nord NORDAC START Series User Manual

Motor starter
Hide thumbs
Table of Contents

Advertisement

Quick Links

BU 0135 – en
NORDAC
®
START (SK 135E / SK 175E)
Users Manual for Motor Starters

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NORDAC START Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for nord NORDAC START Series

Summary of Contents for nord NORDAC START Series

  • Page 1 BU 0135 – en NORDAC ® START (SK 135E / SK 175E) Users Manual for Motor Starters...

  • Page 2: Table 1: Version List

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Documentation Title: BU 0135 Order – No.: 6071302 Series: SK 1x5E Device series: SK 135E, SK 175E Device types: SK 1x5E-301-340-A SK 1x5E-751-340-A Version list Title, Order number Device Remarks software...
  • Page 3 Any editing or amendment or other utilisation of the document is prohibited. Publisher Getriebebau NORD GmbH & Co. KG Getriebebau-Nord-Straße 1 • 22941 Bargteheide, Germany • http://www.nord.com/ Fon +49 (0) 45 32 / 289-0 • Fax +49 (0) 45 32 / 289-2253 Member of the NORD DRIVESYSTEMS Group...
  • Page 4 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters BU 0135 en-4118...

  • Page 5: Table Of Contents

    Table of Contents Table of Contents General ................................. 9 Overview ............................9 Delivery ............................12 Scope of delivery..........................12 Safety, installation and operating instructions .................. 15 Warning and hazard information ...................... 20 1.5.1 Warning and hazard information on the product ..............20 1.5.2 Warning and hazard information in the document ..............
  • Page 6 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Factory settings ..........................62 Starting up the device ........................62 4.2.1 Connection ......................... 63 4.2.2 Configuration ........................63 4.2.2.1 Parametrisation 4.2.2.2 Potentiometers P1 to P4 4.2.2.3 DIP switches (S1) 4.2.2.4 Overview of switch-off modes 4.2.3 Commissioning examples ....................
  • Page 7 List of illustrations List of illustrations Figure 1: Device with internal SK CU4-......................... 11 Figure 2: Device with external SK CU4-........................ 11 Figure 3: Name plate ............................. 25 Figure 4: Example of motor size adaptation ......................31 Figure 5: Option locations ............................35 Figure 6: Connection example, power supply SK xU4-24V-…...
  • Page 8 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters List of tables Table 1: Version list ..............................2 Table 2: Additional features ........................... 10 Table 3: Warning and hazard information on the product ..................20 Table 4: Standards and approvals ......................... 21 Table 5: Standards and approvals for explosion hazard environments ..............

  • Page 9: General

    1 General 1 General The SK 1x5E series is based on the tried and tested NORD platform. The devices are characterised by their compact design and their optimum operational characteristics, and have uniform parametrisation. Due to dual phase control, not only a pure motor start, but also a soft start is possible. The phase control process was selected so that the resulting harmonic torques are kept as low as possible.

  • Page 10: Table 2: Additional Features

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters • Motor overload protection (I t triggering characteristic in accordance with EN 60947)  This means that a motor protection switch is not needed, merely a pre-fuse! •...

  • Page 11: Figure 1: Device With Internal Sk Cu4

    1 General Option modules Option modules are used to extend the functionality of the device. These options are available as an installation variant, the so-called SK CU4-… customer unit, and also as an attachment variant, the so-called SK TU4-… technology unit. As well as the mechanical differences, the installation and attachment variants also have some functional differences.

  • Page 12: Delivery

    Only use options and accessories which are explicitly intended for use with this device and are stated accordingly in this manual. Standard version: • IP55 version of device (optionally IP66, IP69K) • Operating instructions as PDF file on CD ROM including NORD CON, (PC parametrisation software) Available accessories: Designation Example Description...
  • Page 13 1 General Power supply for installation in the device for Internal power supplies generating the low control voltage (24 V DC). Model SK CU4-24V- …  Section 3.2.1 "Internal customer interfaces SK CU4-… (installation of modules)" Technology unit for attaching to the device or External power supplies alternatively for wall mounting (wall mounting kit required) for generating the low control voltage...
  • Page 14 Model SK CU4-FUSE- …  Section 3.2.1 "Internal customer interfaces SK CU4-… (installation of modules)" For commissioning, parametrisation and control NORD CON of the device. MS Windows ® - based www.nord.com Refer to...

