Related Manuals for Apex Digital TRAVERSE E112
Summary of Contents for Apex Digital TRAVERSE E112
- Page 1 2kw Remote Control Electric Fire. User and Installation Instructions TRAVERSE FLAME HEATER Please read the instructions carefully before the installation or use of this electric fire and retain for future reference.
- Page 2 IMPORTANT INFORMATION z This heater must not be located immediately below a socket-outlet. z This heater must be earthed. If in any doubt consult a suitable competent person. z This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 3 DIMENSIONS F LA ME HE A TE R Dimensions in mm Mantel Minimum Mantel opening size Depth（RD） Width Width Height Height Depth Model With （W1） （W2） （H1） （H2） （D） Width Height spacer spacer （OW） （OH） frame frame E112 Spacer frames to reduce the minimum rebate depth to 75 mm and a full depth flat wall fix spacer can be purchased from your supplier.
- Page 4 ● Installation into a fireplace opening/insert no spacer frame with spacer frame Carefully mark out the fixing screw positions as above, drill and plug the holes and fit two pan head screws leaving approximately 2mm between the wall/panel and the underside of the screw head.
- Page 5 OPERATION This appliance can be operated by both remote control and manual button. Once the unit has been properly connected to an earthed electrical outlet, turn on the main switch. A beep should be heard when the power is first applied. NOTE: To use both remote and manual functions the main on/off switch must be in the ‘on’...
- Page 6 ICON TITLE FUNCTION POWER Press once will turn the fire on. Press again turns the fire off. The fire has four flame effect settings. Pressing the flame effect FLAME button will cycle the fire through each effect. Pressing once will turn the heater fan on. 8secs later the element will switch on to the low heat setting.
- Page 7 Cleaning the Fireplace You can clean the exterior of the fireplace with a soft, damp, lint-free cloth. Do not use cleaning or polishing products. To remove fingerprints or other marks on the front glass panel, use a soft, damp, lint-free cloth with a good quality household glass cleaner. The front glass panel should always be completely dried with a clean, lint-free cloth or paper towel.
- Page 8 This fire complies with the European Safety Standards (LVD) EN 60335-2-30 and the European Electro Magnetic Compatibility (EMC) EN 55014-1, EN 55014-2 and EN 61000-3-2 and EN 61000-3-3 which covers the essential requirements of the EC Council Directives and 2004/108/EC...
