood.
Page 150 Engine Compartment Overview When you open the hood on the engine, you’ll see the following: A. Engine Air Cleaner/Filter B. Engine Oil Filler Cap C. Brake/Clutch Fluid Reservoir D. Engine Coolant Surge Tank E. Underhood Fuse Block F. Battery G. Windshield Washer Fluid Reservoir H.
Page 151 SERVICE AND APPEARANCE CARE Engine Oil If the oil pressure light appears on the instrument cluster, it means you need to check your engine oil level right away. For more information, see “Oil Pressure Light” in section 3. You should check your engine oil level reg- ularly;...
Page 152 This (A) is where you add oil. See “Engine Compartment Overview” on a previous page in this section for more information on location. Be sure to add enough oil to put the level somewhere in the proper operating range. Push the dipstick all the way back in when you’re through.
Page 153 Instead, recycle it by taking it to a place that collects used oil. If you have a problem properly disposing of your used oil, ask your SUZUKI dealer, a service station or a local recycling center for help. Engine Air Cleaner/Filter The engine air cleaner/filter is located on the passenger’s side of the engine com-...
Page 154 If the fluid is contaminated or discolored, change the automatic transmission fluid. A decrease in the fluid level indicates a leak in the automatic transmission. If noted, contact your SUZUKI dealer for repair as soon as possible. SERVICE AND APPEARANCE CARE WARNING This work requires special skill and equipment.
Page 155 Before attempting to do the work, be sure you are fully acquainted with doing this job. Have your SUZUKI dealer do this work if you are not confident you can complete the task safely. Otherwise, you could be injured or could damage the vehicle.
Page 156 Hydraulic Clutch There is one reservoir for both the brake and the hydraulic clutch fluid. See “Brakes” in this section for more information. The hydraulic clutch linkage in your vehicle is self-adjusting. The master cylinder res- ervoir is filled with hydraulic fluid. A fluid loss in this system could indicate a problem.
Page 157 Too much water in the mixture can freeze and crack the engine, radi- ator, heater core and other parts. If you have to add coolant more than four times a year, have your SUZUKI dealer check your cooling system. 5-13 CAUTION If you use the proper coolant, you don’t have to add extra inhibitors or...
Page 158 When replacing the pressure cap, make sure it is hand-tight. Coolant Surge Tank Pressure Cap CAUTION Your coolant surge tank cap is a pressure-type cap and must be tightly installed to prevent coolant loss and possible engine damage from overheating. See “Capacities and Specifications”...
Page 159 SERVICE AND APPEARANCE CARE If the warning continues and you have not stopped, pull over, stop, and park your vehicle right away. If there’s still no sign of steam, you can idle the engine for three minutes while you’re parked. If you still have the warning, turn off the engine and get everyone out of the vehicle until it cools down.
Page 160 WARNING Never turn the cap when the cooling system, including the coolant surge tank pressure cap, is hot. Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They are under pres- sure, and if you loosen the coolant surge tank pressure cap –...
Page 161 MAX mark. 5) Then replace the pressure cap. Be sure the pressure cap is hand-tight and fully seated. See your SUZUKI dealer, if necessary. Power Steering Fluid The power steering fluid reservoir is located toward the front of the engine com- partment on the driver’s side of the vehicle.
Page 162 Windshield Washer Fluid The windshield washer fluid reservoir is located in the front of the engine compart- ment on the driver’s side. See “Engine Compartment Overview” in this section for more information on location. What to Use When you need windshield washer fluid, be sure to read the manufacturer’s instruc- tions before use.
Page 163 Properly torqued wheel nuts are necessary to help prevent brake pulsation. When tires are rotated, inspect brake pads for wear and evenly tighten wheel nuts in the proper sequence to SUZUKI torque specifica- tions. Brake linings should always be replaced as complete axle sets.
