T3B TWS Specifications and User Manual
20190506

Earphone Basic Specifications

■ Size: single-earphone 23.4x18.5x21mm
■ Weight: 4.8g (Only one earphone)
■ Earphone Charging Port:magnetic type
■ Button: 1 (MFB )
■ Charge indicator:Blink blue light (Charging) / light off (Charging completed)
■ Battery :Li-polymer Battery 80mAh 3.7V/0.296Wh(One earphone)
■ Earphone Charging Current: 80mA
■ Earphone Charging time: 2 hour
■ Working Voltage: 3.3V~4.2V
■ Standby time: about 160 hours
■ Battery and Power
■ Earphone(single charge):
Music Time: 5 hours
Talking Time: 5 hours
■ Earphone with Charging case:
Music Time:10~11 hours
Talking Time:10~11 hours
1 / 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T3B TWS and is the answer not in the manual?

Questions and answers

Related Manuals for Mees T3B TWS

Summary of Contents for Mees T3B TWS

  • Page 1 T3B TWS Specifications and User Manual 20190506 Earphone Basic Specifications ■ Size: single-earphone 23.4x18.5x21mm ■ Weight: 4.8g (Only one earphone) ■ Earphone Charging Port:magnetic type ■ Button: 1 (MFB ) ■ Charge indicator:Blink blue light (Charging) / light off (Charging completed) ■...
  • Page 2 ※ Working time of main earphone in the state of two earphones:＜5 Hours ■ Bluetooth version: Bluetooth 5.0 ■ Bluetooth chip: BES200S ■ Support Profile: HSP, HFP, A2DP, AVRCP ■ The remote control to speaker: MFB (Play/Pause/Stop, Volume+/Volume-, Next song, Previous song) ■...
  • Page 3 ■ Working temperature: -15℃～+60℃ ■ Working humidity: 10%~85%( in a non-frozen state) Operating Instructions Bluetooth pairing 1. Take out both earphones from the charging case,they interconnected within 10 seconds,you can hear a “click” if wearing; with “Pairing” prompt tone, afterward to enter pairing mode; 2.
  • Page 4 Case status lights Charging Flashing blue light Full charge Steady blue light Notes: It will turn off automatically after 5 minutes if without any connection with mobile phone when it turns on. Pairing time: 3 minutes. It will quit the pairing mode automatically after 3 minutes if without any connection with mobile phone when it is in the state of pairing.
