- Page 1 Operating and Installation Instructions for Wood Burning Stoves with water heat exchanger ORANIER Polar Neo Aqua I 292 9929 000 · 1069...
-
Page 2: Table Of Contents
Flue tube connection and Maintenance schedule setup of the wood burning stove Connections Connection of the flue tube ORANIER factory guarantee Setup of the wood burning stove Dimensions Technical data Energy label and product data sheet Operating the wood burning stove... -
Page 3: Welcome
Dear Customer, ORANIER Heiztechnik GmbH Oranier Straße 1 Congratulations on the purchase of this ORANIER 35708 Haiger / Sechshelden wood burning stove! Telefon: +49 (0) 27 71 / 2630-0 ORANIER wood burning stoves offer you sophisti- Kundenservice / Ersatzteile cated and reliable technology, functionality and an email customer attractive design. - Page 4 This fireplace must not be altered in any way! The purchaser and operator of this wood burning stove is obliged to learn how to handle it correctly by reading these instructions. Our guarantee of fault-free function shall im- mediately be rendered void if the following guidelines and instructions are not complied with.
-
Page 5: Description
1. Description 2.1 External combustion air supply If necessary, the wood burning stove can The wood burning stove is made of a welded be equipped with a connection for an ex- steel construction. The central section features the firebox, which is lined with safety panels. ternal combustion air supply (See Fig. -
Page 6: Design
3. Flue tube connection and In every case, care must be taken to ensure setup of the wood burning stove that the combustion air requirement of around 30 m /h is met at a feed pressure of 4 Pa. 3.1 Connection of the flue tube When not in use, all air slides should be kept closed to ensure that no cold air is able to cir- Your wood burning stove is connected up-... -
Page 7: Setup Of The Wood Burning Stove
3.2 Setup of the wood burning stove Caution! For your own safety, you Fire safety regulations according to FeuVo must comply with the mini- (minimum distances; see Fig. 2) must be com- mum distances specified to plied with when setting up the appliance. installation walls, flammable FeuVo ("Ordinance on Firing Installations and furnishings and objects and... -
Page 8: Technical Data
4. Technical data Exhaust mass flow: 8,1 g/s Wood burning stove type: POLAR NEO AQUA I Design: Feed pressure for NHO: 12,0 Pa Nominal heat output: 10,0 kW Exhaust temperature at outlet: 227 °C Water heat output: 6,0 kW Approved fuels: - Firewood <... -
Page 9: Operating The Wood Burning Stove
5. Operating the wood burning stove Caution! The burning of fuel releases heat energy, which 5.1 General leads significant safety instructions heating of surfaces, firebox doors, To ensure the safe operation of your wood operating handles, viewing panes and burning stove, it is essential to follow the flues. -
Page 10: Suitable Fuels
Secondary air regulator 5.4 Commissioning The secondary air regulator is located at the - Adjust fuel selector. Open secondary air re- back of the stove: gulator to maximum: - Ensure that any throttle cap installed in the closed open connecting piece is also fully opened. - Place 2-3 firelighters far back on the grid and layer kindling and small shavings of wood over them. -
Page 11: Heating With Lignite Briquettes
5.5 Heating with lignite briquettes 5.7 Maximum feed quantities and air ad- justment with nominal heat output (NHO) - First create a base pile of embers with wood. - Then place 2-3 lignite briquettes cross-ways For wood fuel: in the firebox. The third briquette should lie Fuel quantity: 3-4 logs on top. -
Page 12: Emptying Ashes
5.8 Emptying ashes 5.10 Chimney fire Ensure that the ash box is emptied promptly so If an unsuitable fuel or a fuel that is too wet is that the cinder cones do not adhere too tightly used, deposits in the chimney can ignite, caus- ing a chimney fire. -
Page 13: Connection Of The Water Circuit To The Heating System
