H PIKOS
INSTRUCTION MANUAL
Congratulations on choosing a Claypaky product
We thank you for your custom.
Please note that this product, as all the others in the rich
Claypaky range, has been designed and made with total quality
to ensure excellent performance and best meet your expectations
and requirements.
1
C61397
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Claypaky HEPIKOS
Summary of Contents for Claypaky HEPIKOS
-
Page 1: Table Of Contents
We thank you for your custom. Please note that this product, as all the others in the rich Safety information Claypaky range, has been designed and made with total quality Unpacking and preparation to ensure excellent performance and best meet your expectations and requirements. -
Page 2: Safety Information
SAFETY INFORMATION SAFETY INSTRUCTIONS IMPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also available in digital format at the following link: www.claypaky.com Ref: [FIS00H - Safety Information Supersharpy-Mythos-Hepikos] INFORMAZIONI DI SICUREZZA IMPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative a questo prodotto, sempre reperibili in versione digitale al seguente link: www.claypaky.com... -
Page 3: Unpacking And Preparation
UNPACKING AND PREPARATION 2 x 183102/805 LAM00N (fitted into fixture) Packing contents - Fig. 1 5 / 2 / 6 0 LOCKED UNLOCKED LOCKED UNLOCKED I N S S I G S I G PAN Mechanism Lock and Release (every 90°) - Fig. 2 TILT Mechanism Lock and Release (every 45°) - Fig. -
Page 4: Installation And Start-Up
INSTALLATION AND START-UP Installing the projector - Fig. 4 The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING: with the exception of when the projector is positioned on the floor, the safety cable must be fitted. (Cod. 105041/003 available on request). This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base. -
Page 5: Control Panel
Press the switch. The projector starts resetting the effects. At the same time, the following information scrolls on the display: Model Firmware xxx (Fixture ID) System errors HEPIKOS Version X.X.X Dmx Address xxx E: ......Date - Hour W: ...... - Page 6 Reversal of the display - Fig. 9 To activate this function, press UP and DOWN keys simultaneously while the display is in the rest mode. This status will be memorised and maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again. Setting the projector starting address On each projector, the starting address must be set for the control signal (addresses from 1 to 512).
-
Page 7: Maintenance
MAINTENANCE 1/4 Turn 1/4 Turn Locking and releasing Pan and Tilt movements - Refer to the instructions in the UNPACKING AND PREPARATION section. Opening the head covers - Fig. 10. Closing the head covers - Fig. 11. Continue H PIKOS... - Page 8 • General cleaning of internal parts. • Restoring lubrication of all parts subject to friction, using lubricants specifically supplied by Claypaky. • General visual check of the internal components, cabling, mechanical parts, etc.
- Page 9 Cleaning of the filters - Fig. 13. Continue H PIKOS...
- Page 10 1/4 Turn 1/4 Turn Upper Side Lower Side Extraction of the effect modules: Preliminary operations - Fig. 14. H PIKOS...
- Page 11 Extraction of the effect modules - Fig. 15. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 14, 15, and 16 in reverse order. Continue H PIKOS...
- Page 12 Extraction of the effect modules - Fig. 16. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 14, 15, and 16 in reverse order. H PIKOS...
- Page 13 Upper Side IMPORTANT: Pay attention to the Dimmer blade when you open the lamp department, you can bent it if it is on the wrong position, please move it in the right position (close it) to avoid that. Lamp change - Fig 17 Take the new lamp out of its package and insert in the fitting.
- Page 14 Battery removal - Fig. 19 This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. H PIKOS...
-
Page 15: Technical Information
TECHNICAL INFORMATION 427 (16.81") (15.59") 628 (24.72") (22.44") (16.53") (14.96") POWER SUPPLIES ELECTRONICS BODY AC power input Neutrik PowerCON TRUE1 Long life self-charging buffer battery Aluminum and steel structure with plastic covers (IP65) 115/230V 50/60 Hz Automatic power Function reset from the lighting desk Two side handles for transportation Device supply switching “AUTOTEST”... -
Page 16: Cause And Solution Of Problems
Fault in the electronic circuits. Call an authorised technician. Lenses or reflector broken Call an authorised technician. Dust or grease deposited. Clean (see instructions). Clay Paky - Via Pastrengo, 3/b - 24068 Seriate (BG) Italy - Tel. +39-035-654311 - Fax +39-035-301876 - www.claypaky.com S.p.A.
