Model# FR02-B
Item#: ET-F-016
ASSEMBLY INSTRUCTIONS AND SAFETY GUIDE
1008/16
Type of gas: Butane
Nominal heat input: 16.5 kW
Gas consumption: (G30)-1201 g/h
BE, BG, CY, CZ, DK, EE, FI, FR, GB, GR, HR, HU, IT, LT, LU, LV, MT, NL, NO, RO, SE, SI, SK, TR:
Cat. I
= Butane, Propane and their mixtures at 30mbar, Injector: 2.09mm
3B/P(30)
"Only nationally approved hose and regulator corresponding to the appliance category and pressure must
be used "
This manual is for: GB
PIN.: 1008CR2974
