AutoDab USB Installation & User Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Installation & User Guide
What's Included?
i. AutoDAB USB Interface
ii. Amplified Antenna
iii. USB Connection Lead
Features & Benefits
•
Universal, plug and play digital radio interface
•
True Digital Sound
•
Integrates seamlessly with the original vehicle stereo
•
Operated via the vehicle's head unit or steering wheel controls
•
Voice prompt system for added safety (if supported by the original head unit)
•
Glass mount DAB antenna included for high quality signal
The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This
instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the
vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.
ii
i
DISCLAIMER
USB
iii
AUTODAB-USB_IUG_en-GB_v1
