Atomos Connect-AC
Connect-AC S2H & H2S User Guide
Congratulations on purchasing
your rack-mountable Connect-AC
converter and Test Pattern Generator.
You are now the proud owner of an
extremely compact and versatile
converter.
The built-in Test Pattern Generator
has multiple patterns, in both SD
Register now to receive an upgraded 2 Year Warranty
plus free updates and video tutorials > Register at atomos.com/support
www.atomos.com | Sales: sales @ atomos.com | Support: support @ atomos.com
and HD, the latter including 1080p50
and 60 – true 3G modes.
The modes are indicated by coloured
LEDs, which are explained in this
QuickStart Guide. Learn the colour
sequences and modes for fast and
easy operation.
Advertisement
Table of Contents
Related Manuals for Atomos Connect-AC Series
Summary of Contents for Atomos Connect-AC Series
- Page 1 The built-in Test Pattern Generator easy operation. has multiple patterns, in both SD Register now to receive an upgraded 2 Year Warranty plus free updates and video tutorials > Register at atomos.com/support www.atomos.com | Sales: sales @ atomos.com | Support: support @ atomos.com...
-
Page 2: What's In The Box
(Part No. ATOMACH001) Connect-AC H2S Power Cable CONNECT-AC S2H HD-SDI>HDMI (Part No. ATOMACS001) Connect-AC S2H Power Cable NOTE: This User Guide pertains to both Connect-AC units. Each box contains one converter only. Atomos Connect-AC User Manual V1.0... -
Page 3: Unit Description
LED INDICATOR OVERVIEW Pulldown Removal There are 3 modes of operation indicated Test Pattern Generator by LEDs. Conversion Input Status MODE LED COLOUR TPG> (TEST PATTERN MODE) Mode CONVERTER MODE Progressive/Interlaced TPG MODE Rate FLASHLIGHT MODE Scan Atomos Connect-AC User Manual V1.0... -
Page 4: Converter Mode
A GREEN Rx LED indicates a locked 1080i60 1080psf24 video signal is being converted. 1080i59.94 1080psf23.98 1080i50 720p60 GREEN 1080p30 720p59.94 1080p29.97 720p50 A RED Rx signal indicates searching 1080p25 486i59.94 for a signal for conversion. 1080p24 480i59.94 1080p23.98 576i50 Atomos Connect-AC User Manual V1.0... - Page 5 PDR function is 2:2 Pulldown Removal Operation disabled. To activate the 2:2 pulldown function, Pressing the MODE button a third time press the MODE button once. The PDR turns off the pulldown. LED will turn BLUE. BLUE Atomos Connect-AC User Manual V1.0...
- Page 6 2 seconds. TPG Mode ON (Home) After TPG Mode has been activated, pressing the MODE button at any time will utilise all four LEDs to indicate the current video output mode, as per the following indicators. Atomos Connect-AC User Manual V1.0...
- Page 7 GREEN = film scan rates (23.98, 24 Hz) No Light = television rates (29.97, 59.94, 25, 50 Hz) NOTE: The TPG video mode indication will last for 4 seconds before returning to TPG Home page. Atomos Connect-AC User Manual V1.0...
- Page 8 (This TPG guide is included with your converter as a quick reference card and sticker). NOTE: You must first enter the TPG Video Indication mode in order to 720 50 change the current TPG video output 1080i 50 format. Atomos Connect-AC User Manual V1.0...
- Page 9 Indicator and while in this mode press the PWR/BAT button. To return back to Converter Mode, press and hold the MODE button for more than 2 seconds. 3. Colour Bars 75% 4. Colour Bars 100% Atomos Connect-AC User Manual V1.0...
-
Page 10: Flashlight Function
Arri and RED SDI TC and S/S. In HDMI how to update your converter can be they support Canon and Sony TC and found at: Canon’s S/S, currently the only HDMI TC and S/S protocols available. www.atomos.com/support Atomos Connect-AC User Manual V1.0... -
Page 11: Warranty & Conditions
OF MERCHANTABILITY OR FITNESS FOR A If during the warranty period the product is PARTICULAR PURPOSE. THE REMEDIES OUTLINED shown to be defective Atomos may at its option: IN THIS WARRANTY ARE THE EXCLUSIVE REMEDY A a) replace the goods or supply equivalent ones;... -
