FIGURE 1-2
Features
This PCI adapter offers the following features:
Fully complies with the ANSI/IEEE std. 802.3 CSMA/CD physical layer
specification
Four independent Ethernet channels run at either 10 Mbps or 100 Mbps
Supports half-duplex or full-duplex operation modes
Multiple 48-bit IEEE 802.3 style media access control (MAC) identifiers, one for
each channel
Link integrity LED for each channel
2
Sun Quad FastEthernet PCI Adapter Installation and User's Guide • August 1997
Ethernet channels
0
1
2
Sun Quad FastEthernet PCI adapter Back Panel
Four Switchable 10BASE-T/100BASE-TX Ethernet channels with auto
negotiation. Conforms to IEEE 802.3u Ethernet standard
Provides operations of up to 100 meters of twisted-pair without use of
repeaters
3
LEDs