Page 164 Brake Pedal Travel See your SUZUKI dealer if the brake pedal does not return to normal height, or if there is a rapid increase in pedal travel. This could be a sign of brake trouble. Brake Adjustment Every time you make a moderate brake stop, your disc brakes adjust for wear.
Page 165 SERVICE AND APPEARANCE CARE CAUTION If the other system isn’t a 12-volt sys- tem with a negative ground, both vehicles can be damaged. Only use vehicles with 12-volt systems with negative grounds to jump start your vehicle. 2) Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other.
Page 166 age the battery and maybe other parts, too. And don’t connect the negative (–) cable to the negative (–) terminal on the dead battery because this can cause sparks. WARNING An electric fan under the hood can start up and injure you even when the engine is not running.
Page 167: Headlamp Aiming
Bulb Replacement For the type of bulb to use, see “Replace- ment Bulbs” in this section. For any bulb changing procedure not listed in this sec- tion, contact your SUZUKI dealer. Halogen Bulbs WARNING Halogen bulbs have pressurized gas inside and can burst if you drop or scratch the bulb.
Page 168 Headlamps N4U5042A To replace a headlamp bulb: 1) Open the hood. 2) Remove the two bolts and one nut shown in the illustration that retain the headlamp assembly. 3) Disconnect the wiring harness connec- tor from the rear of the bulb. 4) Remove the headlamp cap by turning it counterclockwise.
Page 169 SERVICE AND APPEARANCE CARE Center High-Mounted Stop Lamp N4U5046A To replace a center high-mounted stop lamp bulb: 1) Open the liftgate. 2) Pry off the trim and remove the two screws shown in the illustration. 3) Remove the bulb socket from the lamp housing.
Page 170 7) Replace the lamp housing into the vehi- cle using the two screws removed ear- lier. 8) Close the liftgate. Backup Lamps and Tail/Stop Lamps N4U5045A To replace a backup lamp or a tail/stop lamp bulb: 1) Open the liftgate. 2) Remove the protective cover.
Page 171: Windshield Wiper Blade Replacement
SERVICE AND APPEARANCE CARE Rear Sidemarker Lamps To replace a rear sidemarker lamp bulb: 1) Insert your hand into the inside of the rear bumper and hold the socket. 2) Rotate the rear sidemarker lamp bulb socket counterclockwise. 3) Pull the rear sidemarker bulb socket out of the rear bumper.
Page 172: Tires
If you ever have questions about your tire warranty and where to obtain service, see your SUZUKI Warranty booklet for details. For additional information refer to the tire manufacturer’s booklet included with your vehicle’s Owner’s Manual.
Page 173 Tire Size WARNING Your SUZUKI is equipped with tires which are all the same type and size. This is important to ensure proper steering and handling of the vehicle.
Page 174 The following illustration shows an exam- ple of a typical passenger car tire size. A. Tire Type This letter code indicates the primary intended use of the tire. The “P” as the first character in the tire size means a passenger vehicle tire engi- neered to standards set by the U.S.
Page 175 SERVICE AND APPEARANCE CARE Cold Inflation Pressure: The amount of air pressure in a tire, mea- sured in pounds per square inch (psi) before a tire has built up heat from driving. Curb Weight: This means the weight of a motor vehicle with standard and optional equipment including the maximum capacity of fuel, oil and coolant, but without passengers and...
Page 176: Tire Pressure Monitoring System
Speed Rating: An alphanumeric code assigned to a tire indicating the maximum speed at which a tire can operate. Traction: The friction between the tire and the road surface. The amount of grip provided. Tread: The portion of a tire that comes into con- tact with the road.
Page 177 Have your vehi- cle inspected by your SUZUKI dealer. If you use new wheels with new tire infla- tion pressure sensors, their ID codes must be programmed into the tire pressure mon- itoring system.
Page 178 WARNING We highly recommend that any TPMS sensor replacement or tire rotation be done by an authorized Suzuki dealer. The dealer will make sure that the TPMS system is set up to recog- nize the ID codes of the TPMS sen- sors.
Page 179 SERVICE AND APPEARANCE CARE When to Check Check your tires each time you fill your fuel tank or at least once a month using a tire pressure gauge. Don’t forget your compact spare tire. It should be at 60 psi (420 kPa). How to check Use a good quality pocket-type gauge to check tire pressure.
