Summary of Contents for tws NV-W002
- Page 1 USER MANUAL TWS Wireless earphone 第 - 1 - 页 共 13 页...
- Page 2 Product Parameters： Product model Wireless earphone version RTL8763BFR V5.0+EDR Talk time about 4 hours Music time about 4 hours Headphone tip language English Transmission distance Headphone charging time about 1 hours Charging time of charging box about 8 hours Single headphone weight 4.5g Charging box weight 135g...
- Page 3 Function description： Switch/Power LED indicator button microphone Horn Charging contact 第 - 3 - 页 共 13 页...
- Page 4 Micro USB charging port Charging box battery indicator position Charging: (1) Headphone charging. The charging box has a built-in battery. When the charging box is fully charged, put the earphone into the charging box to charge the earphone. When the earphone is in the charging state, it always lights up red, the charging box is always bright blue;...
- Page 5 Full of electricity Bright blue light goes out after 30 seconds Charging box Charging Blue light flashes Full of electricity Blue light is always on wearing method: Please choose the earphones of different sizes (the earphones are medium-sized earphones, and the accessories include large and small earbuds and hook-type earhooks).
- Page 6 When the earphone is not inside the charging box, you can manually touch the power on; at the same time, press and hold the two headphones to open the key for about 3 seconds, then let go, this time is the power on state. Pairing mode: Open the top cover of the charging box, then pick up the two headphones, the two headphones will automatically turn on (there...
- Page 7 you use the right ear R), the searched pair name is "V10-R", click the connection, You can use the single ear mode. (At this time, the blue light of the headset flashes slowly, and it flashes once every 3 seconds) Play / Pause / Cut song (up and down) (1) Play/Pause.
- Page 8 main ear to open the key, and the music can be switched to the previous song. Call Pickup / Hangup / Reject / End Replay / Voice Assistant / Factory Reset When the headset is in the pairing state, after connecting with the mobile phone, when there is a call incoming, there is an incoming call alert.
- Page 9 Three-click the main ear or the auxiliary ear to open the key, but the last number can be replayed; (5) Voice assistant. When the headset is successfully paired, after connecting with the mobile phone, press and hold the main or secondary ear for 1 second to turn on the voice assistant.
- Page 10 (2) Press and hold the two earphones for about 3 seconds at the same time to turn off the headphones; (3) When the headset is disconnected from the mobile phone for more than 5 minutes, the headset automatically shuts down; Other functional tests: (1) Boot back.
- Page 11 (5) Back connection status. The TWS connection state lasts for 20 seconds, and the Bluetooth status of the mobile phone is connected for 30 seconds. If there is no connection, the pairing state will be entered;...
- Page 12 (10) Charging box battery capacity. 3.7V/3200mAh (the charging box can be used to charge the headset for more than 30 times), the charging box can be used as an emergency mobile power source to charge the mobile phone and other peripherals (the MIRCO 5PIN charging adapter is equipped in the accessory);...
- Page 13 (3) If a single product is replaced or is mishandled, the main and sub-headphones are disconnected, and the left and right headphones are re-paired. (4) If the earphone is connected to the mobile phone and there is no sound after listening to the song, please go to the Bluetooth setting of the mobile phone, find the name of the connected headset, and if the display is connected, click the name of the headset again.
