Panucatt Devices Azteeq X3 3DP Wiring Diagram

BASIC SETTINGS
SELECT ARDUINO MEGA 2560 on Arduino IDE
SELECT MOTHERBOARD 33 or 34 on Marlin, Repetier or Sprinter
EXPANSION
D25 D29 A12 A11 SDA
D23 D27 A5 A4 D22
D17 D16 D31 D32 D7
+ _
POWER INPUT
PC POWER SUPPLY OR
AC/DC SWITCHING PS
12-24VDC
HEATED BED
FAN OR 2ND HOT-END
HOT-END
v1.01
X-AXIS
J11 J2
D41 TX
SCL
D40 RX
+5V
D37 GND
GND
D35 +5V
Max
Z-STOP
Y-STOP
X-STOP
NO(Normally Open)
(OPTIONAL)
ENDSTOPS
Location of C and NO on switch
may vary. Check markings.
STEPPER MOTORS
Y-AXIS Z-AXIS
PARALLEL
OR SERIES
PANUCATT DEVICES
J11
J2
SERIAL
Min
LOW POWER SWITCH
(PWM)
C(Common)
5V FAN
12V FAN
LED STRIPS
EXTR1 EXTR2
GND
GND
VMOT
0.15in
#6-32 X 4
STEP SIZE
SELECTOR
RESET
ICSP
ATX PWR
SD ACTIVITY LED
microSD
(TransFlash)
USB PORT
MINI B
BUZZER
HOTEND2
HOTBED
HOTEND1
THERMISTORS
PANUCATT DEVICES
reprap.org/wiki/Azteeg_X3
DIR
VDD STEP
2B SLEEP
RST
1A
MS3
2A
2B MS2
MS1
ENABLE
STEPPER DRIVER
ORIENTATION
meters | controllers | sensors
