- Page 1 MILLENNIUM MY2019 ISA S.p.A. Via Madonna di Campagna 123 - 06083 Bastia Umbra PG - Italy T. +39 075 801 71 - F. +39 075 800 09 00 - E. customerservice@isaitaly.com www.isaitaly.com USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
-
Page 2: Table Of Contents
OPERATOR SIDE OPENING / CLOSING CONTROL PANEL 12.1 USER INTERFACE XR44CH 12.1.1 LIST OF ALARMS CLEANING 13.1 INTERNAL 13.2 CONDENSER UNIT (REMOVABLE) 13.3 FILTER 13.4 DEFROST WATER COLLECTION TRAY (IF PRESENT) PROLONGED APPLIANCE SWITCH-OFF USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... - Page 3 Live electrical parts or technical assistance centre ATTENTION / DANGER Important information Operations that must be performed by two Information persons Eye check Notes/Important Notes DANGER Waste disposal Slipping DANGER Recyclable Material Tripping Earthing USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
-
Page 4: Notes / Warnings
TRANSLATION OF THE ORIGINAL INSTRUCTIONS NOTES / WARNINGS ISA employs materials of the best quality and as they enter the company, we con- stantly monitor their storage and the use as part of the manufacturing process to prevent damage, deterioration and failure. All manufacturing elements have been de- signed and manufactured in order to guarantee reliability and high safety standards. - Page 5 NOTE The contents of this manual are of a technical nature and are owned by ISA . It is forbidden to reproduce, circulate or modify all or part of its content without written consent. Any infringement will be legally pursued.
- Page 6 Keep the air vents in the casing of the appliance or in the structure built into the wall free of obstructions. Do not damage the refrigeration circuit. “A”-weighted sound pressure level lower than 70 dB(A). RISK OF EXPLOSION Do not store products containing flammable propellants or explosives. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
- Page 7 The refrigerant system is High Pressure. Do not tamper with the system, but call a specialised and qualified technician before disassembly. ATTENTION Maintenance must be performed by qualified personnel that has been to work with flammable refrigerants. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
- Page 8 17 m³ for each cooling system present in the room. ATTENTION Maintenance must be performed by qualified technical personnel trained and enabled to perform interventions on flammable refrigerants. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
-
Page 9: Manufacturer
NOMINAL POWER (NORMAL OPERATION) POWER (DEFROSTING) MINIMUM PRESSURE MAXIMUM PRESSURE SAFETY CLASS RATED CURRENT CURRENT DURING DEFROSTING SHELF LOAD TANK LOAD TYPE OF COOLANT WEIGHT OF COOLANT GROSS VOLUME EXPANDING INSULATION AGENT WEEE MARK USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 10: Use
The limits indicated refer to a static and evenly distributed load. Therefore dynamic overloads due to violent loading operations are excluded, which must be prevented for safety reasons. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 11: Composition
Internal LED lighting Closure on operator side with manual self-winding / sliding blind Manually openable front glass (LX) Manually tiltable front glass (ST) Swivel casters with brakes Height adjustable feet Dust filter for condensing unit USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 12: Safety
It is strictly forbidden to conduct any electrical modification, in order to prevent additional unforeseen hazards and risks. FIRE DANGER In the event of a fire, immediately disconnect the master switch from the main power supply line. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 13: Explosive Atmosphere
, contamination of the product itself may occur; in this case, strictly follow the instructions for use of the appliance (remove the packaging damaged by exposure and clean using specific products). USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 14: Disposal Of Waste Material
Further information on the disposal of liquid coolant, oils and other substances is available on the safety data sheet corresponding to the substance itself. In order to dispose of foamed assemblies, remember that the polyurethane foams used are CFC, HFC and HCFC free. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 15: Installation
Standards in force), which guarantees complete disconnection in category III (3) over-voltage conditions and therefore protects the circuits against earth faults, overloads and short circuits. Do not route the electricity cable in passageways. ATTENTION Earthing is necessary and mandatory by law. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 16: Unpacking
All packaging materials are recyclable and should be disposed of in accordance with local regulations. All packaging materials are recyclable and should be disposed of in accordance with local regulations.Please destroy "plastic" bags to prevent them from becoming hazardous to children (suffocation). USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 17: Wall Mounting
After its positioning the equipment must be stabilised on the floor via the specific height-adjustable feet as indicated so that the weight does not push down on the wheels. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 18: Handling
