WR-90 Point to Multi-Point Wireless
Instruction Manual
• Point to Multi-Point Signal Wire Replacement
• Simple to Configure Using WR Manager
Programming Software and Onboard USB
• Range: 1 Mile Line-of-Sight, 500 Ft Indoor
• Analog, Digital, and RS-485 Inputs and Outputs
• Remote or Attached, Directional and Omnidirectional Antennas Available
• Field Units Feature Flanges for Wall or Pipe Mounting
• Base Station Housed in Plastic NEMA 4X Field Enclosure
• Field Units Housed in IP68, NEMA 4X Enclosure
Wireless System
Division of Garner Industries
7201 North 98th Street
Lincoln, NE 68507-9741
(402) 434-9102
Advertisement
Table of Contents
Related Manuals for BINMASTER WR-90 Series
Summary of Contents for BINMASTER WR-90 Series
- Page 1 WR-90 Point to Multi-Point Wireless Instruction Manual Wireless System • Point to Multi-Point Signal Wire Replacement • Simple to Configure Using WR Manager Programming Software and Onboard USB • Range: 1 Mile Line-of-Sight, 500 Ft Indoor • Analog, Digital, and RS-485 Inputs and Outputs •...
- Page 2 WR-90 Point to Multi-Point Wireless Instruction Manual Disclaimer The information contained in this document is subject to change without notice. BinMaster makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
-
Page 3: Table Of Contents
WR-90 Point to Multi-Point Wireless Instruction Manual Table of Contents Table of Contents ........... 3 Power Connector .......... 11 Table of Figures ............. 3 Analog Input Connector ........ 11 Introduction ............. 4 Analog Output Connector ......11 Ordering Information ..........5 Digital I/O Connector ........ -
Page 4: Introduction
WR-90 Point to Multi-Point Wireless Instruction Manual Introduction The BinMaster WR-90 is a rugged, customizable, point-to-multipoint wireless bridge. It offers a highly-flexible means of getting analog, digital, and Modbus® signals from where you have them to where you need them. Modular input/output cards and expandable field units mean that the WR-90 can be customized to meet the needs of any wireless application. -
Page 5: Ordering Information
WR-90 Point to Multi-Point Wireless Instruction Manual Ordering Information WR-90 Wireless Components Model Number Description WR-90-BA WR-90 Point-to-Multipoint Wireless Process Signal Base Station WR-90-TR WR-90 Point-to-Multipoint Wireless Process Signal Field Unit Base Station Modules Model Number Description WR-90-CA WR-90 Dual Analog Input Base Station Module WR-90-CT WR-90 Dual Analog Output Base Station Module WR-90-CR... -
Page 6: Specifications
WR-90 Point to Multi-Point Wireless Instruction Manual Specifications Except where noted all specifications apply to operation at +25°C. WR-90 Base Station Specifications HART Analog input will not interfere with General existing HART communications on Transparency the wired 4-20 mA signal Maximum 32 field units Connected... -
Page 7: Wr-90 Field Unit Specifications
WR-90 Point to Multi-Point Wireless Instruction Manual WR-90 Field Unit Specifications Analog Input General Inputs Field selectable: 4-20 mA, 0-10 V, Display 32-character dual-line alphanumeric 0-5 V, 1-5 V dot matrix LCD display with backlight Accuracy ±0.03% of calibrated span ±1 count (4.68mm x 2.21mm characters) Temperature 0.005% of calibrated span/°C max... -
Page 8: General Specifications
WR-90 Point to Multi-Point Wireless Instruction Manual General Specifications Wireless Radio WR Manager Software ® ® Frequency 900 MHz System Microsoft Windows XP/Vista/7/8/10 Range 500 ft (152.4 m) indoor, 1 mi Requirements (1.61 km) outdoor (line-of-sight) Communicatio USB 2.0 (Standard USB A to Micro USB B) Encryption AES 128-bit encryption available... -
Page 9: Pre-Installed Conduit Plug
WR-90 Point to Multi-Point Wireless Instruction Manual Pre-Installed Conduit Plug The WR-90 field units are supplied with one pre-installed optional conduit plug for installations that do not require the use of both conduit entries. The conduit plug includes an internal hexagonal socket recess for removal. -
Page 10: Base Station Connections
WR-90 Point to Multi-Point Wireless Instruction Manual Base Station Connections To access the connectors for the base station, open the enclosure door. Signal connections are made to removable screw terminal connectors. • The WR-90 base station must be powered down completely prior to installing or removing any modules. -
Page 11: Figure 2. Base Station Power Connection
WR-90 Point to Multi-Point Wireless Instruction Manual Power Connector Power connections are made to a two-terminal connector labeled POWER in Figure 1. Make sure that the power supply can provide 24 VDC to the wireless base station. Figure 2. Base Station Power Connection Analog Input Connector The analog input module can accept either 4-20 mA, 0-10 V, 0-5 V,... -
Page 12: Figure 6. Base Station Relays Connection
WR-90 Point to Multi-Point Wireless Instruction Manual Relays Connector The relays module includes two mechanical relays. Relay connections are made to the six-terminal connector shown to the right. Each relay’s C terminal is common only to the normally open (NO) and normally closed (NC) contacts of the corresponding relay. -
Page 13: Figure 9. Base Station Three- And Five-Wire Rs-485 Modbus Connection
