- Page 1 PC104-PLUS 100BT Ethernet PRELIMINARY V1.0...
-
Page 3: Table Of Contents
GENERAL ........... . . 1 DESCRIPTION . -
Page 4: General
PC/104-plus format. It uses the National Semiconductor DP83815 Ethernet chip with integrated PHY for minimum component count and reliability. The 4I61 is a universal card and can work in 5V and 3.3V systems. It is a PC/104-PLUS card, meaning that in addition to the stackthrough PCI connector, the standard PC/104 stackthrough connector is available. -
Page 5: Hardware Configuration
SHARES SL2 RQ/GNT The 4I61 can accommodate a boot EPROM or Flash EEPROM. Socket U6 is provided for the EPROM or flash EEPROM. The 4I61 will only support 3.3V ,32 pin EPROM and Flash EEPROMs. The hexadecimal MAC address is printed on a label on the front edge of the PC/104 connector of the 4I61 card. -
Page 6: Connectors
CONNECTORS 4I61 3... -
Page 7: Led Connector
LED current limit resistor are provided on the 4I61 card. Pin 1 of P1 is marked with a white square on the 4I61 card. P1 is a 10 pin .1" header. P1 pinout is as follows:... -
Page 8: Operation
OPERATION The Distribution disk supplied with the 4I61 has drivers for Windows 9X,NT,2K,CE,ME, DOS,Linux ,Vxworks and Netware. In addition the DP83815 chip used on the 4I61 is supported by FreeBSD, NetBSD, OpenBSD, and QNX. 4I61 5... -
Page 9: Specifications
SPECIFICATIONS POWER SUPPLY 4.5V 5.5V POWER CONSUMPTION: ACTIVE ---- 250 mA IDLE ---- 175 mA SLEEP MODE ---- 35 mA OPERATING TEMP. +70 C OPERATING TEMP. (-I version) -40 C +85 C OPERATION HUMIDITY 95% NON-CONDENSING 4I61 6...