Page 180 (bias, bias-belted or radial) as your original tires. SERVICE AND APPEARANCE CARE WARNING Your SUZUKI is equipped with tires which are all the same type and size. This is important to ensure proper steering and handling of the vehicle.
Page 181 10 to 12 inches (25 to 30 cm), or to some limited-production tires. While the tires available on SUZUKI vehi- cles may vary with respect to these grades, 5-37 they all conform to federal safety require- ments.
Page 182 See your SUZUKI dealer if any of these conditions exist. Your SUZUKI dealer will know the kind of wheel you need. Each new wheel should have the same load-carrying capacity, diameter, width, off- set and be mounted the same way as the one it replaces.
Page 183 SERVICE AND APPEARANCE CARE it’s much more likely to leak out slowly. But if you should ever have a “blowout”, here are a few tips about what to expect and what to do: If a front tire fails, the flat tire will create a drag that pulls the vehicle toward that side.
Page 184 Removing the Spare Tire and Tools A. Jack B. Wrench C. Jack Handle D. Screwdriver The compartment spare tire and tools you’ll need are located in the trunk. WARNING Only use the jack for lifting this car during an emergency tire change. 1) Remove the trim cover from the floor of the cargo area by pulling up on the tab.
Page 185 SERVICE AND APPEARANCE CARE WARNING Raising your vehicle with the jack improperly positioned can damage the vehicle and even make the vehi- cle fall. To help avoid personal injury and vehicle damage, be sure to fit the jack lift head into the proper location before raising the vehicle.
Page 186 This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new SUZUKI original equipment wheel nuts. Stop somewhere as soon as you can and have the nuts tight-...
Page 187 SERVICE AND APPEARANCE CARE Compact Spare Tire Although the compact spare tire was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare tire on your vehicle, you should stop as soon as possible and make sure your compact spare tire is correctly inflated.
Page 188: Appearance Care
Wipe vinyl, leather, plastic and painted surfaces with a clean, damp cloth. Cleaning Fabric/Carpet Your SUZUKI dealer has cleaners for the cleaning of fabric and carpet. They will clean normal spots and stains very well. You can get SUZUKI approved cleaning products from your SUZUKI dealer.
Page 189 • Things like tar, asphalt and shoe polish will stain if you don’t get them off quickly. Use a clean cloth and vinyl cleaner. See your SUZUKI dealer for this product. Cleaning Leather Use a soft cloth with lukewarm water and a mild soap or saddle soap and wipe dry with a soft cloth.
Page 190 Occasional waxing or mild polishing of your vehicle by hand may be necessary to remove residue from the paint finish. You can get SUZUKI-approved cleaning prod- ucts from your SUZUKI dealer. See “Vehi- cle Care/Appearance Materials” later in this section. Your vehicle has a “basecoat/clearcoat”...
Page 191 Minor chips and scratches can be repaired with touch-up materials available from your SUZUKI dealer. Larger areas of finish damage can be corrected in your SUZUKI dealer’s body and paint shop. 5-47 Underbody Maintenance Chemicals used for ice and snow removal and dust control can collect on the under- body.
Page 192: Vehicle Identification
Odorless spray odor Eliminator eliminator used on fabrics, vinyl, leather and carpet. See your SUZUKI parts department for these products. Vehicle Identification Vehicle Identification Number (VIN) This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side.
Page 193 SERVICE AND APPEARANCE CARE Power Windows and Other Power Options Circuit breakers in the fuse block protect the power windows and other power accessories. When the current load is too heavy, the circuit breaker opens, protecting the circuit until the problem is fixed or goes away.
Page 194 Fuses Usages AIRBAG Air Bag Wiper RADIO/CLK Radio/Clock Engine Control Module Occupation Classifi- AIRBAG cation Sensor AUX LTR Extra Jack TRN SIG LAMPS Turn Signal Lamps Antilock Brake System Cigar Lighter Cluster, BTSI CLSTR, BTSI Solenoid Remote keyless Entry BCK/UP Back-up BLANK Not Used...
Page 195: Service And Appearance Care
SERVICE AND APPEARANCE CARE HEAD LAMPS I/P FUSE FUEL PUMP HORN HI BEAM DRIVER’S PWR WNDW STOP LAMPS 5-51 DR/LCK MIR HTD FRT FOG ILLUM LT SPARE ENG SNSR ILLUM RT SPARE LOW BEAM LT LOW BEAM RT SPARE N4U5038B...