WR-90 Point to Multi-Point Wireless Instruction Manual Modbus RTU Serial Communications The WR-90 base station acts as a simple pass-through for Modbus communications. As such, multiple Modbus enabled devices may transmit and receive wirelessly using the base station. (WR-90 Base Station) Shield Twisted-Pair (WR-90 Base Station) -
Page 14: Figure 11. Field Unit Device Assembly, Rear View
WR-90 Point to Multi-Point Wireless Instruction Manual Field Unit Connections To access the connectors, remove the enclosure cover and unscrew the two captive stainless steel screws. Remove the electronics assembly from the enclosure. Signal connections are made to removable terminal blocks on the back of the electronics assembly. Grounding connections are made to the two ground screws provided on the base –... -
Page 15: Figure 12. Field Unit Power Connection
WR-90 Point to Multi-Point Wireless Instruction Manual Power Connector Power connections are made to a two-terminal connector labeled POWER in Figure 11. The WR-90 is reverse polarity protected; it will not be damaged if wired backward. Make sure that the power supply can provide between 12 and 24 VDC to the wireless device. -
Page 16: Signal Connector
WR-90 Point to Multi-Point Wireless Instruction Manual Signal Connector The analog input may be either 4-20 mA, 0-10 V, 0-5 V, or 1-5 V. The appropriate input type must be programmed for each unit. Once the appropriate input type has been programmed, wire the analog signal source to the device as shown in the diagram at right. -
Page 17: Modbus Rtu Serial Communications
WR-90 Point to Multi-Point Wireless Instruction Manual Modbus RTU Serial Communications The WR-90 field units act as simple pass-throughs for Modbus communications. As such, multiple Modbus enabled devices may be transmitted wirelessly using a wireless field unit. Note: Modbus Master must be connected to Base Station. (WR-90 Field Unit) Shield Twisted-Pair... -
Page 18: Setup And Programming
WR-90 Point to Multi-Point Wireless Instruction Manual Setup and Programming The base station and field units are factory calibrated prior to shipment to read analog inputs in milliamps or volts depending on the input selection. The calibration equipment is certified to NIST standards. Overview There are no jumpers to set for wireless device input selection. -
Page 19: Connecting Field Units To Base Station
WR-90 Point to Multi-Point Wireless Instruction Manual Connecting Field Units to Base Station The first thing that must be done when programming the WR-90 is connect all of the wireless field units to the base station. Configuration of the base station is accomplished using the WR Manager software, while the individual field units may be programmed using the device buttons which are accessed by unscrewing the enclosure cover. -
Page 20: Base Station Configuration
WR-90 Point to Multi-Point Wireless Instruction Manual Base Station Configuration The Base Station Configuration tab is where the base station name, network ID, password, and Modbus settings may be modified. Once you are finished modifying any of these settings, click the Save Settings button to write your changes to the device. -
Page 21: Input / Output Module Configuration
WR-90 Point to Multi-Point Wireless Instruction Manual Input / Output Module Configuration The Base Station IO Configuration tab is where individual I/O modules connected to the base station may be programmed. Click on one of the installed modules in the IO Modules list to the left of the screen in order to begin programming that module. - Page 22 WR-90 Point to Multi-Point Wireless Instruction Manual 4-20 mA Analog Outputs Module Each Analog Outputs module has two 4-20 mA output channels. Each channel may be independently programmed and mapped to remote analog inputs or Modbus registers. Once you have modified the module’s settings, click the Save Module Configuration button to save these settings to the base station.
- Page 23 WR-90 Point to Multi-Point Wireless Instruction Manual Digital I/O Module Each Digital I/O module has four I/O channels. Each channel may be independently programmed as either an input or an output. These channels may also be mapped to a remote digital I/O or Modbus register.
- Page 24 WR-90 Point to Multi-Point Wireless Instruction Manual Relays Module Each Relays module has two channels. Each channel may be independently programmed and mapped to remote digital I/O or Modbus registers. Once you have modified the module’s settings, click the Save Module Configuration button to save these settings to the base station.
-
Page 25: Remote Unit Configuration
WR-90 Point to Multi-Point Wireless Instruction Manual Remote Unit Configuration The Remote Unit Configuration tab is where connected field units may be programmed to communicate with the base station. Select a connected field unit from the Connected Clients list in order to begin programming that unit. - Page 26 WR-90 Point to Multi-Point Wireless Instruction Manual 4-20 mA Analog Output The 4/20mA Output tab is used to program the selected field unit’s analog output. Once you have modified the settings, click the Save Configuration button to save these settings to the field unit. The IO Mapping section will show to what (if any) device the analog input has been mapped.
