Eurospec XIA5002SV Installation Instructions

Push pad emergency exit device
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Installation Instructions
Push Pad Emergency Exit Device EN179
Door – Maximum specification of door on which this product should be fitted.
•
Maximum weight of door = 200kg
• Maximum width of door = 1300mm
This product is designed for peoples safety and complies with EN179. DO NOT modify the product in
anyway other than those outlined in these instructions.
This product is non handed and can be fitted on both left and right handed single doors
IMPORTANT INFORMATION
PLEASE READ THESE INSTRUCTIONS CAREFULLY
For internal use only.
1
Push Pad Rev.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIA5002SV and is the answer not in the manual?

Questions and answers

Related Manuals for Eurospec XIA5002SV

Summary of Contents for Eurospec XIA5002SV

  • Page 1 Installation Instructions Push Pad Emergency Exit Device EN179 IMPORTANT INFORMATION PLEASE READ THESE INSTRUCTIONS CAREFULLY Door – Maximum specification of door on which this product should be fitted. • Maximum weight of door = 200kg • Maximum width of door = 1300mm This product is designed for peoples safety and complies with EN179.
  • Page 2 Installation 1. At a height of 1000mm +/- 100mm, mark the door at a measurement of 55mm from the edge of the door frame. This distance is the centre line of the spindle hole. See Diagrams 1 & 3. 2. Detach Mounting Plate from Push Pad unit by using allen key provided to remove the two screws. See diagram 2.
  • Page 3 Installation – (Continued) Note: If External Locking Attachment is not required, please proceed to step 5. 4. Identify correct door handing, See Diagram 4 and prepare spindle rotation as follows: Right Hand door, rotate follower fully “clockwise”. Left Hand door, rotate follower fully “anti-clockwise”. Diagram 4 5.
  • Page 4 Ensure all fixing screws are secure and that the striker is clean and free from obstruction. Check Push Pad operates correctly. PLEASE LEAVE THESE INSTRUCTIONS WITH THE END USER Stancliffe Street Mill Hill Blackburn BB2 2QR Tel: +44 (0) 1254 274100 Fax: +44 (0) 1254 274111 www.eurospec.co.uk Push Pad Rev.7...