  • Page 15: Safety, Installation And Operating Instructions

    1 General 1.4 Safety, installation and operating instructions Before working on or with the device, please read the following safety instructions extremely carefully. Please pay attention to all other information from the device manual. Non-compliance can result in serious or fatal injuries and damage to the device or its surroundings. These safety instructions must be kept in a safe place! 1.
  • Page 16 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2. Qualified experts For the purposes of these basic safety instructions, qualified personnel are persons who are familiar with the assembly, installation, commissioning and operation of this product and who have the relevant qualifications for their work.
  • Page 17 1 General Installation and assembly The installation and cooling of the device must be implemented according to the regulations in the corresponding documentation. The permissible mechanical and climatic ambient conditions (see technical data in the manual for the device) must be complied with. The device must be protected against impermissible loads.
  • Page 18 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Operation Where necessary, systems in which the devices are installed must be equipped with additional monitoring and protective equipment according to the applicable safety requirements (e.g. legislation concerning technical equipment, accident prevention regulations, etc.).
  • Page 19 Only original parts which are approved for the device and for operation in an explosion hazard area ATEX Zone 22 3D, EAC Ex must be used. • Repairs may only be carried out by Getriebebau NORD GmbH & Co. KG. BU 0135 en-4118...

  • Page 20: Warning And Hazard Information

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 1.5 Warning and hazard information Under certain circumstances, hazardous situations may occur in association with the frequency inverter. In order to give explicit warning of possibly hazardous situations, clear warning and hazard information can be found on the device and in the relevant documentation.

  • Page 21: Warning And Hazard Information In The Document

    1 General 1.5.2 Warning and hazard information in the document The warning and hazard information in this document are located at the beginning of the section which describes the action which may result in the corresponding hazards. The warning and hazard information is classified as follows according to the risk and the severity of the resulting injuries.

  • Page 22: Table 5: Standards And Approvals For Explosion Hazard Environments

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Devices which are configured and approved for use in explosion hazard environments ( Section 2.4 "Operation in potentially explosive environments ") comply with the following directives and standards. Applied Approval Directive...

  • Page 23: Ul And Csa Approval

    1 General 1.6.1 UL and CSA approval File No. E365221 Categorisation of protective devices approved by the UL according to United States Standards for the inverters described in this manual is listed below with essentially the original wording. The categorisation of individually relevant fuses or circuit breakers can be found in this manual under the heading “Electrical Data”.
  • Page 24 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Size valid description 1 - 2 generally valid “Suitable For Use On A Circuit Capable Of Delivering Not More Than 100 000 rms Symmetrical Amperes, 500 Volts Maximum” “When Protected by class RK5 Fuses or faster, rated ______ Amperes, and 500 Volts”, as listed in “Suitable For Use On A Circuit Capable Of Delivering Not More Than 100 000 rms Symmetrical Amperes, 500 Volts Maximum”...

  • Page 25: Type Code / Nomenclature

    1 General 1.7 Type code / nomenclature Unique type codes have been defined for the individual modules and devices. These provide individual details of the device type and its electrical data, protection class, fixing version and special versions. A differentiation is made according to the following groups: Motor starters Optional module Motor...

  • Page 26: Type Code Motor Starter

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 1.7.2 Type code Motor starter SK 175E-751-340-B (-ASI) (-C) (-xxx) Special version IP protection class: Standard = IP55, C = IP66, C-NSD = IP69K Device version: ASI – integrated AS Interface, PBR – integrated PROFIBUS DP Radio interference filter: O = none, B= Class B Mains voltage: x40 = 200 - 500 V...

  • Page 27: Type Code, Connection Unit For Technology Unit

    1 General 1.7.4 Type code, connection unit for technology unit SK TI4-TU-BUS (-C) IP protection class: Standard = IP55 C = "coated" IP66 Suitable NET = Mains option module (e.g. TU4-24V-…) device types: Bus option module (e.g. CANopen: TU4-CAO Group: TU = Technology unit SK TI4 = Connection unit SK TI4 Device series: (...) Options, only implemented if required.

  • Page 28: Version In Protection Class Ip55, Ip66, Ip69K

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 1.9 Version in protection class IP55, IP66, IP69K The SK 1x5E is available in IP55 (standard) or IP66, IP69K (optional). The additional modules are available in protection classes IP55 (standard) or IP66 (optional). A protection class that differs from the standard (IP66, IP69K) must always be specified in the order when ordering! There are no restrictions or differences to the scope of functionality in the protection classes that have...

  • Page 29: Assembly And Installation

    Information Device version IP6x IP6x-compliant devices must be installed by NORD, since special measures have to be implemented. IP6x components that are retrofitted on site cannot ensure that this protection class is provided. When delivered separately, the device includes the following components: •...

  • Page 30: Work Procedures For Motor Installation

    Fit the casing of the SK 1x5E to the terminal box base of the NORD motor using the existing screws and seal as well as the provided toothed contact washers. When doing this, align the casing so that the rounded side is facing the direction of the A bearing cover of the motor.