6. Connection of the water circuit to the heating system On houses with controlled living room ventila- Caution! tion, a short piece of connecting pipe, which is The heat exchanger must available as an accessory for connecting an only be connected to a hea- external combustion air supply, may need to ting system by an authorised be retrofitted. -
Page 14: Connection Of The Supply And Return Pipe
6.1 Connection of the supply and return Caution! pipe Solid-fuel boilers must be designed in accordance with Connect the supply and return pipe to the hea- EN 12828 and feature a sa- ting system in accordance with the planned fety heat exchanger with a system diagram. -
Page 15: Installation Instructions
6.3 Installation instructions Every fireplace with a water heat exchanger AQUAload must be equipped with a return flow boost. with... This device prevents cold return water from cooling the firing chamber to the dew point range (formation of condensation!). Performance-impairing tar and soot depo- sits on the heating surfaces are therefore avoided. -
Page 16: Connection Diagram
7. Connection diagram Safety heat exchanger AQUAload with integrated pump and return flow boost 55°C Safety valve 2,5 bar Possible uses: Water storage Return-supply on an existing oil-/ gas-boiler Expansion tank Buffer store (min. 300 l) Radiator, underfloor heating... -
Page 17: Maintenance Schedule
8. Maintenance schedule The heater should be checked and ser- viced at least once a year. At least the following checks should be carried out: 1. Check of the flues for damage and unimpe- ded airflow. 2. Check of all gaskets in the door area. 3. -
Page 18: Connections
Connections Flue tube opening Bleeding valve D150 mm Immersion pocket for differential regu- lator sensor Immersion pocket for TAS sensor Secondary air regulator Connection for external combustion air supply D100 mm Supply pipe (G 3/4“) Return pipe (G 3/4“) TAS Inlet TAS outlet (G 3/4“) (G 3/4“) -
Page 19: Oranier Factory Guarantee
This also includes defects to the exhaust gas pipes plyt to the respective country company. (stove pipe, inadequate or excessive chimney draught) 1. The ORANIER factory guarantee runs for 24 months and any incorrectly carried-out repair work, especially the undertaking of modifications to the appliance, its fit- and starts from the moment of handover, which must be tings and its supply cables or pipelines. -
Page 20: Dimensions
Dimensions... -
Page 21: Energy Label And Product Data Sheet
Produktdatenblatt gemäß (EU) 2015/1186 Anhang IV Product data sheet in accordance to (EU) 2015/1186 Annex IV/ Label énergétique et fiche produit selon les normes (EU) 2015/1186 Annexe IV Warenzeichen ORANIER Heiztechnik GmbH / trademark/ marque Modell / model/ modèle Polar Neo Aqua... -
Page 22: Declaration Of Performance
Notifizierte Prüfstelle: 1417/ TÜV SÜD KERMI Kft. Notified laboratory: 1417/ TÜV SÜD KERMI Kft. Organisme notifié : 1417/ TÜV SÜD KERMI Kft. 8. Leistungserklärung Declaration of performance Declaration of performance Performances déclarées Harmonisierte technische Spezifikationen EN 13240:2001/ A2:2004/ AC:2007 harmonized technical specification Norme technique harmonisée Wesentliche Merkmale/ main features/ Leistung/ performance/ Rendement... -
Page 23: Ce Mark
CE - Kennzeichnung (CE marking) (Marquage CE) Der Hersteller ORANIER Heiztechnik GmbH Werk 10 (The manufacturer) Sechsheldener Str. 122 (Le fabricant) 35708 Haiger erklärt in alleiniger Verantwortung, dass das Produkt „Raumheizer für feste Brennstoffe“ mit der Handelsbezeichnung (declares under our responsibility that the produkt “Room heater by solid fuel“ with trade name ) (certifie par la présente que le produit «... - Page 24 Schwarz / Kachel grappa 7615 80 A04 7615 87 A04 Gray Iron / Ceramic namib Black / Ceramic grappa Gris fonte / Céramique namib Noir / Céramique grappa Oranier Heiztechnik GmbH · Oranier Straße 1 · 35708 Haiger / Sechshelden...
