The LAARS Gateway Startup Guide
Document 4236E
ProtoNode FPC-N34 and ProtoNode FPC-N35
ProtoNode FPC-N34 and ProtoNode FPC-N35
Startup Guide
Startup Guide
For Interfacing LAARS Products:
For Interfacing LAARS Products:
Sola
Sola
To Building Automation Systems:
To Building Automation Systems:
BACnet MS/TP, BACnet/IP, Modbus TCP/IP, Metasys N2
and LonWorks
and LonWorks
APPLICABILITY & EFFECTIVITY
APPLICABILITY & EFFECTIVITY
Explains ProtoNode FPC-N34 and FPC-N35 hardware and how to install it.
Explains ProtoNode FPC-N34 and FPC-N35 hardware and how to install it.
The instructions are effective for the above as of July 2015
The instructions are effective for the above as of July 2015
Document Revision: 9.C
Document Revision: 9.C
Auto Selector
Auto Selector
Template Revision: 45
Template Revision: 45
800.900.9276 • Fax 800.559.1583
Customer Service and Product Support:
800.900.9276 • Fax 800.559.1583
(Customer Service, Service Advisors)
20
Industrial Way, Rochester, NH USA 03867 • 603.335.6300 • Fax 603.335.3355
Headquarters:
20 Industrial Way, Rochester, NH 03867 • 603.335.6300 • Fax 603.335.3355
(Applications Engineering)
1869 Sismet Road, Mississauga, Ontario, Canada L4W 1W8 • 905.238.0100 • Fax 905.366.0130
1869 Sismet Road, Mississauga, Ontario, Canada L4W 1W8 • 905.238.0100 • Fax 905.366.0130
www.Laars.com
www.Laars.com
Litho in U.S.A. © Laars Heating Systems 1602 Document 4236E
