TECHNICAL INFORMATION
PIN: 0063CL1279
Gas Category
Gas
Supply Pressure (mbar)
Pilot Burner
Nominal Input (Gross kW)
Gas Rate (max. m³/hr)
Burner Pressure Mertik(Hot
mbar)
Burner Pressure Seagas(Hot
mbar)
Efficiency Class
Nox Class
Burner Injector
Gas Category
Gas
Supply Pressure (mbar)
Pilot Burner
Nominal Input (Gross kW)
Gas Rate (max. m³/hr)
Burner Pressure Mertik(Hot
mbar)
Burner Pressure Seagas(Hot
mbar)
Efficiency Class
Nox Class
Burner Injector
Inlet Pipe connection
Appliance mass
Electrical Supply
Natural
I2H
I2E
I2E+
G20
G20
G20/G25
20
20
20/25
SIT 0.977.113
8.8
8.8
8.8/8.0
0.838
0.838
0.838/0.886
12
12
12/16.3
10.8
10.8
10.8/14.7
2
4
650
LPG
I3B/P
I3+
I3B/P
G30/G31
G30/G31
G31
30
28-30/37
37
SIT 0.977.148
8.8
0.252
0.331
28.9
36.8
28.2
35.5
2
5
240
8mm Compression
5kg
230 V ~ 50Hz 0.085A
32
I2L
G25
25
8.0
0.838
16.3
14.7
USER, INSTALLATION AND SERVICING
Please read these instructions carefully before installation or use, and leave
with the customer for storage is a safe place for future reference.
This appliance has been designed and approved for use in other countries than shown on this
cover. To install in other countries it is essential to obtain the manual in the local translation.
Ambifuego
Avda. Cañada del Cura, 29
Poligono Industrial de Levante
03187 Los Montesinos (Alicante)
tel.: +34 96 672 1018
info@ambifuego.net www.ambifuego.net
KALIDO77
INSTRUCTIONS (GB & IE)
Contact Ambifuego for further information.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ambifuego KALIDO77
Summary of Contents for Ambifuego KALIDO77
- Page 1 This appliance has been designed and approved for use in other countries than shown on this Electrical Supply 230 V ~ 50Hz 0.085A cover. To install in other countries it is essential to obtain the manual in the local translation. Contact Ambifuego for further information.
-
Page 2: General Information
GENERAL INFORMATION TECHNICAL INFORMATION This manual covers the following appliances: Austria Kalido77 Belgium I3+ G30/G31@28-30/37mbar Switzerland I3+ G30/G31@28-30/37mbar Cyprus I3B/P G30/G31@30mbar Czech Republic I3+ G30/G31@28-30/37mbar Preliminary Notes Before Installation Germany The fire is designed to fit into a purpose made builder’s opening, and Denmark ... -
Page 3: Table Of Contents
TECHNICAL INFORMATION GENERAL INFORMATION Countries of Destination Contents The following tables gives detail of the Countries that these GENERAL INFORMATION Important Safety Notice . appliances are approved for use within. The tables following General Fitting Information immediately on give the technical characteristics of the appliances. Battery type (Remote Versions only) Natural USER INFORMATION . -
Page 4: General Information
GENERAL INFORMATION INSTALLER INFORMATION Troubleshooting MPORTANT AFETY OTICE This appliance has a ceramic Fire-bed arrangement; this contains Refractory Pilot sparks but does not light – Ceramic Fibres, which are man-made vitreous silicate fibres. Excessive No gas to fire, check isolators are open. exposure to these materials can cause irritation to eyes, skin and respiratory Pipework blockage, clean out. - Page 5 INSTALLER INFORMATION GENERAL INFORMATION Bearing in mind that the heat given off by this appliance may affect articles Spare Parts placed close to it, curtains should not be placed within 30cm. Burner, Natural XXxxxxx The appliance is not designed as a dryer. It is not therefore recommended Burner, LPG XXxxxxx that the appliance be used in such a manner.
-
Page 6: General Fitting Information
GENERAL INFORMATION INSTALLER INFORMATION General Fitting Information Servicing Instructions Inlet Pipe connection 8mm Compression Ensure that the fire is fully cold before attempting service. A Flame monitor Permanent Pilot suggested procedure for servicing is detailed below. Appliance mass 1. Lay out the dust sheet and tools. User control: Variable rotary control inc. -
Page 7: User Information
USER INFORMATION INSTALLER INFORMATION Operating The Appliance Briefing The Customer If the Flame Supervision Device is extinguished either All instructions must be handed to the user for safekeeping. Show intentionally or unintentionally, no attempt should be the customer how to light and control the fire. made to re-light the gas until at least 3 minutes have After commissioning the appliance, the customer should be elapsed. - Page 8 USER INFORMATION INSTALLER INFORMATION Turn the Left-hand control knob (B) anti-clockwise to the highest setting (large flame). Flue Spillage Monitoring System The appliance is now burning at its highest operating output. This fire is fitted with a flue spillage safety device (TTB). If the fire shuts down during use for no apparent reason then several things Running the appliance at lower setting may be suspected.
- Page 9 INSTALLER INFORMATION USER INFORMATION In the extent of a flue blockage or spillage, the monitoring system will operate and turn off the fire. If this occurs extinguish the appliance Arranging The Ceramic Fire-bed fully and re-light following the procedures as previously described. Only the ceramics supplied with this appliance are to be used.
- Page 10 USER INFORMATION INSTALLER INFORMATION The receiver unit should be located away under the fire, ensure that Mertik GV60 Fully Automatic System the receiver is located on its special bracket that will keep the receiver at a temperature below 60ºC, and that the customer knows Setting the Electronics Code where the receiver is for future battery replacement.
- Page 11 INSTALLER INFORMATION USER INFORMATION It is also possible to turn the main burner all the way down so that it is Micro Switch Installation effectively off, leaving only the pilot ignited. This procedure is to be followed for the installation of the Micro Switch required for the “Climate Control System”, the micro switch Extinguishing the Appliance Fully From any heat setting, press the “...
- Page 12 USER INFORMATION INSTALLER INFORMATION Press and hold the SET button until the P1 is displayed, and the Simple Version Up and Lower control only time flashes. Set the hour by pressing the (▲) and set the minutes by pressing the (▼) . This requires no external electrical power to operate.
-
Page 13: Seagas Manual Control (Single Control Knob)
INSTALLER INFORMATION USER INFORMATION Installing the Additional Controls (Remote Control) Seagas Manual Control Motor Installation Igniting the Pilot Light This procedure is to be followed for the installation of the Motor Unit, Turn the Control knob slightly anti- which must be fitted to use all remote control options, except the clockwise towards ignition... - Page 14 USER INFORMATION INSTALLER INFORMATION With the control knob at the highest setting, rotate in a clock-wise Testing and Commissioning direction towards the lower setting as required. The appliance is now operating at lower operating output. Turn on and test the gas supply up to the fire for any leaks, in accordance with current edition of BS6891.
-
Page 15: Site Requirements
INSTALLER INFORMATION INSTALLER INFORMATION Setting Pressure Site Requirements Remove the screw from the pressure test point. The fireplace opening should be inspected and repairs made where The pressure test point is situated on the side of the gas control. necessary. It will usually be necessary to remove any chair brick that may be in place. -
Page 16: Installing The Appliance
INSTALLER INFORMATION INSTALLER INFORMATION Installing the Appliance As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e. flock, blown vinyl and embossed paper) Notes: Ensure that the gas supply is isolated before commencing positioned too close to the appliance may discolour or scorch. installation of the appliance.
