INSTALLATION, USER AND SERVICING INSTRUCTIONS
THESE INSTRUCTIONS MUST REMAIN WITH THE USER
THIS APPLIANCE MEETS THE REQUIREMENTS OF THE EUROPEAN GAS DIRECTIVE
BEFORE INSTALLATION, CHECK THAT THE LOCAL DISTRIBUTION CONDITIONS, NATURE OF GAS & PRESSURE AND
October 2005
ACF526 Issue Technigas
KALIDO 73
Convector Gas Fire
MODEL NUMBERS: ACF526NG & ACF526P
ADJUSTMENT OF THE APPLIANCE ARE COMPATIBLE.
Avda Cañada del Cura, 29, Pol. Ind. de Levante
03187 Los Montesinos - Alicante.
Tel. 96 6721018 Fax. 96 6721023
Correo electrónico:
info@ambifuego.net
0120
Ambifuego
web:
www.ambifuego.net
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ambifuego KALIDO 73
Summary of Contents for Ambifuego KALIDO 73
- Page 1 KALIDO 73 Convector Gas Fire MODEL NUMBERS: ACF526NG & ACF526P INSTALLATION, USER AND SERVICING INSTRUCTIONS THESE INSTRUCTIONS MUST REMAIN WITH THE USER 0120 THIS APPLIANCE MEETS THE REQUIREMENTS OF THE EUROPEAN GAS DIRECTIVE BEFORE INSTALLATION, CHECK THAT THE LOCAL DISTRIBUTION CONDITIONS, NATURE OF GAS & PRESSURE AND ADJUSTMENT OF THE APPLIANCE ARE COMPATIBLE.
- Page 2 Installation & Service Record Please ensure that installer completes the installation record below INSTALLATION RECORD Appliance Supplied by: …………………………..Installation Date: ……………Serial No.: ….……... Installed By: …………..…...Reg. No.: …..…… Signed by Installer: ……………………………..… RECORD OF 1 SERVICE RECORD OF 2 SERVICE Serviced by: …………...
- Page 3 Important Notes – Please read before undertaking the installation This is not a “Do it yourself” product and it must be installed by a competent person. The fire has a ceramic Fire-bed arrangement; this contains Refractory Ceramic Fibres, which are man-made vitreous silicate fibres. Excessive exposure to these materials can cause irritation to eyes, skin and respiratory organs.
- Page 4 Five Piece Log Set. PPLIANCE DATA ACF526NG ACF7526P GAS TYPE NATURAL GAS PROPANE SUPPLY PRESSURE 20mb 37mb HEAT INPUT 6.8kW Net 6.6kW Net GAS RATE 0.72m/h 0.2m/h 512g/hr INJECTOR SIZE Ø Ø 2.1 mm 1.35mm GAS CONNECTION 8mm COMPRESSION ELECTRICAL 230V / 50Hz / 3A Burner Pressure 17,5mbr...
- Page 5 No restrictor plate or flue damper is permitted. Where a variable damper is fitted, this must be removed. A dedicated power flue kit is available for the appliance. The appropriate fitting instructions are supplied with the kit. Ventilation. Purpose made ventilation must be installed in accordance with local regulations. The appliance is designed for use with both natural gas and propane.
- Page 6 Remove the glass window by undoing the two nuts + two screws and lifting clear. Store it in a safe place. Remove the screw at the bottom of the fascia and pull the burner forward. Remove the four screws holding the control fascia in position. Remove the screw holding the circulation fan switch plate to the gas control valve.
- Page 7 molex connector. Fix into place with the four screws previously removed. Temporarily place the burner and mark the gas pipe for cutting. Trim the gas supply pipe to the mark. The end of the supply tube should finish 10 mm above the base. Prior to connecting the burner to the gas supply it is advisable to blow out the pipe to clear any dirt that may be present and which could cause a blockage in the control valve or pilot.
- Page 8 Closing the Glass Door. 1 Place the glass door in position over the studs on the heat exchanger making sure the joint in the rope seal lies along the lower edge. Secure in position with the 2 nuts and 2 screws.
- Page 9 To ensure that the release of fibres from these RCF articles is kept to a minimum, during installation and servicing we recommend that a HEPA filtered vacuum cleaner is used to remove any dust accumulated in and around the appliance before and after working on the appliance.
- Page 10 SERS UIDE Useful tips & recommendations Once your appliance has been fitted, the following recommendations are made to ensure you enjoy the best results from your purchase; The installation of this appliance must have been carried out by a qualified installer and in accordance with all local laws and regulations.
- Page 11 FIG. 7 Lighting the Appliance Open the louvered door at the base of the appliance under the glass door by pulling on the top edge at the sides. Push in and turn the control knob anti-clockwise to the PILOT position. Hold the knob in for several seconds to purge any air from the system.
- Page 12 Depress the control knob and turn clockwise to "OFF". The fire is now turned off completely. EMOTE ONTROL LECTRONIC GNITION YSTEM Igniting the Appliance. Simultaneously press the “(Spark) OFF” and “▲ or big flame” buttons of the receiver for ignition. (Fig-A).
- Page 13 Remote control with climate control system (depending the gas fire model) Display setting After having changed the batteries, press the symbols (OFF) and (▼) and select ºF/12 hours or ºC/24 hours. Hour setting For the selection of the hour you have to press (▼) and (▲). Once the screen light you can proceed to the hour (▲...
-
Page 14: Troubleshooting
During this period the Dealer undertakes to repair or replace the faulty parts. Such repairs shall not alter the date of expiry of the Guarantee. AMBIFUEGO RESERVES THE RIGHT TO MODIFY OR UPDATE ITS PRODUCTS OR SPECIFICATIONS WITHOUT PRIOR NOTICE, AS ITS...