Page 196 Fuses Usages HEAD LAMPS Head Lamp Engine Control Module Instrument Panel I/P FUSE Fuse FUEL PUMP Fuel Pump Air Conditioning HORN Horn Head Lamp HI BEAM High-Beam DRIVER’S PWR Driver’s Power WNDW Window STOP LAMPS Stop Lamps DR/LCK Door Lock MIR HTD Heated Mirror FRT FOG...
Page 197: Capacities And Specifications
SERVICE AND APPEARANCE CARE Capacities and Specifications The following approximate capacities are given in English and metric conversions. Capacities Capacities Application English Metric Air Conditioning 1.41 lbs 0.64 kg Refrigerant R-134a Brake/Clutch Fluid 0.53 0.5 L quarts Engine Coolant 7.4 L quarts Engine Oil with Filter 4.0 L...
Page 198 Dimension Overall Length 169.1 in (4,295 mm) Overall Width 67.9 in (1,725 mm) Overall Height 56.9 in (1,445 mm) Wheel Base 102.4 in (2,600 mm) Tread Front 58.3 in (1,480 mm) Rear 58.3 in (1,480 mm) Minimum Ground 6.3 in (160 mm) Clearance Weight Gross Vehicle...
Page 199 SERVICE AND APPEARANCE CARE MEMO 5-55...
Page 200: Maintenance Schedule
MAINTENANCE SCHEDULE MAINTENANCE SCHEDULE General Information ... 6-1 Maintenance ... 6-2...
Page 201: General Information
Non-SUZUKI genuine parts and accesso- ries have not been examined or approved by SUZUKI. SUZUKI can certify neither the suitability nor the safety of non-SUZUKI parts and accessories and is not liable for damage caused by their use.
Page 202 Maintenance Scheduled Maintenance Services Maintenance services and record retention are the owner’s responsibility. You should retain evidence that proper maintenance has been performed on your vehicle in accordance with the scheduled maintenance services chart. Maintenance Recommended under Normal Driving Conditions Maintenance Interval Months...
Page 203 MAINTENANCE SCHEDULE Maintenance Interval Months x 1,000 miles 120 127.5 135 142.5 150 157.5 165 172.5 180 187.5 195 202.5 210 217.5 225 Maintenance Item x 1,000 km Engine Control System (continued) Drive Belt (Alternator, Power steering Pump & A/C Compressor) Engine Oil &...
Page 204 Maintenance Interval Months x 1,000 miles Maintenance Item x 1,000 km Chassis and Body Air Filter (A/C) Exhaust Pipe & Mountings Brake/Clutch Fluid Front Brake Pads & Discs Rear Brake Pads & Discs Parking Brake Brake Line & Connections (Including Booster) Manual Transmission Fluid Automatic Transmission Fluid Chassis and Underbody Bolts and...
Page 205 MAINTENANCE SCHEDULE Maintenance Interval Months x 1,000 miles 120 127.5 135 142.5 150 157.5 165 172.5 180 187.5 195 202.5 210 217.5 225 Maintenance Item x 1,000 km Chassis and Body (continued) Air Filter (A/C) Exhaust Pipe & Mountings Brake/Clutch Fluid Front Brake Pads &...
Page 206 Maintenance Recommended under Severe Driving Conditions Follow this schedule if your car is mainly operated under one or more of the following conditions: • Repeated short-distance driving less than 5 miles (8 km). • Extensive idling and/or slow-speed driving in stop-and-go traffic. •...
Page 207 MAINTENANCE SCHEDULE Maintenance Interval Months x 1,000 miles Maintenance Item x 1,000 km Engine Control System (continued) Drive Belt (Alternator, Power steering Pump & A/C Compressor) Engine Oil & Oil Filter Cooling System Hose & Connections Engine Coolant Dex-cool Fuel Filter (integrated in Fuel Pump) Fuel Line &...
Page 208 Maintenance Interval Months x 1,000 miles 3.75 Maintenance Item x 1,000 km Chassis and Body Air Filter (A/C) Exhaust Pipe & Mountings Brake/Clutch Fluid Front Brake Pads & Discs Rear Brake Pads & Discs Parking Brake Brake Line & Connections (Including Booster) Manual Transmission Fluid Automatic Transmission Fluid...
Page 209 MAINTENANCE SCHEDULE Maintenance Interval Months x 1,000 miles Maintenance Item x 1,000 km Chassis and Body (continued) Air Filter (A/C) Exhaust Pipe & Mountings Brake/Clutch Fluid Front Brake Pads & Discs Rear Brake Pads & Discs Parking Brake Brake Line & Connections (Including Booster) Manual Transmission Fluid Automatic Transmission Fluid...
Page 210: Recommended Fluids And Lubricants
R – Replace or Change NOTE: Check the engine oil and engine coolant levels weekly. *: SUZUKI recommends that this mainte- nance service be performed at the time/ mileage interval indicated to ensure the peak performance and long-term reliability of your vehicle. However, the U.S. Environ-...