  • Page 31: Adapters For Different Motors

    Information about converting a drive to the device can be found in BU0320. SK 1x5E Adapter plate Gasket Motor, size 71 Figure 4: Example of motor size adaptation NORD motor sizes Attachment Attachment SK 1x5E size 1 SK 1x5E size 2 with adapter kit I Not possible Size 63 –...

  • Page 32: Dimensions, Sk 1X5E Mounted On Motor

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.1.1.2 Dimensions, SK 1x5E mounted on motor Size Housing dimensions SK 1x5E / Motor Weight of SK 1x5E without motor Motor ∅ g Approx. [kg] Size 71 177.5 Size 80 171.5...

  • Page 33: Wall Mounting

    2 Assembly and installation 2.1.2 Wall mounting As an alternative to wall mounting, the device can also be installed close to the motor using an optional wall-mounting kit. Wall mounting kit SK TI4-WMK-… (…1-K, …2-K, …1-NSD, 2-NSD) This wall-mounting kit provides a simple method for installing the device close to the motor. The SK TIE4-WMK-1-K and …2-K versions are made of plastic.
  • Page 34 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Wall mounting kit SK TIE4-WMK-… (…1-EX, …2-EX) These wall mounting kits are intended for use in explosion hazard environments ( Section 2.4 "Operation in potentially explosive environments "). They are made of stainless steel and are equally suitable for IP55 and IP66 applications.

  • Page 35: Installation Of Optional Modules

    2 Assembly and installation 2.2 Installation of optional modules Modules must not be inserted or removed unless the device is free of voltage. The slots may only be used for the intended modules. 2.2.1 Option locations on the device Figure 5: Option locations View from left View from right The various installation locations for the optional modules are displayed in the above-mentioned...

  • Page 36: Installation Of Internal Customer Unit Sk Cu4

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.2.2 Installation of internal customer unit SK CU4-… (installation) Information Installation location of customer unit Installation of the SK CU4-... customer unit separately from the device is not permitted. If must always be installed inside the device in the intended position (option location 1).

  • Page 37: Installation Of External Technology Units Sk Tu4

    2 Assembly and installation 2.2.3 Installation of external technology units SK TU4-… (attachment) The technology units SK TU4-…(-C) require a connection unit SK TI4-TU-…(-C). This is the only way to create a closed functional unit. This can be attached to the device or installed separately by means of the optional SK TIE4-WMK-TU wall-mounting kit.

  • Page 38: Electrical Connection

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.3 Electrical Connection WARNING Electric shock Dangerous voltages can be present at the mains input and the motor connection terminals even when the device is not in operation. •...

  • Page 39: Wiring Guidelines

    2 Assembly and installation 2.3.1 Wiring guidelines The soft starters have been developed for use in an industrial environment. In this environment, electromagnetic interference can affect the device. In general, correct installation ensures safe and problem-free operation. To meet the limiting values of the EMC directives, the following instructions should be complied with.

  • Page 40: Electrical Connection Of Power Unit

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.3.2 Electrical connection of power unit NOTICE EMC Interference to the environment This device produces high frequency interference, which may make additional suppression measures necessary in domestic environments ( Section 8.1 "Electromagnetic compatibility (EMC)"). The use of shielded motor cables is essential in order to maintain the specified radio interference suppression level.

  • Page 41: Motor Cable (U, V, W, Pe)

    2 Assembly and installation conditions stated in Section 8.1.3 "EMC of device". In this case, additional interference suppression measures must be provided. Size 2 devices can in principle be operated in TN/TT networks. The device must be appropriately configured for operation in an IT network. This configuration can also be carried out at a later date; however it can only be carried out by the manufacturer.

  • Page 42: Electrical Connection Of The Control Unit

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.3.3 Electrical connection of the control unit Connection data: Terminal bar X4, X5 Cable Ø * [mm²] 0.2 … 1.5 0.2 … 1.5 Ø cable * [mm²] 0.2 …...

  • Page 43: Control Terminal Details

    2 Assembly and installation 2.3.3.1 Control terminal details Labelling, function ASI+/-: Integrated AS interface PBR-A/B: Integrated PROFIBUS DP 24 V: 24 V DC control voltage Digital output GND: Reference potential for digital signals DIN: Digital input MB+/-: Control of electro-mechanical brake TF+/-: Motor thermistor (PTC) connection Connection depending on the configuration...
  • Page 44 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Meaning, Functions Description / Technical data Terminal Parameter Designation Meaning Function of factory setting Digital outputs Signalling of the operating statuses of the device 18 – 30 V DC, voltage level depending on Maximum load 200 mA, SK 175E…-ASI: 165 mA when using the input voltage level the yellow cable...
  • Page 45 ASI+ ASI- ASI- Communication Connection of device to various communication tools interface 24 VDC ± 20 % RS 232 (for connecting a PC (NORD CON)) 38400 Baud USS protocol Address 0 Bus signal reference potential RS232 TXD Data cable RS232...

