- Page 1 PORTABLE 1000 CLAMPING STAND CLAMPING FORCE HANDS FOLDING FREE LEGS CLAMPING CAPACITY CLAMPING WEIGHT CAPACITY 1000 CLAMPING FORCE FOLDING LEGS MAX WEIGHT CAPACITY KP1102 ED2 (MAY 15)
- Page 2 4. Rear Leg Release Knob 9. Front Leg Release Lock 5. Folding Rear Leg 10. Clamp Lock Lever Model No: ........................KP1102 Maximum Clamping Force: ..................1000kg Maximum Weight Capacity: ..................270kg Clamping Capacity: ....................0-420mm / 465mm-900mm Maximum Material Overhang: ................2000mm Clamping Method:.....................
- Page 3 The clamping stand must be used only for its prescribed purpose. Any other use then those mentioned in this instruction manual will be considered a case of misuse. Kincrome shall not be liable for any damage or injury resulting from such case of misuse.
- Page 4 Portable Clamping Stand User Instructions Congratulations on purchasing your Kincrome KP1102 Portable Clamping Stand. The KP1102 will enable you to safely hold and secure all of your materials or products when you need to work on them. Please thoroughly read and understand all safety and user installation instructions prior to assembly and use of the clamping stand.
- Page 5 PORTABLE CLAMPING STAND 1) Portable Clamping Stand Assembly (Cont.) 6. Unfold the folding front legs (6) towards the front of the portable clamping stand until they locate and click into the fully extended position (fig 4). 7. Unfold the clamp foot pedal (8) by releasing the foot pedal folding release lever (7) (fig5a), then unfold the clamp foot pedal (8) out towards the front of the portable clamping stand (fig 5b) until it clicks &...
- Page 6 PORTABLE CLAMPING STAND 3) Portable Clamping Stand User Instructions (B) 465-900mm 3a) Reversing the sliding clamp rail (1) 1. Ensure that the clamp lock lever (10) located on the front of the clamping stand is in the unlock position as shown in (fig 12). 2.
- Page 7 PORTABLE CLAMPING STAND 5) Folding The Portable Clamping Stand For Storage 1. Fold in the clamp foot pedal (8) by releasing the foot pedal folding release lever (7) (fig 19a), then fold the clamp foot pedal (8) inwards until the clamp foot pedal (8) is flat against the body of the portable clamping stand (fig 19b). 2.
- Page 8 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. For further details please visit www.kincrome.
