Summary of Contents for Sirus MXA 3500
- Page 1 Manual Mixer MXA 3500...
-
Page 2: Table Of Contents
Table of content Safety instructions ..........................3 1.1. FOR SAFE AND EFFICIENT OPERATION ................3 Einleitung ................... Fehler! Textmarke nicht definiert. 2.1.1. Product features ......................4 2.1.2. Specifications ........................5 Controls/ Connections ........................6 3.1. Front view ..........................6 3.2. Back view .......................... -
Page 3: Safety Instructions
1. Safety instructions • Read the safety instructions and also this manual carefully. • Keep the manual. • Observe all red flags. • Observe the manual. • To prevent fire or electric shocks, protect the device against rain and humidity •... -
Page 4: Product Features
Safety Do not remove the grounding. It is for your safety. If you remove the grounding it can cause electric shocks. Hearing To avoid hearing damages, you should not operate a sound system with high levels. This applies to monitor systems, which are in the near of the ear, headphones or IEMs also. Accessory Please use only the accessory which is set by the manufacturer. -
Page 5: Specifications
2.1.2. Specifications Audio Inputs Mic 1 40dB Gain, elec, balanced Inputs Phono 1, 2, 3 40dB Gain @1kHz, unbalanced input Line 1, ,2, 3 0dB Gain, unbalanced Inputs Audio Outputs Master max. +21dBu @ +10db (Line in) Booth max. +21dBu @ +10db (Line in) Tape Type.0 dBu Phones XLR Balanced... -
Page 6: Controls/ Connections
3. Controls/ Connections 3.1. Front view 1. MIC Input Balanced XLR connector for dynamic microphones. 2. Channel Gain With this control you line up the input signal of each channel. 6 / 10... - Page 7 3. Equalizer Each cannel has a 3-hand-EQ (HIGH, MID, LOW) This EQ enables an attenuation range from -32dB up to +12dB. You can use this for raising or lowering specific frequency ranges. Nevertheless the EQ is not for producing a higher volume.
- Page 8 18. Headphones Here you can plug in headphones which should have a minimum impedance of 32Ω. 19. Mode Key With this button you can choose between USB, SD Card and Bluetooth as signal source. 20. Play/Pause Key Wirth this button you can start or pause the playback. 21.
-
Page 9: Back View
3.2. Back view 29. Phone/Line Switch With this button you can set if the signal source is a Line or a Phono signal. The selector switch at the front has to be set on Line/Phono. 30. Input 1 Phono/Line input of channel 1. 31. - Page 10 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 10 / 10...