Page 211 MAINTENANCE SCHEDULE Maintenance Record Date Odometer Reading Serviced By Maintenance Record 6-11...
Page 212 MAINTENANCE SCHEDULE Maintenance Record Date Odometer Reading Serviced By Maintenance Record 6-12...
Page 213 MAINTENANCE SCHEDULE Maintenance Record Date Odometer Reading Serviced By Maintenance Record 6-13...
Page 214 GENERAL INFORMATION GENERAL INFORMATION Identification Numbers ... 7-1 Safety Certification Label ... 7-2 Emission Compliance Label (for U.S.A.) ... 7-2 Warranties ... 7-2 On-Board Vehicle Computers and Event Data Recorders ... 7-3 Reporting Safety Defects ... 7-4...
Page 215: Identification Numbers
This number is used to register the vehicle. It is also used to assist your SUZUKI dealer when ordering parts or referring to special service information. Engine Serial Number...
Page 216: Safety Certification Label
For U.S.A. The following warranties are provided with your vehicle: • New Vehicle Limited Warranty • Limited Warranty For SUZUKI Parts or Accessories • Emission Components Defect Warranty • Emission Performance Warranty...
Page 217: On-Board Vehicle Computers And Event Data Recorders
SUZUKI’s defense of litiga- tion through the discovery process, or as required by law. In addition, once SUZUKI collects or...
Page 218: Reporting Safety Defects
War- ranty Information booklet. For vehicles registered for use and principally operated in Canada please contact Suzuki Canada Inc. at 1-905- 889-2677 extension 2254 or write to: Suzuki Canada Inc. Customer Relations 100 East Beaver Creek Road...
Page 219 GENERAL INFORMATION MEMO...
Page 220: Index
INDEX Accessory Power Outlet ...3-10 Adding Equipment to the Outside of Your Vehicle ...5-1 Adding Equipment to Your Air Bag-Equipped Vehicle ...1-31 Additives ...5-2 Add-On Electrical Equipment ...5-48 Air Bag Readiness Light ...3-20 Antenna ...2-23 Anti-Lock Brake System (ABS) ...4-3 Anti-Lock Brake System Warning Light ...3-21 Appearance Care ...5-44 Ashtrays and Cigarette Lighter ...3-11...
Page 221 INDEX Doing Your Own Service Work ...5-1 Door Ajar Light ...3-26 Door Ajar Reminder ...2-5 Door Locks ...2-4 Doors and Locks ...2-4 Driver Position ...1-7 Driver Seat Height Adjuster ...1-2 Driving at Night ...4-8 Driving in Rain and on Wet Roads ...4-9 Drunken Driving ...4-1 Electrical System ...5-48 Emission Compliance Label (for U.S.A.) ...7-2...
Page 222 Ignition Positions ...2-11 Infants and Young Children ...1-16 Instrument Panel Cluster ...3-18 Instrument Panel Overview ...3-1 Interior Lamps ...3-9 Jump Starting ...5-20 Keys ...2-1 Lap-Shoulder Belt ...1-11 Leaving Your Vehicle ...2-6 License Plate Lamps ...5-26 Liftgate ...2-6 Loading Your Vehicle ...4-17 Lockout Protection ...2-6 Loss of Control ...4-7 Low Fuel Warning Light ...3-26...
Page 223 INDEX Power Windows and Other Power Options ...5-49 Questions and Answers About Safety Belts ...1-7 Radio with Six-Disc CD (Double Display, MP3/WMA) (AGH-5400) ...3-38 Rear Door Security Locks ...2-5 Rear Seat Armrest ...2-23 Rear Seat Passengers ...1-11 Rear Seats ...1-4 Rear Sidemarker Lamps ...5-27 Rear Window and Outside Rearview Mirror Defogger ...3-16 Rear Window Washer/Wiper ...3-6...
Page 224 Tail/Stop Lamps and Rear Turn Signal Lamps ...5-25 Theft-Deterrent Systems ...2-8 Tilt Wheel ...3-3 Tire Chains ...5-38 Tire Inflation Pressure ...5-34 Tire Inspection and Rotation ...5-35 Tire Pressure Monitoring System ...5-32 Tire Pressure Monitoring System Warning Light ...3-27 Tire Sidewall Labeling ...5-28 Tire Size ...5-29 Tires ...5-28 Top Strap ...1-20...
Page 225 INDEX MEMO...
Page 226 SERVICE STATION INFORMATION Fuel recommendation: See page 5-1 Engine oil recommendation: Engine oil with “Starburst” symbol For further details, see “Engine Oil” in the “SERVICE AND APPEARANCE CARE” section. Brake and clutch fluid: DOT3 Automatic transmission fluid: ESSO LT71141 or TOTAL ATF H50235 Tire cold pressure: See the “Tire Information Label”...

This manual is also suitable for:

2008 reno

Suzuki Reno 2008 Reno Owner's Manual

Table of Contents

Seats and Restraint Systems 1

Features and Controls

Instrument Panel

Service and Appearance Care

Quick Links

Chapters

Related Manuals for Suzuki Reno 2008 Reno

Summary of Contents for Suzuki Reno 2008 Reno

This manual is also suitable for:

Table of Contents
