Summary of Contents for Partizan PAB-FC2
- Page 2 Partizan PAB-FC2 Features & Technical Parameters 1.1 Features: ● Metal vandalproof housing ● Secure and reliable biometric fingerprint recognition ● Simple for using, wiring can be done by a user without professional knowledge ● Luminous touch unlock button. Manually or automatically enter dormant state ●...
- Page 3 Pic. 1 Device installation Pic. 2 Principle of the electric lock connection...
- Page 4 Pic. 3 Wiring diagram Pic. 4 Connection to the access controller (reader mode) 3. Master setting by IR remote control Note that all the following settings should be done under Master programming mode. If master PIN is wrong and time is over 5 seconds after PIN entering, the device will return to standby mode.
- Page 5 Access controller settings Red flash Orange Functions Description 6-8 digits of a new PIN, #, repeat 6-8 To change Master PIN digits of a new PIN, # Add 1 Master “add fingerprint” “add fingerprint” – for 1(ID), #, press Master fingerprint twice adding a user.
-
Page 6: User Operation
4. Master fingerprint operation To add users Press Master Add fingerprint once, press user fingerprint twice, press Master Add fingerprint once to complete. To delete users Press Master Delete fingerprint once, press user fingerprint once, press Master Delete fingerprint once to complete. -
Page 7: Reader Mode
9. Reader mode Before using the device, you need to add user fingerprints, set door relay timer and facility code. Device format data output - Wiegand 26. It's a virtual card number which consists of facility code (0-255) and fingerprint ID (3-1000). For example: facility code is set 255, fingerprint ID is 3, then output virtual card number 255, 00003.