  • Page 46: Power Supply Sk Xu4-24V

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.3.3.2 Power supply SK xU4-24V-… - Connection example 3~ 230/400V + PE L1 - L2/N - L3 L1 - L2/N 230/400V 230/400V Device 24V power supply SK 1x5E-... SK TU4-24V-...

  • Page 47: Operation In Potentially Explosive Environments

    2 Assembly and installation 2.4 Operation in potentially explosive environments WARNING Danger of explosion due to electricity Electric sparks may ignite an explosive atmosphere. • Do not open the device in an explosive atmosphere and do not remove any covers (e.g. diagnostic openings).

  • Page 48: Operation In Potentially Explosive Environments - Atex Zone 22 3D

    Only a specially modified device is permissible for operation in ATEX zone 22. This adaptation is only made at the NORD factory. In order to use the device in ATEX Zone 22, the diagnostic caps are replaced with aluminium / glass versions, among other things.

  • Page 49: Commissioning Information

    2 Assembly and installation ATEX zone 22 3D. This also includes connectors and switches that may also not be used in such an environment. Control and parametrisation units are basically not approved for operation in ATEX zone 22 3D. They may therefore only be used for commissioning or maintenance purposes and if it has been ensured that no explosive dust atmosphere exists.

  • Page 50: Eu Conformity Declaration - Atex

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.4.1.4 EU conformity declaration - ATEX BU 0135 en-4118...

  • Page 51: Operation In Potentially Explosive Environments - Eac Ex

    2 Assembly and installation 2.4.2 Operation in potentially explosive environments - EAC Ex All of the conditions which must be observed for operation of the frequency inverter in an explosion hazard environment according to EAC Ex are listed below. All of the conditions according to ...

  • Page 52: Further Information

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 2.4.2.2 Further Information Further information regarding explosion protection can be found in the following sections. Description  Section "Options for ATEX Zone 22, category 3D" 2.4.1.2 "Commissioning information" 2.4.1.3 2.4.2.3 EAC Ex certificate...

  • Page 53: Outdoor Installation

    2 Assembly and installation 2.5 Outdoor installation The device and the technology units (SK TU-...) can be installed outdoors under the following conditions: • IP66 version (incl. UV-resistant blank screw caps, see special measures, section 1.9 "Version in protection class IP55, IP66, IP69K"), •...

  • Page 54: Display, Operation And Options

    The SK 1x5E can be easily adapted to a wide range of requirements by using function-enhancing modules for display, control and parametrisation. Optionally available control devices from NORD or the free "NORDCON" PC software can be used for targeted adaptation of individual parameters. The right-hand diagnostic connection must be opened to access the diagnostic interface.

  • Page 55: Control And Parametrisation Units, Use

    3 Display, operation and options 3.1.1 Control and parametrisation units, use Access to the parameters of the SK 1x5E can take place either using the NORD CON software or with the aid of an optionally available SimpleBox or ParameterBox. Permanent parameter changes must be saved in the Flash memory of the device using parameter P550.
  • Page 56 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Connection to motor starter Remove right-hand diagnostics glass (transparent cable gland) of the RJ12 socket from the housing cover, alternatively remove housing cover (illustration on right) WARNING: Electric shock possible from touching conducting parts with device open! Set DIP switch to Master RS 485 at converter (SK TIE4-RS485-RS232)

  • Page 57: Optional Modules

    3 Display, operation and options 3.2 Optional modules 3.2.1 Internal customer interfaces SK CU4-… (installation of modules) Internal customer units allow the scope of functionality of the devices to be extended without changing the physical size thereof. The device provides an installation location for the installing an appropriate option.

  • Page 58: External Technology Units Sk Tu4

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 3.2.2 External technology units SK TU4-… (module attachment) External technology units allow the scope of functionality of the devices to be extended in a modular way. Depending on the type of module, different versions are available (differentiated according to IP protection class, with/without connector etc.).

  • Page 59: Plug Connectors

    3 Display, operation and options 3.2.3 plug connectors The use of optionally available plug connectors for power and control connections not only makes it possible to replace the drive unit with almost no loss of time in case of servicing, but also minimises the danger of installation errors when connecting the device.

