Signtex Moonlite MAEBB Series Installation Instructions And Owner's Manual

Moonlite LED
™
INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL

J- Box and Supply Wiring

1. See above. Assemble standard 4" x 4" deep j-box with 1 ½" extension. Note available knock-outs for
wiring. Remove K.O's in areas shown for wiring and connecters.
2. Align edge of extension flush or just below finish panel surface.
3. SECURITY LIGHTING SWITCH CONTROL (OPTION -SW)
IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Disconnect AC power before servicing.
2. Refer to wiring diagram for proper connections.
3. All servicing should be performed by qualified personnel.
4. Consult your local building code for approved wiring and installation.
5. Do not use this equipment for other than intended use.
6. Do not let power cords touch hot surfaces.
LED Architectural Emergency Light with Battery Backup
4
OPTIONAL NORMAL ON
CONTROL SWITCH WIRING
AVAILABLE K.O.'S
4 PLACES
STANDARD J-BOX
4 x 4 x 21/8"
EXTENSION RING
4 x 4 x 11/2"
SET EDGE OF BOX
FLUSH TO WALL
FINISH OR
PANEL THICKNESS
POWER
BATT
SUPPLY
L N
120 / 277 VAC
UN- SWITCHED NORMAL INPUT
SAVE THESE INSTRUCTIONS
ITEM QTY P/N
1 1
2 1
3 1
4 1
Red
L N G
120/277 VAC
BUILDING SUPPLY
GROUND
TO J-BOX
LAMPS
SEC CONTROL INPUT VOLTS
STANDARD FIXTURE = 120 VAC
RED
DG FIXTURE = 120/ 277 VAC UNIVERSAL
(LINE)
SEC CONTROL
MAKE- SEC ON
BREAK- SEC OFF
7. Mount and secure the fixture at a location and height to avoid ready access
and tampering by unauthorized persons.
8. The use of accessory equipment is not recommended by the manufacturer
and may cause an unsafe condition.
9. Suitable for wet locations. See product label for temperature limitations.
Series MAEBB
DESCRIPTION
346302 CANOPY POWER ASSBY
206110 BATTERY PACK 3.6V
206117 BATTERY PACK 4.8V
346200 LAMP HOUSING ASSBY
Black
White
2 3
SUITABLE FOR WET LOCATIONS
AMBIENT TEMPERATURE LIMITS:
Standard "BB" models: -20º C to +40º C
High Temp "BB" models (SW): -20º C to +45º C
Remote models: -40º C to +50º C
5.15.03
LAMP
PLUG
