TroughVeyor
Trough Conveying and Food Waste Disposing System
TroughVeyor
Model TVL Shown
Left Hand Models: 300 - TVL, 500 - TVL
Right Hand Models: 300 - TVR, 500 - TVR
2
3
Fabricator Instructions & Attaching Disposer
4
Plumbing & Electrical
5
Operating Instructions & Troubleshooting
6
7
8
ALL INSTALLATIONS SHOULD BE MADE IN
ACCORDANCE WITH LOCAL AND NATIONAL
PLUMBING AND ELECTRICAL CODES.
FOR PRODUCT/WARRANTY REGISTRATION
•
Go to www.salvajor.com
•
Click on SUPPORT at the top of homepage
•
Click on PRODUCT REGISTRATION
4530 East 75th Terrace Kansas City, MO 64132-2081, USA
Toll Free: 1.888.725.8256
I
service@salvajor.com
Model TVL & TVR
®
TroughVeyors are available in either left
hand or right hand models to accomodate
trough water flow from right to left (TVL)
or left to right (TVR).
Manufacturers of Commercial Food Waste Solutions - Since 1944
I
Fax: 1.800.832.9373
www.salvajor.com
Disposer not
included in
NSF listing
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Salvajor TroughVeyor TVL Series
Summary of Contents for Salvajor TroughVeyor TVL Series
- Page 1 ACCORDANCE WITH LOCAL AND NATIONAL included in PLUMBING AND ELECTRICAL CODES. NSF listing FOR PRODUCT/WARRANTY REGISTRATION • Go to www.salvajor.com • Click on SUPPORT at the top of homepage • Click on PRODUCT REGISTRATION Manufacturers of Commercial Food Waste Solutions - Since 1944 4530 East 75th Terrace Kansas City, MO 64132-2081, USA Toll Free: 1.888.725.8256...
- Page 2 Additional Parts Contents Installation & Operating Manual Diffuser Gusher Head (Optional) Note: Drain piping not furnished...
- Page 3 8. If disposer drain orientation is incorrect loosen top clamp and rotate disposer to correct location. NOTE: It is important that the leg fit tightly between the disposer and the floor. STOP! If you have any questions about this installation call 1 - 888 - SALVAJOR for installation advice.
- Page 4 Plumbing WATER SUPPLY The Salvajor TroughVeyor is designed for easy plumbing installation. The solenoid valves are factory installed and are attached to an automatic water AIR GAP blender which will introduce water tempered to approximately 107˚ F. Plumb 3/4” lines from both hot and cold water supply sources and reduce to 1/2”...
- Page 5 Operating Instructions TO START: TO STOP: SAFETY RESERVOIR COVER SCREENS Close DRAIN VALVE. Press STOP button on the Position RESERVOIR SCREENS in bottom of tank. CONTROL PANEL. SALVAGE BASIN Lower SALVAGE BASIN over reservoir screens. Open DRAIN VALVE. Lower SAFETY COVER over disposer. Allow time for trough to drain.
- Page 6 How it Works Hot and cold water pass through a water blender set at 107˚ F. The blended water enters the tank at the rate of 5 gallons per minute. Cold water is introduced directly into the disposer grind chamber at the rate of 2 gallons per minute.
- Page 7 United States, Hawaii and Canada. of the original disposer assembly or system package. Accessories not manufactured by Salvajor are covered for parts only. Accessories For your nearest and parts sold separately are covered for parts and/or workmanship for 90 days from date of Factory Authorized Service Center: installation.
- Page 8 Buyer agrees that in no event shall seller’s liability to buyer and/or its customers ex- These Terms and Conditions shall govern the transaction by and between The Salvajor Company (herein referred to as the “Seller”) and the customer or person or entity purchas- tend to include incidental, consequential or punitive damages.
