coDe:1689
coDe:1690
manUfactUreD
to iso9001
Installation Instructions
1689
1690
EV-LEDFIRE-III-SM-B
contents
Welcome
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Self-test/ standard wiring/ central battery system
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
1. Welcome
Thank you for choosing this quality Ektor product.
This manual is intended to help you install this
product in a way that ensures the safety of yourself
and others. Whilst this Ektor product is designed
to be installed easily, we highly recommend you
take the time to read this manual thoroughly before
commencing installation. When installed correctly
and serviced regularly, this product will provide
hassle free operation for many years.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV-LEDFIRE-III-SM and is the answer not in the manual?

Questions and answers

Related Manuals for ektor EV-LEDFIRE-III-SM

Summary of Contents for ektor EV-LEDFIRE-III-SM

  • Page 1: Table Of Contents

    Compliance standards Technical support and troubleshooting 1. Welcome Thank you for choosing this quality Ektor product. This manual is intended to help you install this product in a way that ensures the safety of yourself and others. Whilst this Ektor product is designed...

  • Page 2: Overview

    SURFACE MOUNT LEDFIRE III EMERGENCY INSTALLATION INSTRUCTIONS 2. overvieW Ektor Generation III platform introduces you to a new era of emergency lighting control. With years in the making, the third generation platform builds on the Ektor product ranges’ increasing quality, reliability and performance.

  • Page 3: Installation

    4. installation The Ektor Surface Mount Ledfire III can be installed either by surface or rod mounting the product. To install the Surface Mount Ledfire III please follow the steps listed below: Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.

  • Page 4: Mounting Options

    SURFACE MOUNT LEDFIRE III EMERGENCY INSTALLATION INSTRUCTIONS 5. moUnting oPtions SURFACE MOUNT Remove the Surface Mount Ledfire III cover as shown in the installation instructions in section 4 (page 3) of this instruction manual. This will allow the mounting holes to become visible. Mount the Surface Mount Ledfire III by fastening screws securely to a flat surface.

  • Page 5: Terminal Block Wiring

    6. terminal BlocK Wiring Wiring schematic for the terminal block used with the Surface Mount Ledfire III is illustrated below. Figure 4: Wiring schematic DRAFT 7. maintaining yoUr sm leDire iii lUminaire WARNING The Surface Mount Ledfire III is connected to an unswitched active during normal operating conditions. When disconnected from the mains supply, the Surface Mount Ledfire III is powered by a LiFePO4 battery operated inverter.

  • Page 6: Battery Life

    AS/NZS 2293 or an equivalent standard can have a positive effect on the battery performance as long as 12 discharge cycles per year is not exceeded. 10. PoWer anD Battery cHarge The Ektor Generation III platform uses smart battery charging technology which reduces power consumption and increases battery life. Max charge voltage...

  • Page 7: Wireless Daughterboard

    11. Wireless DagHterBoarD The Surface Mount Ledfire III inverter supports an optional wireless daughterboard. The driver must be disconnected from mains and battery must be removed, before installing or changing any expansion module. More information and a list of other accessories can be found in the Wireless design and installation guide. The assembly for the Wireless daughterboard onto the inverter is shown below: Wireless daughterboard (6118)(optional) Surface Mount Ledfire III inverter (1204, 1207)

  • Page 8: Dali Wiring/ Central Battery System

    SURFACE MOUNT LEDFIRE III EMERGENCY INSTALLATION INSTRUCTIONS 13. DALI WIRING/ CENtRAL BAttERY SYStEM The Surface Mount Ledfire III inverter supports DALI out of the box, illustrated in the hardwiring diagram shown below. The inverter also supports central battery systems and can be monitored through DALI. When used as a central battery system the devices can be tested with DALI.

  • Page 9: Accessories List

    EV-WIFI-DAUG 6118 Easy commissioning module - DALI EV-ECM-DALI 5304 Easy commissioning module - EKTOR EV-ECM-EKTOR 5305 17. NON MAINtAINED/ MAINtAINED JUMPER DRAFT A user can select the mode of operation for the Surface Mount Ledfire III inverter. If the inverter is using a switch input this is disregarded and not used.

  • Page 10: Self-Test Indicator Leds

    SURFACE MOUNT LEDFIRE III EMERGENCY INSTALLATION INSTRUCTIONS 19. self-test inDicator leDs The table below shows the operation of the Surface Mount Ledfire III status indicators: INDICATOR DESCRIPTION YELLOW Device is performing a duration test 2sec ON / 2sec OFF Last duration test passed. The duration YELLOW was met when last run.

  • Page 11: Product Specifications

    21. ProDUct sPecifications SURFACE MOUNT LEDFIRE III 230mm DRAFT 53mm 230mm voltage (v) viewing distance 230~240V frequency (Hz) 50Hz mounting type Surface mounted max. ambient temp. 40°C Wiring Hard wired Battery type LiFePO4 class Battery voltage 6.4V Duration Dependant on jumper charging time 16 hours iP rating...

  • Page 12: Australian Emergency Classification

    If you choose to expose the Ektor emergency products to such harsh operating conditions, Evolt may not honour any warranty on the life of the batteries or the product enclosure. This Ektor emergency product is designed to undergo regular discharge tests but it is recommended that the intervals between consecutive tests are not less than two weeks.

  • Page 13: Testing Precautions

    26. ProBlem solving ProceDUre If you have installed and connected the Ektor Surface Mount Ledfire III as per the instructions contained within this manual and the product fails to work properly, please use the following table as a guide to fixing the problem before calling our office.

  • Page 14: Warranty Information

    Australian Competition and Consumer Act and other Australian laws. Ektor products are warranted in Australia for a period of 12 months from the date of delivery of the product, provided that the products are properly stored, installed, used and maintained in accordance with the instructions DRAFT contained within their manual.

  • Page 15: Compliance Standards

    28. comPliance stanDarDs STANDARD TITLE Australian/ New Zealand AS/NZS 2293-3:2005+A1:2010 Emergency escape lighting and exit signs for buildings. Part 3: Emergency escape luminaires and exit signs. Standards AS/NZS 60598-2-22:2005 Luminaires Part 2.22: Particular requirements - Luminaires for emergency lighting (IEC 60598-2-22, Ed. 3.1(2002) MOD). AS 61000.3.2:2007 + A1:2009 Electromagnetic compatibility (EMC) - Limits - Limits for harmonic current emissions (equipment input current...
  • Page 16 DRAFT Ph: + 612 9502 1161 Fax: + 612 9502 1154 Email: sales@evolt.com.au evolt.com.au Reference: 602893_V2...
