Summary of Contents for crosscontrol CC Pilot XL
- Page 1 CC Pilot XLII, rev.1.3 100823 CC Pilot™ XL Sub User Manual and Reference Handbook for the CC Pilot™ Model XL...
-
Page 2: Table Of Contents
User Manual and Reference Handbook for the CC Pilot™ XL Table of Contents Introduction ................................4 Identification ................................ 4 Care ..................................5 Environment and Environmental Tolerance ......................5 Cleaning ................................5 Overview.................................. 6 CC Pilot™ XL – Display unit ..........................6 CC Pilot™... - Page 3 User Manual and Reference Handbook for the CC Pilot™ XL Power Supply ..............................25 Display ................................25 Environmental Tolerance ..........................25 Weight and Dimensions ............................ 26 Contact Technical Support ............................ 29 Trade Mark, etc..............................30 Index ..................................31...
-
Page 4: Introduction
CC Pilot™ XL is built. This material is copyright protected © 2006 CrossControl. All rights reserved. Identification There is a brand label on the back of the display and PC-unit of CC Pilot™ XL. On the brand label there are numbers which identify your unique computer. -
Page 5: Care
Consider traffic safety when the CC Pilot™ XL is installed and whenever it is used. CrossControl does not recommend that CC Pilot™ XL or its accessories be used actively by the driver when a risk of injury to people, or damage to property, is present. -
Page 6: Overview
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL Overview The CC Pilot™ XL is a compact, robust and versatile onboard computer. It is equipped with, among other things, a pressure-sensitive touch screen as well as a large number of connection alternatives such as CAN, COM, Ethernet and USB. -
Page 7: Cc Pilot™ Xl - Pc Unit
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL – PC unit CC Pilot™ also consists of a PC-unit which contains a hard disk and processor. It also provides easily accessible external connectors. Brand Label & Mounting Holes Connector legend External connectors... -
Page 8: Basic Operations
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL Basic operations This section covers basic operation of the CC Pilot XL unit such as start-up ™ and shut down. Function of the Display’s Push-buttons In the top left of the CC Pilot™ XL there are two buttons to control the screen brightness. -
Page 9: Touch Screen
User Manual and Reference Handbook for the CC Pilot™ XL Touch screen The CC Pilot™ XL can as an option be fitted with a touch screen which gives the opportunity to provide a very easy-to-use HMI (Human Machine Interface) for the user. Double and right click on the touch screen To perform the equivalent to a right click on the touch screen first tap the place where the right click is supposed to be pressed and then tap the screen again slightly to the... -
Page 10: External Interface Description
Accessible on the rear of CC Pilot™ XL, there are a number of ports to connect various peripheral equipments. In order to give the CC Pilot™ XL its high environmental classification, the unit is equipped with DIN M12 connectors. CrossControl provides adapter cables which convert from DIN M12 to standard connectors. -
Page 11: Power Supply Connector
User Manual and Reference Handbook for the CC Pilot™ XL Power Supply Connector Marking: POWER IN Connector Type: Serial 723 8 Pin, male Signal Description Comments Not connected PC on 10-36 V = PC on Dpow Unswitched Preheating Signal to starts preheating of HD PC on 10-36 V = PC on Ground... -
Page 12: Ethernet (Ethernet)
User Manual and Reference Handbook for the CC Pilot™ XL The USB ports follow the USB 2.0 standard. Due to data communication safety in rough environments three of the four available USB connectors is limited to full speed (up to 12 Mbps). If high speed is necessary (up to 480 Mbps) the device must be connected to the USB 1. -
Page 13: Can (Can1, Can2)
There is no termination in the interface; therefore, this shall be present in the cable. CrossControl is well-experienced with control via the CAN-interface and both software and drivers are tested in various environments and under different conditions. Contact... -
Page 14: Com
User Manual and Reference Handbook for the CC Pilot™ XL Marking: COM Connector Type: DIN M12, 8-pole, A-coded, male. Signal Description Comments Data Carrier Receive data Transmit data Data Terminal Signal reference Data Set Ready Request To Send Clear To Send The COM port follows the RS232 standard except for the “Ring Indicator”... -
Page 15: Dmi - Display
User Manual and Reference Handbook for the CC Pilot™ XL The DMI cable handles display and control signals between the CC Pilot™ XL Display and PC-unit. The maximum recommended DMI cable length is 5.5 m. Outer cable shield and LCDS double-shield is connected to the connector cover. For information concerning the DMI connector on the display see chapter DMI - Display. -
Page 16: Audio
User Manual and Reference Handbook for the CC Pilot™ XL Audio Marking: Audio Connector Type: DIN M12, 8-pole, A-coded, female. Signal Description Comments Line out L Line out R GND (Speaker) Shield in cable Microphone Mic. Ref. Microphone reference Speaker output L Amplified Speaker output R Amplified... -