- Page 27 WR-90 Point to Multi-Point Wireless Instruction Manual Digital I/O Each field unit has four digital I/O channels. Each channel may be independently programmed as either an input or an output. Once you have modified the settings, click the Save Configuration button to save these settings to the field unit.
- Page 28 WR-90 Point to Multi-Point Wireless Instruction Manual Modbus RTU ® Each field unit is capable of transmitting Modbus RTU serial communications. Enter the Modbus network settings on the Modbus tab in order to communicate with the Modbus network. The Modbus address must be unique in order to ensure field unit/base station connectivity.
-
Page 29: Advanced Configuration
WR-90 Point to Multi-Point Wireless Instruction Manual Advanced Configuration Device communication can be secured by enabling 128-bit AES encryption. A channel mask may also be set for interference immunity. The encryption key and channel mask may be entered on the Advanced tab. -
Page 30: Programming The Field Units
WR-90 Point to Multi-Point Wireless Instruction Manual Programming the Field Units The field units can be programmed using the buttons located behind the enclosure cover or using WR Manager. Because of the limited number of options available for the field units, it is easier in most cases to use the programming buttons. -
Page 31: Field Unit Setup Menu
WR-90 Point to Multi-Point Wireless Instruction Manual Field Unit Setup Menu ® The setup menu consists of analog, digital (discrete), and Modbus input/output settings, network ID, password, and factory defaults restoration. Run Mode RSSI 10 increments selected digit. LINK OK selects next digit to the right. - Page 32 WR-90 Point to Multi-Point Wireless Instruction Manual Entering Numeric Values Numeric values are set using the next and previous buttons. Press next to select next digit and previous to increment digit value. The selected digit will flash. Press the enter button, at any time, to accept the value or the menu button to exit without saving. Increment Select the Increment...
- Page 33 WR-90 Point to Multi-Point Wireless Instruction Manual Making Changes to a Password Protected Field Unit Once a password has been set on the device, you will be required to enter that password before being allowed to access the device menu. Note: Setting a password will require you to enter the password to access the device settings via the PC software as well.
-
Page 34: Programming The Field Units With Wr Manager
WR-90 Point to Multi-Point Wireless Instruction Manual Programming the Field Units with WR Manager The field units may also be programmed using the PC based WR Manager. Field units connect to a PC via the micro USB connection on their face, underneath the enclosure cover. Use of WR Manager is required for programming advanced settings such as wireless encryption and analog signal calibration. - Page 35 WR-90 Point to Multi-Point Wireless Instruction Manual The field unit’s analog inputs and outputs can be calibrated using the Calibration tabs. The IO Testing tab allows you to perform diagnostics and testing on the units. Note: The field units are factory calibrated prior to shipment to read analog inputs in milliamps and volts depending on the input selection.
- Page 36 WR-90 Point to Multi-Point Wireless Instruction Manual Device communication can be secured by enabling 128-bit AES encryption. A channel mask may also be set for interference immunity. The encryption key and channel mask may be entered on the Advanced tab. Once you have entered the encryption information, click Save Settings. If you have made changes that have not been saved and would like to load the saved settings from the base station, click the Read Settings button.
-
Page 37: Troubleshooting
WR-90 Point to Multi-Point Wireless Instruction Manual Troubleshooting If you are experiencing difficulties with your wireless installation, consult the troubleshooting steps listed below. For best results, identify the symptoms of the problem you are having and attempt all of the corrective actions listed for the particular symptom. - Page 38 WR-90 Point to Multi-Point Wireless Instruction Manual Symptom Possible Cause Corrective Action Wireless device • Make sure that input type on the device is has mismatched correct for the analog input being used. Destination device reads out input type. Options are 4-20 mA, 0-10 V, 0-5 V, or 1-5 V. of range, zero, or incorrect.
- Page 39 29 or page 33. If you require technical support, please contact us at: Phone: (402) 434-9102 Fax: (402) 434-9133 Email: info@binmaster.com Web: www.binmaster.com...
-
Page 40: Mounting Dimensions
WR-90 Point to Multi-Point Wireless Instruction Manual Mounting Dimensions Note: all units are in inches (mm). Figure 19. Base Station Dimensions – Figure 20. Base Station Dimensions – Front View Side View 2.31 (58.6) 4.00 (101.6) Ø 0.35 (Ø 9.0) 2.17 (55.0) 4.27 (108.4) 2.74 (69.7) -
Page 41: Pda6963-Bm Stainless Steel Pipe Mounting Kit For Field Units
WR-90 Point to Multi-Point Wireless Instruction Manual PDA6963-BM Stainless Steel Pipe Mounting Kit for Field Units Pipe Figure 23. PDA6963-BM Stainless Steel Pipe Mounting Kit for Field Units... - Page 42 Division of Garner Industries 7201 North 98th Street P.O. Box 29709 Lincoln, NE 68507-9741 Lincoln, NE 68529 (402) 434-9102 Fax: (402) 434-9133 www.binmaster.com Email: info@binmaster.com 925-0382 LIMW90BM_A Base Station: SFT103 Ver. 1.000 & up Field Units: SFT102 Ver. 1.000 & up 10/19...
