SEAL KIT REPLACEMENT
Series G, H & J
Part Number KSH123
(For Disposer Models 75-750)
MODEL
75
75
75
100
100
100
150
150
150
200
200
200
300
500
750
These instructions are designed to assist in the rebuilding of Salvajor Disposers.
Not all parts in this kit will be identical matches to the parts removed.
The changes made are part of our ongoing commitment to quality,
increased longevity and durability of Salvajor Disposers.
All repairs should be made according to local codes and by a qualified technician.
Manufacturers of Commercial Food Waste Solutions - Since 1944
STARTING SERIAL NUMBER
VOLTAGE
115/230
208
208-230/460
115/230
208
208-230/460
115/230
208
208-230/460
115/230
208
208-230/460
208-230/460
208-230/460
208-230/460
PHASE
SERIAL NO.
1
72139
1
71135
3
73142
1
9318
1
3709
3
8401
1
152115
1
151144
3
153322
1
6169
1
3698
3
16441
3
11850
3
8472
3
5100
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Salvajor G Series
Summary of Contents for Salvajor G Series
- Page 1 8472 208-230/460 5100 These instructions are designed to assist in the rebuilding of Salvajor Disposers. Not all parts in this kit will be identical matches to the parts removed. The changes made are part of our ongoing commitment to quality, increased longevity and durability of Salvajor Disposers.
- Page 2 Disposer Disassembly Step 1 SHUT OFF POWER TO THE DISPOSER CONTROL and remove disposer from service. Remove the top housing by removing the eight top housing bolts. Remove the center gasket located on the top of the cutters. Note: For easier removal, the top housing can be TOP HOUSING ASSEMBLY left attached to the sink, remove the eight bolts so that only the disposer bottom comes off.
- Page 3 Seal Kit Installation Step 1 With disposer housing upright, press the bottom varilip seal ( S67350 ) , open side up, into the bottom of the bearing pocket. The upper lip of the bottom varilip seal should be flush with the bottom of the bearing pocket. Step 2 Place the tolerance ring ( ANL79X15S ) into the bearing pocket and push out against the outer wall.
- Page 4 Place the center gasket ( 996045 ) and remove center of gasket so that the inside diameter matches shredder. Place top housing on motor housing and secure with the eight motor housing bolts. 4530 East 75th Terrace Kansas City, MO 64132-2081, USA Toll Free: 1.888.725.8256 Fax: 1.800.832.9373 Printed in USA www.salvajor.com service@salvajor.com Form No.SKR (04-18)
