DIGITAL MULTIMETER
600.219
600.524
Gebruiksaanwijzing
Instruction Manual
Mode d'Emploi
Gebrauchsanleitung
Brugsanvisning

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 600.219 and is the answer not in the manual?

Questions and answers

Summary of Contents for SKYTRONIC 600.219

  • Page 1 DIGITAL MULTIMETER 600.219 600.524 Gebruiksaanwijzing Instruction Manual Mode d’Emploi Gebrauchsanleitung Brugsanvisning...
  • Page 3 The warranty is not applicable in case of accidents or damages caused by inappropriate use or disrespect of the warnings contained in this manual. SkyTronic UK cannot be held responsible for personal injuries caused by a disrespect of the safety recommendations and warnings. This is also applicable to...
  • Page 4 WARNING To avoid possible electric shock or personal injury, follow these guidelines: • Do not use the meter if it is damaged. Before you use the meter, inspect the case. Pay particular attention to the insulation surrounding the connectors • Inspect the test leads for damaged insulation or exposed metal.
  • Page 5: Maintenance

    CAUTION To avoid possible damage to the meter or to the equipment under test, follow these guidelines: • Disconnect circuit power and discharge all high-voltage capacitors before testing resistance, continuity, diodes, or capacitance. • Use the proper terminals, function, and range for your measurements.
  • Page 6: General Specifications

    FRONT PANEL DESCRIPTION Power Switch Capacitor Measuring Socket Transistor Testing Socket Function Range Switch Temperature Measuring Socket (For 600.219 only) Input Jacks GENERAL SPECIFICATIONS Maximum Display: 1999 counts (3 ½ Digits) with automatic polarity indication Indication Method: LCD display Measuring Method: Dual-slope integration A/D converter system Overrange Indication: Only figure “1”...
  • Page 7 ±(0.5% rdg +2D) 10mV 200V 100mV 1000V ±(1.0% rdg +2D) Input impedance: 10MΩ for all ranges AC VOLTAGE ACCURACY RANGE RESOLUTION 600.219 600.524 200mV 0.1mV ±(1.2% rdg+2D) ±0.8% rdg ±3D 10mV 200V 100mV 700V ±1.5% rdg ±3D Input impedance: 10MΩ for all ranges...
  • Page 8 DC CURRENT ACCURACY RANGE RESOLUTION 600.219 600.524 200µA 0.1µA ±0.8% rdg+1D) 1µA 20mA 10µA 200mA 100µA ±(1.2% rdg+1D) 10mA ±(2.0% rdg+5D) Overload protection: 600.219: 250mA/250V fused (Range 20A unfused) 600.524: 2A/250V fused (Range 20A unfused) Maximum input current: 20A (can not last for more than 10 seconds)
  • Page 9 2KΩ 1Ω 20KΩ 10Ω ±(0.8% rdg+2D) 200KΩ 100Ω 2MΩ 1KΩ 20MΩ 10KΩ ±(1.2% rdg+2D) Open cicuit voltage: less than 700mV. FREQUENCY (For 600.219 only) RANGE RESOLUTION ACCURACY 20KHz 10Hz ±(1.0% rdg+1D) CAPACITANCE (For 600.219 only) RANGE RESOLUTION ACCURACY 2000pF 20nF 10pF ±(1.0% rdg+5D)
  • Page 10 TEMPERATURE (For 600.219 only) RANGE Temperature Range RESOLUTION ACCURACY 0ºC ~ 400ºC 1ºC ±(1.5% rdg+3ºC) TEMP. 400ºC ~ 1000ºC 1ºC ±(1.5% rdg+15ºC) Note: Use “K” type thermocouple probe while measuring temperature. DIODE AND AUDIBELE CONTINUITY TEST Range Description Test Condition The approx.
  • Page 11: Dc Voltage Measurement

    Read the voltage value displayed on the. DC CURRENT MEASUREMENT [600.219] Connect the black test lead to the "COM" jack and the red test lead to the "mA" jack (While the current to be measured is between 200MA and 20A, remove the red test lead to the “20A”...
  • Page 12: Resistance Measurement

    DC CURRENT MEASUREMENT [600.219] Connect the black test lead to the "COM" jack and the red test lead to the "mA" jack (While the current to be measured is between 200MA and 20A, remove the red test lead to the “20A”...
  • Page 13: Diode Test

    Read the approximate hFE value at the test condition of base current 10µA and Vce 2.8V. FREQUENCY MEASUREMENT (For 600.219 only) Set the Function / Range switch to the “KHz” range. Connect the black test lead to the “COM” jack and the red test lead to the “V/Ω”...
  • Page 14: Auto Power Off

    Fuse rarely needs replacement and is blown as a result of the operator's error. To replace the fuse, open the case, and replace the blown fuse with the ratings specified: F 250mA/250V (600.219) F 2A/250V (600.524) and then close the case.
  • Page 15 été provoqués suite à une mauvaise utilisation et le non-respect des avertissements et consignes de sécurité contenus dans ce manuel. SkyTronic décline toute responsabilité en cas de dommages corporels suite au non-respect des consignes de sécurité et des avertissements. Ceci s’applique aussi aux préjudices ultérieurs...
