3hp Dust Collector
3hp Dust Collector
Single Bag
Single Bag
Please read and fully understand the instructions in
Please read and fully understand the instructions in
this manual before operation. Keep this manual
this manual before operation. Keep this manual
safe for future reference
safe for future reference
1
1
Advertisement
Table of Contents
Related Manuals for SIP 01954
Summary of Contents for SIP 01954
- Page 1 01954 01954 3hp Dust Collector 3hp Dust Collector Single Bag Single Bag Please read and fully understand the instructions in Please read and fully understand the instructions in this manual before operation. Keep this manual this manual before operation. Keep this manual...
-
Page 3: Table Of Contents
CONTENTS CONTENTS Page No. Description Page No. Description Contents Contents General Safety Instructions General Safety Instructions Specific Safety Instructions Specific Safety Instructions Technical Specifications Technical Specifications Contents and Accessories Contents and Accessories Guarantee Guarantee Electrical Connection Electrical Connection Assembly Instructions Assembly Instructions Operating Instructions Operating Instructions... -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS GENERAL SAFETY INSTRUCTIONS 1. KNOW YOUR POWER TOOL. Read this owner's manual carefully. Learn the tool's ap- 1. KNOW YOUR POWER TOOL. Read this owner's manual carefully. Learn the tool's ap- plications and limitations, as well as its specific potential hazards. plications and limitations, as well as its specific potential hazards. - Page 5 GENERAL SAFETY INSTRUCTIONS….cont GENERAL SAFETY INSTRUCTIONS….cont 20. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rota- 20. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rota- tion of the blade or cutter only. tion of the blade or cutter only.
-
Page 6: Specific Safety Instructions
SPECIFIC SAFETY INSTRUCTIONS SPECIFIC SAFETY INSTRUCTIONS Caution! If used incorrectly, woodworking machines can be dangerous; Caution! If used incorrectly, woodworking machines can be dangerous; for this reason always comply with the safety instructions mentioned in this for this reason always comply with the safety instructions mentioned in this manual. - Page 7 SPECIFIC SAFETY INSTRUCTIONS….cont SPECIFIC SAFETY INSTRUCTIONS….cont heat sources. heat sources. If you are not using ‘clear’ extraction hose, periodically remove the hose to If you are not using ‘clear’ extraction hose, periodically remove the hose to check that the inlet to the machine is not getting restricted. (The safety guard check that the inlet to the machine is not getting restricted.
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Part Number 01954 Part Number 01954 Input Voltage 230v ~ 50hz Input Voltage 230v ~ 50hz Power 3 hp (2237 watts) Power 3 hp (2237 watts) Air Flow 2526 m³/hour Air Flow 2526 m³/hour Inlet Ø... -
Page 9: Guarantee
Guarantee: Guarantee: This SIP dust collector is covered by a 24 month parts and labour warranty covering This SIP dust collector is covered by a 24 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or op- failure due to manufacturers defects. -
Page 10: Electrical Connection
Connecting to the power supply: Connecting to the power supply: This SIP dust collector is fitted with a standard 230v ~ 13 amp plug. Before using the This SIP dust collector is fitted with a standard 230v ~ 13 amp plug. Before using the machine, inspect the mains lead and plug to ensure that neither are damaged. -
Page 11: Assembly Instructions
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Firstly; attach the 4 x casters to the relevant Firstly; attach the 4 x casters to the relevant holes on the corners of the base plate using holes on the corners of the base plate using the screws, washers and nuts provided. - Page 12 ASSEMBLY INSTRUCTIONS….cont ASSEMBLY INSTRUCTIONS….cont Fit the 3 x collector supports to the base as Fit the 3 x collector supports to the base as shown with the bolts and washers provided. shown with the bolts and washers provided. Fully tighten to secure. FIG. 5. Fully tighten to secure.
- Page 13 ASSEMBLY INSTRUCTIONS….cont ASSEMBLY INSTRUCTIONS….cont Now fit a hose clamp over the hose and slide Now fit a hose clamp over the hose and slide one end of the hose over the outlet adaptor; fit one end of the hose over the outlet adaptor; fit the 2nd hose clamp over the other end of the the 2nd hose clamp over the other end of the hose and slide that end over the opening in...
- Page 14 ASSEMBLY INSTRUCTIONS….cont ASSEMBLY INSTRUCTIONS….cont When the dust collector has been fully assembled, a second check should be carried When the dust collector has been fully assembled, a second check should be carried out to ensure that all of the nuts, bolts and bags etc. are fitted correctly and are fully out to ensure that all of the nuts, bolts and bags etc.
-
Page 15: Operating Instructions
Your SIP dust collector is fitted with a safety NVR (No Volt Release) switch. This means Your SIP dust collector is fitted with a safety NVR (No Volt Release) switch. This means that if power is cut to the dust collector (such as in a power failure); the motor will not that if power is cut to the dust collector (such as in a power failure);... -
Page 16: Exploded Drawing
EXPLODED DRAWING EXPLODED DRAWING... -
Page 17: Parts List
PARTS LIST PARTS LIST Ref No. Description Ref No. Description Ref No. Description Ref No. Description Universal Caster Main Fan Assembly Outlet Seal Universal Caster Main Fan Assembly Outlet Seal Nut M8 Main Fan Assembly Outlet Nut M8 Main Fan Assembly Outlet Base Plate Hose clamp Base Plate... - Page 18 NOTES NOTES...
- Page 19 NOTES NOTES...
- Page 20 Please dispose of packaging for the product in a responsible Please dispose of packaging for the product in a responsible manner. It is suitable for recycling. Help to protect the manner. It is suitable for recycling. Help to protect the environment, take the packaging to the local amenity tip environment, take the packaging to the local amenity tip and place into the appropriate recycling bin.
