SecurUS eZoom Quick Start Manual And Auto Installation Manual

Portable tracking and safety gps locator
Hide thumbs
Table of Contents

Advertisement

Quick Links

e
Zoom
™
PERSONAL GPS LOCATOR
Portable Tracking and Safety
GPS Locator
Quick Start Guide and Auto Installation Guide
A
Product
© 2014 Securus, Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eZoom and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SecurUS eZoom

Summary of Contents for SecurUS eZoom

  • Page 1 Zoom ™ PERSONAL GPS LOCATOR Portable Tracking and Safety GPS Locator Quick Start Guide and Auto Installation Guide Product © 2014 Securus, Inc. All rights reserved.
  • Page 2 • Press the Arm button on the screen. When it turns green, the eZoom is armed and will alert you if it is moved from its location. • Note: Alerts are not sent when eZoom is tracking. Activate and charge eZoom before installing with auto installation kit.
  • Page 3 Solid Fully charged Battery is low Flashing Network Connecting Flashing every 5 seconds Connected Flashing every 10 seconds Not connected Not flashing All 3 lights SOS button pressed Solid until alert is closed For more information about eZoom, click here.

  • Page 4: Getting Started

    5 hours. Note: The initial charging time is • Place your eZoom outside or in a window with a clear view of the sky before activating to ensure a strong GPS signal connection. • DO NOT PRESS SOS BUTTON UNTIL ACTIVATED.
  • Page 5 Customer Registration form. • Enter information when prompted. • Press Submit. • You will be sent a confirmation of your registration to the email address you entered in the registration form. For more information about eZoom, click here.

  • Page 6: Account Activation

    • Select • Enter your IMEI when prompted. This can be found on the back of your eZoom locator (see step 2) or on the bottom of the package. Click Next. • Enter information when prompted. • Select a Service Plan and the Extended Warranty (optional), enter your credit card information and click Next.
  • Page 7 5. Edit Alert Settings Change • Click on the Settings page. • You have the option to receive alerts when the eZoom enters or leaves SafeSpots. • If desired, create SafeSpots and select how you wish to be alerted. • Alert Settings: •...
  • Page 8 6. Find and Track Your eZoom Find • Online at www.SecurusGPS.com/GPSaaS: • Log into your account and click Find. • The eZoom’s current location will display on the map. • From your mobile phone: Find <locator name> • Text to 96225 from a cell phone registered in step 5.
  • Page 9 • You can view and/or download recent location history in your tracking dashboard. Location history is recorded if you did a FIND request or if your eZoom is in continuous tracking mode. History • To view history, click under your locator on the tracking dashboard.
  • Page 10 • To edit the address, name or radius of a Safespot, click Edit. • Make the changes you would like. • Click Save. • To delete a Safespot, select the SafeSpot you would like to remove from the dropdown menu and click Delete. For more information about eZoom, click here.
  • Page 11 Manage Account • Click at the top of the tracking website. Change • Edit details by clicking and then click Save in each window to save your changes. For more information about eZoom, click here.
  • Page 12 Zoom ™ PERSONAL GPS LOCATOR Guide to Auto Installation Product © 2014 Securus, Inc. All rights reserved.

  • Page 13: General Safety

    In glove box • In center console If you choose to install your eZoom Locator using the 12 Volt DC Car Charger and Installation Kit, please carefully review the following instructions before installing and using your eZoom Locator. General Safety This installation manual covers the installation of the Locator and should be used to ensure a safe and functional Locator installation.

  • Page 14: Fcc Regulations

    • Consult the dealer or an experienced radio/TV technician for help. • Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. For more information about eZoom, click here.

  • Page 15: Safety And Warranty Information

    Locator. If battery leakage occurs, avoid contact with skin. If contact occurs, immediately wash thoroughly with soap and water. If liquid leaking from battery pack comes in contact with your eyes, immediately flush your eyes thoroughly with water and contact your doctor.

  • Page 16: Equipment List

    Assure That Your eZoom is Activated and Charged See the Quick Start Guide for complete details on how to activate your Locator. Install Your Locator and Connect to Constant Power Basic Tools Needed for Installation • Metric and standard socket set •...

  • Page 17: Installation Process

    Installation Process 1. Select Your Installation Location To ensure proper operation, the eZoom Locator must be installed in one of the following three concealed locations: A. Under Front Driver or Passenger Seat Select a concealed location under the front driver or passenger seat. Make sure that installation of the unit and placement of wiring does not impede or interfere with normal operation of the seat.
  • Page 18 • DO NOT mount the eZoom Locator where it will be exposed to moisture • DO NOT mount the eZoom Locator in a spot that will impede safe vehicle operation • Make sure the positioning of the Locator does not interfere with any...
  • Page 19 ANY HARNESS TAPED IN YELLOW OR BEARING YELLOW “SRS” (SUPPLEMENTAL RESTRAINT SYSTEM) TAGS. Use wire ties to secure wiring from being pulled out of the eZoom Locator and to ensure that it does not interfere with any vehicle components. Black Wire (-) ground wire Once the eZoom Locator charger is mounted, connect the black ground wire to an existing factory bolt using crimp-on ring connector.
  • Page 20 Most new vehicles incorporate battery saver circuits which switch off power to non-essential accessories after the vehicle has been switched off. Consult the vehicle manufacture shop manual for location and descriptions of these circuits. For more information about eZoom, click here.
  • Page 21 A. Insert micro USB on the Charger into the USB Safety Clip. B. Insert micro USB into the eZoom locator. C. Close the USB Safety Clip around the eZoom locator (check for secure fit). For more information about eZoom, click here.
  • Page 22 Solid until alert is closed pressed Use only branded original chargers and accessories intended for use with your eZoom Locator. Other chargers and accessories may not be designed to the same safety and performance standards. For more information about eZoom, click here.