Page 17: Vga Out
User Manual and Reference Handbook for the CC Pilot™ XL The Video connector has two composite video inputs for the attachment of video sources such as rear view cameras. It supports PAL, the European video format, as well as NTSC-, the American standard. The video connector can be used to power external using the 12V unfiltered supply. -
Page 18: Installation
Consider traffic safety whenever the CC Pilot™ XL is installed and used in vehicle installations. CrossControl does not recommend that the CC Pilot™ XL or its accessories are used actively by the driver or operator when a risk of injury to people, or damage to property, is present. -
Page 19: Mounting The Display
The connectors shall always be screwed-in securely to give good contact and avoid unnecessary strain. Through adapter cables, as supplied by CrossControl, standard connectors for Ethernet, USB and COM can be connected to the unit. The hook up of these adapter cables can and should be placed in a moisture-free, hidden space and should be secured and strain-relived. -
Page 20: Hook Up Of Power Supply
User Manual and Reference Handbook for the CC Pilot™ XL Hook up of Power Supply This instruction addressed vehicle installations but the principle is the same also for other types of installations. See also the description of the pin outs for the Power Supply Connector under the section External interface description Carefully follow the connection instructions below. -
Page 21: Heating Via Preheating
User Manual and Reference Handbook for the CC Pilot™ XL The power supply cable assembly’s wires, which are delivered by CrossControl, are colour marked according to the table below. Signal Colour marking Not Connected ON/OFF (+28 VDC) Yellow Battery (+28 VDC) Pink Preheating (+6 –... -
Page 22: Software
The CC Pilot™ XL offers a multitude of connection alternatives, for instance via USB. In order for the device connected to CC Pilot™ XL to function correctly, sometimes drivers must be installed. CrossControl can only guarantee the function for applications and devices which are tested and approved by CrossControl. - Page 23 The status tab also has an administrator login button. The administrator login gives access to more parameters. CrossControl does not take any responsibility for any resulting damage or injury given as a result of reconfiguring CCP settings. The general tab From the general tab it is possible to alter the steps for the dimming buttons.
-
Page 24: Specifications
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL Specifications The specification may vary depending on your computer configuration. Computer Core Core Component Description Comments Processor Alternative CPU-boards with Intel Pentium Mobile, performance in the range 600 MHz–1.8 1,6 GHz default Storage Compact Flash (512 MB to... -
Page 25: Power Supply
User Manual and Reference Handbook for the CC Pilot™ XL Power Supply Power Supply Description Comments Supply Voltage 10 to 36 V Power Consumption < 2A at 24 V Display Display Description Comments 10”4 Colour, XGA, 320 cd/mm Aspect Ratio 4:3 12”1 Colour, XGA, 320 cd/mm Aspect Ratio 4:3... -
Page 26: Weight And Dimensions
User Manual and Reference Handbook for the CC Pilot™ XL Weight and Dimensions PC unit Description Comments Enclosure size 268 x 196 x 56 mm (W x H x D) - Page 27 User Manual and Reference Handbook for the CC Pilot™ XL 10.4” Display Description Comments Enclosure size 286 x 217 x 57 mm (W x H x D)
- Page 28 User Manual and Reference Handbook for the CC Pilot™ XL 12” Display Description Comments Enclosure size 322 x 257 x 60 mm (W x H x D)
-
Page 29: Contact Technical Support
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL Technical Support Contact your reseller or supplier for help with possible problems with your CC Pilot™ XL. In order to get the best help, you should have your CC Pilot™ XL in front of you and be prepared with the following information before you contact support. -
Page 30: Trade Mark, Etc
Windows are registered trademarks which belong to Microsoft Corporation in the USA and/or other countries. CrossControl is not responsible for editing errors, technical errors or for material which has been omitted in this document. CrossControl is not responsible for unintentional damage or for damage which occurs as a result of supplying, handling or using of this material. -
Page 31: Index
User Manual and Reference Handbook for the CC Pilot™ XL CC Pilot™ XL Index Environmental Test ........ 25 Environmental Tolerance ....5, 25 Ethernet ........10, 12, 24 Adapter cables ........10 External interface description ....10 Application Approval ....... 18 Audio ............ - Page 32 User Manual and Reference Handbook for the CC Pilot™ XL Operating System ........22 Starting up ..........8 Supply Voltage ........25 Outputs ........... 10 Overview of the CC Pilot™ XLII ....6 Support ........... 29 PAL ............17 Technical Support ........29 Panel Mount ..........
- Page 33 User Manual and Reference Handbook for the CC Pilot™ XL CrossControl AB P.O. Box 83 • SE-822 22 Alfta • Sweden Phone: +46 271 75 76 00• info@crosscontrol.se • www.crosscontrol.com...