  • Page 60: Plug Connectors For Control Connection

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Connector (selection) Type Data Designation Material no. Document Power input 500 V, 16 A SK TIE4-HANQ8-K-LE-MX 275 135 030 TI 275135030 Power input 500 V, 16 A SK TIE4-HAN10E-M1B-LE 275 135 070 TI 275135070...
  • Page 61 3 Display, operation and options Connector (selection) Type Version Designation Part Number Document Power supply Connector SK TIE4-M12-POW 275 274 507 TI 275274507 Sensors / actuators Socket SK TIE4-M12-INI 275 274 503 TI 275274503 Initiators and 24 V Connector SK TIE4-M12-CAO 275 274 516 TI 275274516 AS Interface...

  • Page 62: Commissioning

    4.1 Factory settings All motor starters supplied by Getriebebau NORD are pre-programmed with the default setting for standard applications with 4-pole standard motors (same voltage and power). The nominal current of the motor (see motor type plate, for example) can be set for the respective motor circuit using potentiometer P1, which has priority in the factory setting or the as-delivered condition.

  • Page 63: Connection

    4 Commissioning 4.2.1 Connection In order to provide basic operational capability, after the device has been attached to the motor or the wall mounting kit, the power and motor lines must be connected to the relevant terminals ( Section 2.3.2 "Electrical connection of power unit"). It is also essential for the device to be provided with a 24 V DC control voltage.

  • Page 64: Parametrisation

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 4.2.2.1 Parametrisation The use of a control and parametrisation unit (SK CSX-3H / SK PAR-3H) or the NORDCON software is required to adapt the parameters. The most important parameters are shown in the following, depending on the setting of parameter P130: Parameter group Parameter numbers...

  • Page 65: Potentiometers P1 To P4

    4 Commissioning 4.2.2.2 Potentiometers P1 to P4 Basic settings for the operation of the motor starter can be made using potentiometers P1 to P4. They are non-latching and each one has 10 scale values. The potentiometers are provided with non-linear characteristic curves at the software side.

  • Page 66: Dip Switches (S1)

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 4.2.2.3 DIP switches (S1) The basic functionality of the motor starter is set using DIP switch (S1). In the as-delivered condition, all four DIP switches are in position "0" ("OFF"). DIP switch (S1) DIP-No Switch-off mode 1 (factory setting)
  • Page 67 4 Commissioning DIP3/4: OFF/ON P108 = 1 Switch-off mode 2 1. P3 and P210 determine the starting voltage Switch on (starting torque) that is applied to the motor. (Set enable) 2. The brake opens. 3. P4 and P102 determine the duration for which the voltage is continuously increased until the full voltage (100 %) is reached.

  • Page 68: Commissioning Examples

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 4.2.3 Commissioning examples All SK 1x5E devices can basically be operated in the condition in which they are delivered. If an automatic start-up is required when "Mains on" takes place (depending on setting P130), either adapt parameter (P428) or set DIP switch S1-DIP1 = ON.

  • Page 69: As Interface (As-I)

    4 Commissioning 4.3 AS Interface (AS-i) This section is only relevant for device of type SK 175E-...-ASI. 4.3.1 The bus system General information The Actuator-Sensor-Interface (AS interface) is a bus system for the lower field bus level. It is fully defined in the AS interface Complete Specification and standardised as per EN 50295, IEC62026.

  • Page 70: Bus Structure And Topology

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Features • Electrically isolated bus interface • Status display (1 LED) • Configuration, optionally via – integrated potentiometers and DIP switches – or by means of parametrisation •...
  • Page 71 4 Commissioning Controller / automation unit AS interface power unit AS interface master AS interface yellow cable 24 V auxiliary supply, black cable 24 V power supply for auxiliary energy AS-i AS-i AS interface AS interface Slave Slave observe max. power load Sensors Actuators...

  • Page 72: Commissioning

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 4.3.4 Commissioning 4.3.4.1 Connection Connection of the AS interface cable (yellow) is made via terminals 85/85 of the terminal strip and can optionally be made to an appropriately labelled M12 flange plug connector (yellow) Details of control terminals (...

  • Page 73: Displays

    4 Commissioning 4.3.4.2 Displays The status of the AS interface is signalled by a multi- colour AS-i LED. AS-i LED Meaning • No AS interface voltage to the module • Connections not connected or exchanged green ON • Normal operation (AS interface active) red ON •...

  • Page 74: Addressing

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters The device is equipped with two additional digital inputs for connecting initiators. However, there are no optional outputs for connecting actuators which are operated directly via the BUS. The following connections are each provided for four reference data bits: Status BUS-IN...

