- Page 1 Operation Manual Version 2.0 E Series E-6, E-8, E-10, E-12, E-15 ESW-110, ESW-115, ESW-118 Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 Exel Acoustics SL accepts no responsibility for any errors or inaccuracies that may appear in this manual or the products and software described in it. Technical specifications, dimensions, weights and properties do not represent guaranteed qualities.
-
Page 4: Important Safe Instructions
/ apparatus combination to avoid injury from tip-over. If the equipment is used in a manner not specified by the Exel Acoustic, the protection by the equipment may be impaired. Read all the Product Information document before exploiting the system. - Page 5 Operation Manual SYMBOLS USED OBLIGATION.This Important operating Additional instructions must instructions information be strictly followed Obligation. Cela Pour indequer important Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Informationen. Betriebsanweisung Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung Obligación.
-
Page 6: Declaración De Conformidad
Operation Manual DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY EXEL ACOUSTICS SL CL Encinar, 282. Polígono Industrial Monte Boyal. 45950 – Casarrubios del Monte (Toledo), España (Spain). Declara que los productos E Series y sus respectivas opciones, cumple con las Directivas:... -
Page 7: Table Of Contents
Operation Manual Table of Contents IMPORTANT SAFE INSTRUCTIONS..................3 DECLARACIÓN DE CONFORMIDAD ..................5 Introduction ........................7 Welcome to Tecnare ....................7 Overview........................8 The E Series Loudspeaker ..................9 Connections ......................12 Processing and Amplification..................13 Loudspeakers Configurations ..................14 Full Range Stereo/Parallel configuration ..............14 Full Range with low-frequency element..............14 Recommended Amplifier Power................15 Recommended Speaker Cables ................15 Flying and Suspension....................16... -
Page 8: Introduction
If you would like further information about this or any other Tecnare product, please contact us. We look forward to helping you in the near future. As part of a continuous evolution of techniques and standards, Exel Acoustics ® SL as manufacturer of Tecnare products reserve the right to change the specifications of its products and the content of its documents without prior notice. -
Page 9: Overview
Operation Manual Overview E Series is a line of low-cost speakers that deliver the best relationship price-quality, power handling, and rugged build in their class. Custom built, industry leading Tecnare transducers and enclosures give E SERIES the power and ruggedness to stand up to a variety of demanding applications and provide reliable, highest quality sound wherever it is needed. -
Page 10: The E Series Loudspeaker
Operation Manual The E Series Loudspeaker FEATURES The Tecnare E6 loudspeaker are comprised of: One 6,5-inch driver one 1-inch HF compression driver. Built-in rigging points (eyebolt) The E-6 is a ultra-compact 2-way passive loudspeaker that used a 6.5” low-mid frequency transducer in a bass-reflex cabinet and an 1”... - Page 11 Operation Manual E-12 The Tecnare E12 loudspeaker are comprised of: One 12-inch driver one 1-inch HF compression driver on a CD Horn Built-in rigging points (eyebolt) A Pone mount socket The E-12 is a compact 2-way passive loudspeaker that used a 6.5”...
- Page 12 Operation Manual ESW-115 Tecnare ESW-115 loudspeaker comprised of: One 15-inch long excursion driver 3/side recessed handles Top located pole mount socket The ESW-115 is band pass rear horn- loaded subwoofer that used a 15” long excursion low frequency transducer. The response given is very deep, starting at 38Hz.
-
Page 13: Connections
Operation Manual Connections ® ® E Series loudspeakers utilize Neutrik SpeakON connectors. There are two NLT4 ® connectors on the rear of each E Series enclosure. These connectors mate with Neutrik NL-4 or NL-4 compatible in-line cable connectors. The pins 1+/1- of both connectors are wired in parallel to link multiple loudspeakers on a single amplifier output. -
Page 14: Processing And Amplification
Operation Manual Processing and Amplification Only operate Tecnare loudspeaker with a correctly configured Tecnare preset. Tecnare offer a complete solution that guarantees the highest level of performance. A complete range of controllers, amplified and amplified controller with DSP are available to get this objective. Otherwise, there is a risk of damaging the loudspeaker components. -
Page 15: Loudspeakers Configurations
Operation Manual Loudspeakers Configurations Full Range Stereo/Parallel configuration Each enclosure type is driven by the PA Series amplifier according the cabinet power requirements. Correct factory preset is needed. Connect the amplifier's output to the Speakon’s input of the first cabinet, always respecting the polarity positive +1, negative -1. -
Page 16: Recommended Amplifier Power
Operation Manual Recommended Amplifier Power Model Full-Range/ Parallel Model recommended 80 to 320 W @ 8Ω PA900/PA4.450 100 to 400 W @ 8Ω PA900/PA4.450 200 to 800 W @ 8Ω E-10 PA900/PA4.450 250 to 1.000 W @ 8Ω E-12 PA900/PA2100/PA4.450 PA900/PA2100/PA3000/PA4.450 350 to 1.400 W @ 8Ω... -
Page 17: Flying And Suspension
Operation Manual Flying and Suspension Tecnare E series offers 4 kind optional accessories for suspendable: BR U-Bracket, HG1 Wall and Truss Bracket, HG2 Ceiling Bracket and TSC-350 Wall Mount. Before attempting to suspend your speakers, read and understand the following safety information. -
Page 18: Tripod Use
Operation Manual Tripod Use The E-10, E-12 and E-15 models are equipped with a pole mount socket for use with a standard 35mm tripod. Do not use the tripod on non-flat floors and be careful not to raise the cabinet too high on the tripod, as it may become unstable. - Page 19 Operation Manual 3.4.3 Flying with Eyebolts E Series loudspeakers feature several internal steel angles, with 2 mounting threads each. This angles provides different flying points. Eyebolt flying points are factory sealed with M6, M8 and M10 screws, which are replacement with eyebolt on the flying points as required. It is specially recommended for fixes d installations where the boxes are permanently fixed.
-
Page 20: Technical Specifications
Eye bolt TSC-350 Application information is presented for guidance only. Exel Acoustics SL reserves the right to make any necessary changes to the products and the published specifications. As part of the ongoing development program Exel Acoustics SL tries to maintain the highest degree of product compatibility. - Page 21 Operation Manual E Series | rev. 2.00 www.tecnare.com...
- Page 22 The contents of this manual are furnished for informational purposes only, are subject to change without notice, and should not be construed as a commitment by Exel Acoustics SL. Exel Acoustics assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Except as permitted by applicable copyright law, no part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording or otherwise, without prior written permission from Exel Acoustics.
- Page 23 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:2.00 2017...