After its positioning, the equipment must be stabilised on the floor acting on the specific feet that are adjustable in height so that the weight is not resting on the wheels. ATTENTION HANDLES It is essential to move the appliance by installing the dedicated handles supplied as indicated below. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 19: Maintenance
(electronic control unit - thermostat - etc.) REPLACEMENT OF POWER SUPPLY CABLE, PLUGS AND/OR ELECTRICAL SOCKETS ATTENTION After all maintenance it is mandatory to perform all electrical safety tests in accordance with the IEC EN 50106 Standard. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 20: Faults - Technical After-Sales Assistance
If the control unit is set up especially for the R290 refriger- ant, it must only be replaced with an original replacement from ISA. Replace the temperature probes only after check- ing which of the two is not operating efficiently. -
Page 21: Technical Specifications
TECHNICAL SPECIFICATIONS 120+50 170+50 1166 1496 1661 1826 2156 1661 2156 Length 1080 External Depth dimensions 1054 1356 Height Weight (net) USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 22: Combinable Ice Cream Tubs (Optional)
11.1 MODULAR ARRANGEMENT ICE CREAM CONTAINERS (OPTIONAL) USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 23: Technical Plans
11.2 TECHNICAL PLANS USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 24: Lighting
11.5 GLASS FRONT OPENING The front glass can be opened manually as indicated below. ATTENTION The front glass has limited front opening. Never force the opening beyond the permitted limit. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 25: Operator Side Opening / Closing
Open and close the slides manually without forcing and close them, making sure they are completely closed; incorrect closure negatively affects the performance of the equipment and can result in the excessive accumulation of ice on the internal walls. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 26: Control Panel
The appliance starts automatically. ATTENTION The electronic control board is installed already programmed. Any changes to the control board settings can be carried out exclusively by qualified technical personnel. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 27: User Interface Xr44Ch
If a key is pressed for more than 3 seconds, the word "POF" appears. LOCK KEYBOARD Press and hold the keys for a few seconds until the word "POn" appears. To enter the programming function. To exit the programming function. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... - Page 28 • Delayed fan start-up in progress. Temperature alarm Unit of measurement Programming Fans active Delayed activation in progress Energy saving in progress Continuous cycle in progress Auxiliary relay active Fans stopped by key USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
- Page 29 Press the key for at least 2 seconds; the set-point will be displayed and the °C LED will start to flash. To change the value, use the UP and DOWN ARROW KEYS. To save the new set-point, press the SET button, or wait 15 seconds to quit programming mode. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
-
Page 30: 12.1.1 List Of Alarms
Faulty temperature probe Faulty first evaporator probe Faulty second evaporator probe High temperature alarm Low temperature alarm External alarm External alarm (i1F=bAL) Pressure switch alarm (i1F=PAL) Instrument in stand-by Door open Keyboard release Keyboard locked USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 31: Cleaning
Proceed to also clean and disinfect the collection tray. Fit the accessories that were removed (step 3). Turn on the equipment and allow the counter to cool until it reaches the desired temperature before reintroducing foods. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 32: Condenser Unit (Removable)
Remove the condensing unit as shown. Clean the condensing unit using a dedicated soft bristle brush and a vacuum cleaner; carry out the operation taking care not to bend the condensing unit springs. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 33: Filter
(e.g. high humidity, low ambient temperature, presence of dust, etc.) to avoid incorrect and complete evaporation of the water and / or the presence of unpleasant odours. Disinfect the tray with suitable products. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... -
Page 34: Prolonged Appliance Switch-Off
The equipment, whether equipped with its packaging or not, must be stored with care in the warehouse or in an area protected from the elements, atmospheric agents and away from direct sunlight, at a temperature of between 0 and +40 °C. USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037... - Page 35 ATTACHMENT WIRING DIAGRAM - 412100955000 USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
- Page 36 ATTACHMENT WIRING DIAGRAM - 412100956000 USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
- Page 37 ATTACHMENT ASSEMBLY OF PORTIONER WASHER (OPTIONAL) DISCHARGE WATER CONNECTION USE AND MAINTENANCE MANUAL MILLENNIUM MY2019 428001137037...