  • Page 75: Certificate

    AS-i cable incorporated in the AS-i cable. External voltage supply 4.3.5 Certificate Currently available certificates can be found on the Internet at Link "www.nord.com" BU 0135 en-4118...

  • Page 76: Profibus Dp

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 4.4 PROFIBUS DP This section is only relevant for device of type SK 175E-...-PBR. 4.4.1 The bus system PLC's, PC's, operating devices and monitoring devices can all communicate via a uniform bus in serial bit mode using PROFIBUS DP.

  • Page 77: Commissioning

    4 Commissioning 4.4.3 Commissioning 4.4.3.1 Connection Connection of the PROFIBUS cable (lilac) is made via the terminal strip and can optionally be made to an appropriately labelled M12 flange plug contact (lilac) The connection to the terminal strip must not be made via a stub, i.e. the "incoming" and "outgoing" PROFIBUS cables must be connected in one terminal together using a double wire end sleeve, for example! Details of control terminals (...

  • Page 78: Configuration

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters LED BR Meaning No cyclic process data communication active, i.e. no data communication with slave. • PLC / Master in STOP or switched off • Missing 24 V DC voltage supply to motor starter •...

  • Page 79: Addressing

    4 Commissioning Status BUS-OUT Function (P434 [-01 … -02]) Status Bit 1 Bit 0 Bit 0 Fault (status bit 0) Error active Bit 1 Operation (status bit 1) Standby (motor stationary) Bit 2 Status of initiator 1 (DIN3 / C1) Warning (but motor running) Bit 3 Status of initiator 2 (DIN4 / C2)

  • Page 80: Parameter

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 5 Parameter WARNING Unexpected movement due to parameter changes Parameter changes become effective immediately. Dangerous situations can occur under certain conditions, even when the drive is stationary. Functions such as P428 "Automatic Start" or P420 "Digital inputs" or the "Release Brake"...

  • Page 81: Parameter Overview

    5 Parameter 5.1 Parameter overview Operating displays P000 Operating display P001 Selection of display value P003 Supervisor code Basic parameters P102 Acceleration time P103 Run time P107 Brake reaction time P108 Switch-off mode P114 Brake delay off P130 Parameter source P131 Phase control mode Motor data P203 Rated motor current...

  • Page 82: Description Of Parameters

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 5.2 Description of parameters P000 Operating display (parameter number) (parameter name) Setting range Display of typical display format (e.g. (bin = Other applicable List of other parameters that binary)) of possible setting range and number parameter(s): are directly associated...
  • Page 83 5 Parameter Array parameter display Some parameters have the option of displaying settings and views in several levels ("arrays"). After the parameter is selected, the array level is displayed and must then also be selected. If the SimpleBox SK CSX-3H is used, the array level is shown by _ - 0 1. With the ParameterBox SK PAR-3H (picture on right) the selection options for the array level appear at the top right of the display (Example: [01]).

  • Page 84: Operating Displays

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 5.2.1 Operating displays P000 Operating display Display range 0.01 … 9999 Other applicable parameter(s): P001 Description In the SimpleBox (SK CSX-3H) display, the operating value selected in parameter online is displayed.

  • Page 85: Basic Parameters

    5 Parameter 5.2.2 Basic parameters P102 Acceleration time Setting range 0.00 ... 25.50 s Other applicable parameter(s): P130, P216 Factory setting { 1.00 } Description The acceleration time is the time that the drive needs to reach the maximum speed after receiving the enable.
  • Page 86 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters P108 Switch-off mode Setting range 0 … 3 Other applicable parameter(s): P103, P107, P130, P210 Factory setting { 2 } Description This parameter determines the reaction of the motor starter on the removal of the enable.

  • Page 87: Motor Data

    5 Parameter P131 Phase control mode Setting range 0 … 1 Factory setting { 0 } Description Adaptation of the operating behaviour (running characteristics) of the motor Setting values Value Meaning Optimisation of phase control for an even current flow. This Current-optimised reduces the losses in the motor when starting up, but leads to an increased tendency to oscillate in the event of long ramps and an...

