MarMonix MTC-602 User Instruction

Digital tachometer
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Digital Tachometer
Products Code: MTC-602
USER INSTRUCTION
WWW.MARMONIX.CO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTC-602 and is the answer not in the manual?

Questions and answers

Related Manuals for MarMonix MTC-602

Summary of Contents for MarMonix MTC-602

  • Page 1 Digital Tachometer Products Code: MTC-602 USER INSTRUCTION WWW.MARMONIX.CO...
  • Page 2 WARNING!! To avoid injuries to animal or human eyes,Please do not point the laser beam in eyes or look directly into beam. If the instrument is not to be used for any extended period, Please remove battery. 1. FEATURE *This Digital Tachometer provides fast and accurate Non-contact RPM and surface speed measurements of rotating objects.

  • Page 3: Specifications

    2. SPECIFICATIONS Display: 5 digits LCD display. Accuracy: ±(0.05%+1 digits). RPM test rang: 2 to 99,999RPM Count rang: 1 to 99,999 REV. Resolution: 0.1 RPM (2 to 999.9 RPM). 1 RPM. (over 1000 RPM) Sampling time: 0.5 sec. (over 120 RPM) Detecting distance: 50mm to 500 mm.
  • Page 4 align the visible light beam with the applied target. Verify that monitor indicator lights when the target aligns with the beam. Then the current mode is the last time mode. If you need to change the mode, release the “MEAS” button and press the “MODE”...
  • Page 5 greater than the reflective area. b. If the shaft is normally reflective, it must be covered with black tape or black paint before attaching reflective tape c. Shaft surface must be clean and smooth before applying reflective tape. *VERY LOW RPM MEASUREMENT As it is easy to get high resolution and fast sampling time,if measuring the very low RPM values,...
