Panucatt Devices Azteeg X3 V2.0 Wiring Diagram

BASIC SETTINGS

SELECT ARDUINO MEGA 2560 on Arduino IDE
SELECT MOTHERBOARD 33 or 34 or 67 on Marlin or Repetier

EXPANSION

D25 D29 A12 A11
A5
D23 D27 A4
D17 D16 D31 D32
D39
SCL SDA A3
D22 +5V A9 D47
D7 GND A10 GND
+ _

POWER INPUT

PC POWER SUPPLY OR
AC/DC SWITCHING PS
12-24VDC
REVERSE POLARITY MAY
DAMAGE BOARD
HEATED BED
FAN OR 2ND HOT-END

HOT-END

v1.0
X-AXIS
J4 J3 J2
D42 D41 TX
D43 D40 RX
D44 D37 GND
D45 D35 +5V
SECONDARY INPUT
INPUT
SELECT
Max
Z-STOP
Y-STOP
C(Common)
X-STOP
NO(Normally Open)
(OPTIONAL)

ENDSTOPS

Location of C and NO on switch
may vary. Check markings.
Signal to ground or to +5V can
be used. May require firmware changes.

STEPPER MOTORS

Y-AXIS Z-AXIS
PARALLEL
OR SERIES
Min
LOW POWER SWITCH
(PWM)
5V FAN
12V FAN
LED STRIPS
INCORRECT ORIENTATION
MAY DAMAGE BOARD AND
EXTR1 EXTR2
GND
GND
VMOT
MISO
STEP SIZE
SELECTOR
RESET
microSD
(TransFlash)
Push-in
Push-out

USB PORT

MINI B
(D33)BUZZER

INPUT SELECT JUMPER

FOR mCONTROLLER
HOTEND2
HOTBED
HOTEND1

THERMISTORS

PANUCATT DEVICES
reprap.org/wiki/Azteeg_X3
DRIVER
DIR
VDD STEP
2B SLEEP
RST
1A
MS3
2A
2B MS2
MS1
ENABLE

STEPPER DRIVER

ORIENTATION
+5V
SCK MOSI
RST GND
ICSP
(D12)ATX PIN
(D49)CARD DETECT
(D53)CHIP SELECT
Remove jumper to use CS
pin externally. For Viki LCD
or other display panels.
Keep for onboard SD slot.
INTERNAL REGULATOR
USB 5V