  • Page 88: Control Terminals

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 5.2.4 Control terminals P400 Function Analogue input Display range 0 … 6 Other applicable parameter(s): P102, P103, P130, P203, P210, P570 Arrays [-01] = Function Analogue input 1 (= value for P203 from potentiometer P1) [-02] = Function Analogue input 2...
  • Page 89 5 Parameter P420 Digital inputs Setting range 0 … 9 Other applicable parameter(s): P130, P428 Arrays [-01] = Digital input 1 (= value for digital input DIN1) [-02] = Digital input 2 (= value for digital input DIN2) [-03] = PTC input (= value for PTC input TF) [-04] =...
  • Page 90 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters P428 Automatic starting Setting range 0 … 1 Other applicable parameter(s): P130, P428 Factory setting { 0 } Description Decision as to whether the motor starter should react to an enable signal. Note As long as parameter P130=0 is set, the automatic start-up is determined via DIP switch S1-DIP1.
  • Page 91 5 Parameter P499 Function DIP switch Display range 0 … 6 Other applicable parameter(s): P108, P130, P428, P570 Arrays [-01] = Function DIP switch 1 (= value for P428) [-02] = Function DIP switch 2 (= value for P581) [-03] = Function DIP switch 3 (= value for P108 (bit 0)) [-04] =...

  • Page 92: Additional Parameters

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 5.2.5 Additional parameters P523 Factory setting Setting range 0 … 1 Other applicable parameter(s): P550 Factory setting { 0 } Description Reset all motor start parameters to the factory settings. Note The setting is not permanent until the values from the RAM have been transferred to the Flash memory (see P550).
  • Page 93 5 Parameter P538 Mains voltage Monitoring Setting range 0 … 3 Other applicable parameter(s): P108, P427 Factory setting { 3 } Description Mains voltage monitoring – Selection of variant of mains monitoring (terminals L1-L2-L3) by the device. Note For reliable operation of the device, the power supply must meet a certain quality. If there is a brief interruption of a phase or the voltage supply exceeds a particular limit value, the device outputs an error.
  • Page 94 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters P570 Locking time Setting range 0 … 25.50 s Other applicable parameter(s): P102, P103, P108, P130 Factory setting { 0.50 } Description The locking time determines the period of time during which the motor is not powered after the end of the run-down time and before the acceleration time started in the event of a change of rotating direction (reversing).

  • Page 95: Information

    5 Parameter 5.2.6 Information P700 Current operating status Display range 0.0 … 25.4 Arrays [-01] = Current error Current active error message (not acknowledged) [-02] = Current warning Current existing warning [-03] = Reason for switch-on Current existing reason for an active switch-on block block Description Display of current messages about operating status...
  • Page 96 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters P716 Current frequency Display range - 70 … + 70 Hz Description Display of current output frequency Note The value is calculated from the mains frequency and the selected direction of rotation when enabling takes place.
  • Page 97 5 Parameter P728 Present Mains voltage Display range 0 … 1000 V Description Display of current supply voltage present at the input terminals P732 Phase U current Display range 0.0 … 999.9 A Description Display of currently measured voltage of phase U Note Because of the measuring procedure, the value of P719 can deviate in spite of symmetrical output currents.
  • Page 98 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters P741 Bus Out process data Display range 0000 … FFFF -32768 … + 32767 (hex) (dec) Arrays [-01] = Bus status word = Status word [-02] = Bus - Actual value 1 Error number in high byte, warning number in low byte [-03] =...
  • Page 99 5 Parameter P763 Phase V voltage Display range 0 … 500 V Description Display of current voltage of phase V Note The value of P722 can differ because of the measuring procedure, in spite of having symmetrical output voltages. P764 Phase W voltage Display range 0 …...

  • Page 100: Operating Status Messages

    If the device is in the status "Not Ready" or "Start Disabled", the reason for this is indicated in the third array element of parameter (P700). Display is only possible with the NORD CON software or the ParameterBox. Warning messages  (P700 [-02]) Warning messages are generated as soon as a defined limit is reached.

  • Page 101: Diagnostic Leds On Device

    6 Operating status messages parameter P701. Further information on inverter status at the time that the error occurs can be found in parameters P702 to P706 / P799. If the cause of the error is no longer present, the error display in the SimpleBox flashes and the error can be acknowledged with the Enter key.

  • Page 102: Messages

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 6.3 Messages Error messages Display in the SimpleBox / ControlBox Fault Cause Text in the ParameterBox • Remedy Group Details in P700 [-01] / P701 E002 Overtemp. Motor PTC Motor temperature sensor (PTC) has triggered "Overtemperature motor •...
  • Page 103 6 Operating status messages 21.2 ADU error "Overrun" 21.3 PMI error "Access Error" 21.4 Userstack overflow Warning messages Display in the SimpleBox / Warning Cause ControlBox Text in the ParameterBox • Remedy Group Details in P700 [-02] C002 Overtemp. Motor PTC Warning from motor temperature sensor (triggering threshold reached) "Overtemperature motor...

  • Page 104: Faq Operational Problems

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 6.4 FAQ operational problems Fault Possible cause Remedy • Check connections and supply Device will not start (all LEDs • No mains voltage or wrong mains cables off) voltage •...

