COUGAR MARS Assembly Drawing

M A R S
GAMI NG DE SK
COUGAR MARS gaming desk provides ergonomic design and generous gaming space with dazzling
RGB lighting effects for enhancing your superior gaming experiences.
Itʼs how we make your gaming dreams come true and present a unique gaming desk for you!
Enormous and Ergonomic Gaming Space
The spacious gaming surface with carbon fiber texture brings you plenty of space for your gaming
monitors, gaming keyboards, and other gaming gears. Highly ergonomic designs like curved edges
and rounded corners give you better and more comfort gaming experience.
Multifunction Designs
With control stands, you can easily control PC and connect USB/audio devices conveniently. COUGAR
Mars maximizes your gaming experience.
Dual-sided RGB Lighting Effects
In order to increase more immersive feeling in your gaming atmosphere. MARS provides various RGB
lighting effects. It is also compatible motherboardsʼ 5V connection with Asus Aura Sync, Gigabyte RGB
Fusion, MSI Mystic Light Sync, and ASRock Polychrome Sync for system-wide lighting synchronization.
High-strength Welded Steel Frame for Maximum Stability
COUGAR Mars is made of high-strength steel frame for maximum stability. The height of the gaming
desk is manually adjustable between three levels (75/80/85 CM) for the most comfortable position.
ENGLISH
•Ergonomic curved edges design and rounded corners.
•Dual side wing: RGB backlight effects.
•Support for 5V RGB motherboard connections (ASUS,ASRock,Gigabyte or MSI).
•USB3.0 pass-through x2 & Audio Jacks.
•PC's power, reset function are easily accessible on control panel.
•Desktop height adjustment (75/80/85 CM).
•Carbonlike Surface Design.
•High-strength welded steel frame for maximum stability.
ESPAÑOL
•DesignDiseño ergonómico de bordes curvos y esquinas redondeadas.
•Wing Ala lateral doble: RGB efectos de retroiluminación.
•Soporte para conexiones de placa madre de 5V RGB (ASUS, ASRock, Gigabyte o MSI).
•USB3.0 pass-through x2 y conectores de audio.
•PowerEl poder de la PC, la función de restablecimiento son fácilmente accesibles en el panel de control.
•Adjustment Ajuste de altura de la mesa (75/80/85 CM).
•Diseño de superficie de carbono.
•Frame Bastidor de acero soldado de alta resistencia para una máxima estabilidad.
ITALIANO
•Design ergonomico dei bordi curvi e angoli arrotondati.
•Ala laterale doppia: RGB effetti di retroilluminazione.
•Supporto per connessioni della scheda madre RGB 5V (ASUS, ASRock, Gigabyte o MSI).
•USB3.0 pass-through x2 e prese audio.
•La potenza del PC, la funzione di reset sono facilmente accessibili sul pannello di controllo.
•Regolazione altezza del frontalino (75/80/85 CM).
•Carbonlike Surface Design.
•Telaio in acciaio saldato ad alta resistenza per la massima stabilità.
PORTUGUÊS
•Edges Design de bordas curvas ergonómicas e cantos arredondados.
•SideA asa lateral dupla: RGB efeitos de luz de fundo.
•Suporte para conexões de placa-mãe de 5V RGB (ASUS, ASRock, Gigabyte ou MSI).
•USB3.0 pass-through x2 e tomadas de áudio.
•PowerPC poder, função de reset são facilmente acessíveis no painel de controle.
•Adjustment Ajuste de altura do desktop (75/80/85 CM).
•Design de superfície de carbono.
•Estrutura de aço soldada de alta resistência para máxima estabilidade.
1 2
A
B
6
x4
5
2
x8
10
2
x8
!
Position and do not tighten
the screws.
ASSEMBLY DRAWING
C
A
SPECIFICATIONS
Product Name COUGAR MARS Gaming Desk
Model No. CGR-MARS
USB 3.0 x 2 / Audio Jacks x 2 /
I/O Panel
Power button / Reset button / RGB button
Desk Dimension 153.3 (W) x 77.1 (D) mm / 60.4 (W) x 30.4 (D) inch
Three adjustment :
Desk Height
75 / 80 / 85 (H) cm
29.5 / 31.5 / 33.5 (H) inch
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
A
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H1702000001 означает, что товар был произведен в феврале 2017 года.
B
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год, последующие две цифры – месяц изготовления.
Например, S/N: DAG02REVI000001 означает, что товар был произведен в феврале 2017 года.
A B C D E F G H I J
1 2 3 4 5 6 7 8 9 0
Например, AG = 17 = 2017 год
●
3
C D
1
5
6
I
H
I
2
x 8
11
16 Screws
!
Make sure the 16 screws are positioned
and then lock solidly truly.
M
F
X2
E
X2
G
X2
I
H
I
ACCESSORY KIT
1
2
3
4
5
6
7
Spare parts : 1 2 x 2
• Height Adjustment:
MARS gaming desk has three adjustment options: 75cm – 80cm – 85cm
(desktop to ground).
To strengthen the stability, please fasten TWO screws on each side.
x 4
x 4
7
1
x 4
12
M
4
K
O
P
x 8 8
x 4 4
9
x 8
10
x 4
x 4
11
x 4
x 1
4
1
2
75cm
85cm
80cm
8 9
J
2
x 8
!
Position and do not tighten
the screws.
13
N
3
!
x4
J
L
N
D
B
x1
x1
x1
x1
F
G
E
• Please follow this step to assemble two sets.
2
x6
K
L
O
P
x8
When the control stands are uneven on the
gaming desk, they will be automatically
corrected when locking the screws.
To avoid the screw bosses are damaged,
please do not lock the screws too tight.
