Instruction Manual
WR-30 & WR-90 Repeater Field Unit
Instruction Manual
• Wireless Repeater Unit in a Rugged, Industrial Housing
• Simple to Order, Configure, & Install
• Increase Range an Additional 1 Mile Line-of-Sight, 500 Ft Indoor
• Remote or Attached Antenna
• Flanges for Wall or Pipe Mounting
• Software Available for Even Easier Setup
• Rugged, IP68, NEMA 4X Enclosure
Wireless System
Division of Garner Industries
7201 North 98th Street
Lincoln, NE 68507-9741
(402) 434-9102
Advertisement
Table of Contents
Related Manuals for BINMASTER WR-30 Series
Summary of Contents for BINMASTER WR-30 Series
- Page 1 WR-30 & WR-90 Repeater Field Unit Instruction Manual Wireless System • Wireless Repeater Unit in a Rugged, Industrial Housing • Simple to Order, Configure, & Install • Increase Range an Additional 1 Mile Line-of-Sight, 500 Ft Indoor • Remote or Attached Antenna •...
- Page 2 Wireless Repeater Field Unit Instruction Manual Disclaimer The information contained in this document is subject to change without notice. BinMaster makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
-
Page 3: Table Of Contents
Wireless Repeater Field Unit Instruction Manual Table of Contents Table of Contents ............................3 Table of Figures ............................3 Introduction ..............................4 Ordering Information ............................ 4 Specifications ............................... 5 General ..............................5 Wireless Radio ............................5 WR Manager Software ..........................5 Safety Information ............................ -
Page 4: Introduction
Wireless Repeater Field Unit Instruction Manual Introduction BinMaster WR-30-RP wireless signal repeaters are used to retransmit wireless signals when connectivity between WR-30 or WR-90 wireless units is an issue. They are incredibly simple to install as they only require power and a network ID. Any units in range of the repeater with the same network ID will retransmit through it, thus increasing signal strength. -
Page 5: Specifications
Wireless Repeater Field Unit Instruction Manual Specifications Except where noted all specifications apply to operation at +25°C. General Mounting May be mounted directly to conduit. Two mounting holes for 1.5" pipe or Display 32-character dual-line alphanumeric wall mounting. See Mounting dot matrix LCD display with backlight Dimensions on page 15 for mounting (4.68mm x 2.21mm characters) -
Page 6: Safety Information
Wireless Repeater Field Unit Instruction Manual Safety Information Caution: Read complete instructions Warning: Read all product labels prior to installation and operation of the completely and follow all instructions device. and requirements listed on the labels for installation or service. Installation and service should be performed only by trained service personnel. -
Page 7: Pre-Installed Conduit Plug
Wireless Repeater Field Unit Instruction Manual Pre-Installed Conduit Plug The WR-30-RP is supplied with one pre-installed optional conduit plug for installations that do not require the use of both conduit entries. The conduit plug includes an internal hexagonal socket recess for removal. -
Page 8: Connections
Wireless Repeater Field Unit Instruction Manual Connections To access the power connector, remove the enclosure cover and unscrew the two captive stainless steel screws. Remove the electronics assembly from the enclosure. The power connection is made to a two- terminal removable connector on the back of the assembly. Grounding connections are made to the two ground screws provided on the base –... -
Page 9: Setup And Programming
Wireless Repeater Field Unit Instruction Manual Setup and Programming Overview Setup and programming is done through the programming buttons located underneath the enclosure cover. After power connection has been completed and verified, apply power to the device. Programming Buttons The units can be programmed using the buttons located behind the enclosure cover. Use the menu button to enter or exit programming mode, the next button to cycle forward through menu options, the previous button to cycle backward through menu options, and the enter button to select the menu item or option you want. -
Page 10: Wr Manager Software
Wireless Repeater Field Unit Instruction Manual WR Manager Software The unit can also be programmed using the PC based WR Manager. Units connect to a PC via the micro USB connection on their face, underneath the enclosure cover. Use of WR Manager is required for programming advanced settings such as wireless encryption. Note: Units must be powered externally prior to programming via USB. -
Page 11: Setup Menu
Wireless Repeater Field Unit Instruction Manual Setup Menu The setup menu consists of network ID, password, and factory defaults restoration. Run Mode RSSI 10 increments selected digit. <------> selects next digit to the right. NETW ORK ID NETW ORK ID NOW: 01 SET: 01 PASS WORD... -
Page 12: Password Setup
Wireless Repeater Field Unit Instruction Manual Password Setup Both the primary and secondary wireless units may be protected with a four-digit numeric password in order to prevent unauthorized tampering. When a password has been set, you will be prompted to enter that password in order to access the device menu. -
Page 13: Programming With Wr Manager
Wireless Repeater Field Unit Instruction Manual Programming with WR Manager WR Manager allows you to program the WR-30-RP wireless repeater unit from a PC with a USB connection. The unit connects to a PC via the micro USB connection on its face, underneath the enclosure cover. - Page 14 Wireless Repeater Field Unit Instruction Manual Device communication can be secured by enabling 128-bit AES encryption. A channel mask may also be set for interference immunity. The encryption key and channel mask may be entered on the Advanced tab. Once you have entered the encryption information, click Save Settings. The wireless devices must share identical encryption keys in order to communicate, so be sure to enter the same information for the second unit.
-
Page 15: Mounting Dimensions
Wireless Repeater Field Unit Instruction Manual Mounting Dimensions 2.31 (58.6) 4.00 (101.6) Ø 0.35 (Ø 9.0) 2.17 (55.0) 4.27 (108.4) 2.74 (69.7) 3.62 (92.0) 2.44 (61.9) 4.30 (109.2) ½" NPT Figure 3. Enclosure Dimensions – Front Figure 4. Enclosure Dimensions – Side View Cross Section View Note: The supplied conduit plug may extend up to 0.6 in [15 mm] from the conduit opening when... - Page 16 Division of Garner Industries 7201 North 98th Street P.O. Box 29709 Lincoln, NE 68507-9741 Lincoln, NE 68529 (402) 434-9102 Fax: (402) 434-9133 www.binmaster.com Email: info@binmaster.com 925-0383 LIMW30RBM_A SFT102 Ver 1.100 & up 10/19...