  • Page 105: Technical Data

    7 Technical data 7 Technical data 7.1 General data Motor starter Function Specification Motor overload monitoring 150 % for 120 s … 360 s, depending on shut-off class (P535) Motor starter efficiency > 98 % Insulation resistance > 5 MΩ Operating / ambient temperature -25°C …...

  • Page 106: Electrical Data

    The measurement series were made at the rated speed with 4-pole NORD standard motors The following factors have a particular influence on the determined limiting values: Wall-mounting •...

  • Page 107: Electrical Data

    7 Technical data 7.2.1 Electrical data Device type SK 1x5E… -301-340- -751-340- Size 400 V 3.0 kW 7.5 kW Nominal motor power (4-pole standard motor) 480 V 4 hp 10 hp 3 AC 200 V … 500 V ± 10 %, 47 … 63 Hz Mains voltage 7.5 A 16.0 A...

  • Page 108: Additional Information

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 8 Additional information 8.1 Electromagnetic compatibility (EMC) If the device is installed according to the recommendations in this manual, it meets all EMC directive requirements, as per the EMC product standard EN 60947-4-2. 8.1.1 General Provisions As of July 2007, all electrical equipment which has an intrinsic, independent function and which is sold as an individual unit for end users, must comply with Directive 2004/108/EEC (formerly Directive...

  • Page 109: Emc Of Device

    8 Additional information Limit class in accordance with EN 55011 Operation permissible in 1. Environment (living environment) 2. Environment (industrial environment) Note required in accordance with EN-61800-3 Sales channel Generally available Limited availability EMC situation No requirements Installation and start-up by EMC expert Device used neither as a plug-in device nor in moving equipment "The drive system is not intended for use in a public low-voltage network that feeds residential areas".

  • Page 110: Table 15: Overview According To Product Standard En 60947-4-2

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters EMC overview of standards that are used in accordance with EN 60947-4-2 as checking and measuring procedures: Interference emission Cable-related emission EN 55011 (interference voltage) Radiated emission EN 55011 (interference field strength) Interference immunity...

  • Page 111: Eu Declaration Of Conformity

    8 Additional information 8.1.4 EU Declaration of Conformity BU 0135 en-4118...

  • Page 112: Operation On The Fi Circuit Breaker

    NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters 8.2 Operation on the FI circuit breaker Leakage current of ≤ 20 mA is expected during operation of the motor starter. It is suitable for operation on the FI circuit breakers for the protection of persons. BU 0135 en-4118...

  • Page 113: Maintenance And Servicing Information

    9 Maintenance and servicing information 9.1 Maintenance Instructions NORD motor starts are maintenance free during proper operation ( Section 7 "Technical data"). Dusty environments If the device is being used in a dusty environment, the cooling surfaces should be regularly cleaned with compressed air.

  • Page 114: Service Notes

    (P707) and the series number (name plate) at hand. The device must be sent to the following address if it needs repairing: NORD Electronic DRIVESYSTEMS GmbH Tjüchkampstraße 37 D-26605 Aurich, Germany Please remove all non-original parts from the device.

  • Page 115: Abbreviations

    Parameter number (PROFIBUS) I / O Input /Output Supervisor Parameter, P003 S1 … Electromagnetic compatibility DIP switch FI (switch) Leakage current circuit breaker Software version, P707 Ground reference potential Technical information / Data sheet (Data sheet for NORD accessories) BU 0135 en-4118...
  • Page 116 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Key word index Current operating status (P700) ....95 Current voltage (P722)........96 Acceleration time (P102) ....... 85 Customer unit ..........57 Address............114 Apparent power (P726) ......... 96 Array parameters ...........
  • Page 117 Key word index Phase control mode (P131) ......87 Phase sequence detection (P581) ....94 General data Phase U current (P732) ........ 97 Motor starter ..........105 Phase U voltage (P762) ........ 98 Phase V current (P733) ........ 97 i²t motor (P535) ..........92 Phase V voltage (P673) ........
  • Page 118 NORDAC START (SK 135E / SK 175E) – Users Manual for Motor Starters Total currents ..........42 Type code ............25 Wall-mounting ..........33 Warning messages ........103 Warnings ........100, 101, 103 UL/CSA Approval ........106 Weight ............32 Wiring guidelines ...........
  • Page 119 Key word index BU 0135 en-4118...

This manual is also suitable for:

Nordac start sk135eNordac start sk175eNordac start sk 135e seriesNordac start sk 175e seriesNordac start sk 175e-asi seriesNordac start sk 175e-pbr series ... Show all

Table of Contents
