- Page 1 MEET DIGITAL VIDEO PANEL INSTALLER'S MANUAL ENGLISH Version Cod. 970134Ib V05_19 This manual corresponds to MEET Digital Video Panel firmware version V2.0.
- Page 2 FERMAX ELECTRÓNICA S.A.U. http://www.fermax.com MEET DIGITAL VIDEO Panel manual available at https://www.fermax.com/qr/meet/ Copyright Notice Fermax and Fermax MEET panel are trademarks of Fermax Electronica S.A.U. registered in the European Union and other countries. © FERMAX ELECTRÓNICA S.A.U., 2018. Page 2...
-
Page 3: Table Of Contents
INDEX 1 Product Introduction ....................... 4 Overview ......................... 4 Panel Display Screen ..................... 5 2 Functions Introduction ....................5 Call Apartment ......................6 2.1.1 Block Panel call apartment ................6 2.1.2 ... -
Page 4: Product Introduction
1 Product Introduction Overview High definition camera 1,2Mpx Lighting for night vision with LEDs Speaker Motion sensor 4.3” TFT Digital keyboard (capacitive or mechanical) Mifare reader Microphone Slider Page 4... -
Page 5: Panel Display Screen
Panel Display Screen Network Status 2 Functions Introduction Call apartment Call guard unit Call volume settings Door opening, relay delay settings Connect exit button Speech Door opened and tamper alarm Lift control (Only when installed) ... -
Page 6: Call Apartment
Call Apartment 2.1.1 Block Panel call apartment Visitors need to enter apartment number followed by B to confirm. For example, if the resident lives in apartment 201, the visitor should enter: 201 and press B. 2.1.2 General Entry Panel call apartment Visitors need to enter block number followed by a 4 digits apartment number followed by B to confirm. -
Page 7: Call Guard Unit
Call Guard Unit 2.2.1 Block Panel Call Guard Unit The visitor or resident can call the guard unit by entering the number 9901 followed by B to confirm. This call can be made from all Block Entry Panels. 2.2.1 General Entry Panel Call Guard Unit The visitor or resident need can call the main guard unit by entering the number 9901 followed by B to confirm. -
Page 8: Access Code
Access Code Press key “A0” to access PIN code function, entering the access code followed by B to confirm. If the access code is correct the door will open and release the lock. You can enable or disable the function at web of the panel. The access code to be defined at web of the panel, Maximum access code length 6 digits. -
Page 9: About
About Enter code 9999 followed by B to confirm, The ABOUT information will show. You can get information about the device name, firmware version, IP address, MAC address. Page 9... -
Page 10: Configuration Via Web Server
3 Configuration via Web Server The panel has an integrated web server, which allows to configure the parameters. This web server is accessed via the panel’s IP address. The browser opens with the configured IP address of the panel. A screen opens requesting a username and password Default IP: 10.1.0.1 Username: admin... -
Page 11: General Settings
General Settings Configures the panel type: General entrance panel or block panel. 3.2.1 General Entrance Panel DEVICE NO.: General entrance panel number, between 1 and 9000. TYPE: For General Entrance select G.E.PANEL. The panel can communicate with all devices of the installation. LANGUAGE: select the desired language in the dropdown options. - Page 12 Page 12...
-
Page 13: Block Panel
3.2.2 Block Panel BLOCK: Block number, between 001 and 999 (default option 1). DEVICE NO.: Panel Number, between:01-99 (default option 1). TYPE: For block entrance, choose BLOCK PANEL. The panel can communicate with all devices on the same block. LANGUAGE: Select the desired language for the drop-down options. (default option ENGLISH). Refresh the webpage after change the language. - Page 14 NOTE: Do not use TIME ZONE setting if panel is connected to Internet or Management Software. Date and time can’t be saved after power loss, the time zone and date format can be saved. Page 14...
-
Page 15: Network Settings
Network Settings MEET allows the installer to define the IP range according to the project needs and make the network management easier. MEET panel network mode is static mode. Ensure that each device has a unique IP address in same installation. The devices (digital panel, monitor and guard unit) will show IP conflict if there same IP is used on the same LAN. -
Page 16: Access
Access DOOR RELAY TIME: Time for lock-release relay remains active (1-9s optional). OPEN DOOR DELAY: The time when the unlocked signal is sent to the start of the relay. The delay time is useful when the lock is not close panel (0-9s optional). EXT. -
Page 17: Face Recognition
FACE RECOGNITION: Enable or disabled face recognition function. SIMILARITY: High, medium and low options. Default is low. The face data must be added through MEET management software. IP Camera The monitor can switch to IP CCTV camera video during a conversation. This function allows to configure IP CCTV cameras using RTSP protocol to be displayed as an auxiliary camera to provide different view angles from the door or related areas. - Page 18 Page 18...
-
Page 19: Sip Settings
SIP Settings ENABLE SIP: Enable or disable sip function. SIP SERVER: SIP server IP address. DOMAIN: Sip server domain. OUTBOUND: Some servers are used when NAT is active on the router. STUN IP: Audio and video NAT traversing public network server IP. STUN PORT: The port of audio and video NAT traversing public network server. -
Page 20: Sip Trunk
SIP Trunk When there is a VoIP gateway installed on the system or a sip server has a PSTN line. The panel call can be diverted to user's mobile phone or land line telephone through a voice gateway. ENABLE SIP TRUNK: Enable or disable SIP trunk function. URL: sip: sip account @ wan IP: 5062 Page 20... -
Page 21: Pincode Settings
Pincode Settings This allows to change the pin code of the web server login. Logout Log out the web server. Page 21... -
Page 22: Installation
4 Installation Installation height Page 22... -
Page 23: Installation Step Diagram
Installation Step Diagram ○ ○ ○ ,3The upper part of the panel is Flush ,2Base flush box depth adjustment hook. stuck in, then move the panel to the flush box. 2.2CM 2.2CM ○ ,4Move the slider of the panel and fix the two screws. When installing, pay attention to the reservation of the 2.2CM space around the door to move the slide cover. -
Page 24: Connectors
Connectors PANELS WITH HW 95770/95771 PANELS WITH HW 95770B/95771B 10/100Mbps RJ45 Port. +, —: 12Vdc Power Input. C, NO, NC: Relay contacts for release lock, the double terminals are the same connection. +5V, —, WD0, WD1: Wigand-26 protocol output or input. ... -
Page 25: Technical Parameters
Technical Parameters Dimensions Panel (mm): 154(W) ×379(H) ×50(D) Flush box (mm): 142(W) ×357(H) ×58(D) Power supply: 12Vdc Standby current: 250mA Working current: 500mA Technical specifications of the display: -Size: 4.3 inch -Format: 4:3 -Resolution: 480*272 Camera pixel: 1.2 megapixels visual angle: Vertical 72º, Horizontal 54º Minimum illumination: 0.5Lux Maximum conversation time: 120s Door relay time: 1-9s...
