- Page 1 Operating and Installation Instructions for Wood Burning Stoves ORANIER Rota Tre I 292 1037 000 · 1087...
-
Page 2: Table Of Contents
NHO Emptying ashes Cleaning and maintenance 5.10 Chimney fire Room heating capacity (DIN 18893) ORANIER factory guarantee Declaration of performance CE mark Appliance parameters* Rear cover *Please note: When ordering spare parts and in the event of any service call-outs, please al- ways specify the model number of your appliance. -
Page 3: Welcome
A polite request ... Dear Customer, To enable our customer service team to organise Congratulations on the purchase of this ORANIER repairs and provide the necessary spare parts with wood burning stove! complete care and precision, we will need the fol-... - Page 4 This fireplace must not be altered in any way! The purchaser and operator of this wood burning stove is obliged to learn how to handle it correctly by reading these instructions. Our guarantee of fault-free function shall immediately be rendered void if the following guidelines and instructions are not complied with.
-
Page 5: Description
1. Description Fig. 1 Upper flue tube opening The wood burning stove is made of a welded steel construction. The central section fea- tures the firebox, which is lined with safety panels. The ash box is located below a sturdy Rear flue cast iron trivet. -
Page 6: Design
2.2 Design 3. Flue tube connection and setup of the wood burning stove The wood burning stove series described in these instructions are of "Design 1". 3.1 Connection of the flue tube Wood burning stoves of this design have self-closing firebox doors powered by a spring Your wood burning stove can optionally be mechanism and are approved exclusively for connected upwards or to the rear. -
Page 7: Setup Of The Wood Burning Stove
3.2 Setup of the wood burning stove Caution! For your own safety, you Fire safety regulations according to Feu- must comply with the mini- Vo (minimum distances; see Fig. 2) must be mum distances specified to complied with when setting up the appliance. installation walls, flammable FeuVo ("Ordinance on Firing Installations and furnishings and objects and... -
Page 8: Technical Data
4. Technical data Wood burning stove type: Rota Tre I Exhaust mass flow: 4.5 g/s Design: Feed pressure for NHO: 12.0 Pa Nominal heat output: 5.0 kW Exhaust temperature at outlet: 255 °C Energy efficiency class: Approved fuels: - Firewood < 25% moisture... -
Page 9: Operating The Wood Burning Stove
5. Operating the wood burning stove Caution! The burning of fuel releases heat energy, which General leads significant safety instructions heating of surfaces, firebox doors, To ensure the safe operation of your wood operating handles, viewing panes and burning stove, it is essential to follow the flues. -
Page 10: Suitable Fuels
Suitable fuels Commissioning The wood burning stove is suitable for burn- - Open the primary and secondary air controls ing untreated firewood, wood briquettes and as far as they will go! Ensure that any throttle lignite briquettes. cap installed in the connecting piece is also Classic stove woods include beech and birch. -
Page 11: Heating With Lignite Briquettes
Heating with lignite briquettes Maximum feed quantities and air ad- justment with nominal heat output (NHO) - First create a base pile of embers with wood. For wood / wood briquette fuel: - Then place 2-3 lignite briquettes cross-ways in the firebox. The third briquette should lie Fuel quantity: 2-3 logs / piece on top. -
Page 12: Cleaning And Maintenance
Cleaning and maintenance Note: The surfaces of the stove should not be cleaned Caution! with "aggressive" cleaning The wood burning stove agents. Use only a clean, must only be cleaned when dry duster. it has fully cooled! 5.10 Chimney fire At least once a year, and more often if re- quired, the soot and ash deposits in the flue If an unsuitable fuel or a fuel that is too wet... -
Page 13: Oranier Factory Guarantee
(stove pipe, inadequate or excessive chimney draught) and any incorrectly carried-out repair work, especially 1. The ORANIER factory guarantee runs for 24 months the undertaking of modifications to the appliance, its and starts from the moment of handover, which must fittings and its supply cables or pipelines. -
Page 14: Declaration Of Performance
norme harmonisée : Notifizierte Prüfstelle: 1417/ TÜV SÜD KERMI Kft. Organisme notifié : 1417/ TÜV SÜD KERMI Kft. 8. Leistungserklärung Declaration of Performance Performances déclarées Harmonisierte technische Spezifikationen EN 13240:2005/ A2:2004/ AC:2007 Norme technique harmonisée Wesentliche Merkmale Leistung caractéristique principale Rendement Erfüllt / Satisfaisant Brandsicherheit... -
Page 15: Ce Mark
CE - Kennzeichnung (CE marking) (Marquage CE) Der Hersteller ORANIER Heiztechnik GmbH Werk 10 (The manufacturer) Sechsheldener Str. 122 (Le fabricant) 35708 Haiger erklärt in alleiniger Verantwortung, dass das Produkt „Raumheizer für feste Brennstoffe“ mit der Handelsbezeichnung (declares under our responsibility that the produkt “Room heater by solid fuel“ with trade name ) (certifie par la présente que le produit «... - Page 16 Black steel / Cover Limestone bianco Noir / Céramique pomme Acier noir / Plaque sup. Calcaire bianco Schwarz / Keramik grappa 4794 32 A03 Black / Ceramic grappa Noir / Céramique grappa GmbH · Oranier Straße 1 · 35708 Haiger / Sechshelden...
