- Page 1 RUSH SHOWER/BATH DIVERTER MIXER PRODUCT CODE: RU791 CHR FINISH: CHROME STYLISH CONTEMPORARY DESIGN PREMIUM CHROME PHOENIX FINISH WARRANTY MATCH WITH..
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS CONSUMER INFORMATION RANGE: RUSH PRODUCT: SHOWER/BATH DIVERTER MIXER PRODUCT CODE: RU791 CHR WATERMARK LICENCE: WM21009 REVISION DATE: DEC 2013 CONNECTION TYPE: MATERIAL: BRASS Adjustment AVAILABLE FINISHES: CHROME, MATTE BLACK 48mm to WELS RATING: FLOW RATE: TEMPERATURE RATING: MIN 1° - MAX 75° PRESSURE RATING: MIN 150 KPA - MAX 500 KPA... -
Page 3: Exploded View
EXPLODED VIEW PARTS LIST 1. DIVERTER MIXER OUTLET 2. WALL MIXER BODY 3. CARTRIDGE 35MM 4. SHOWER MIXER LOCKNUT 5. DIVERTER ASSEMBLY 6. SQUARE DIVERTER BUTTON 7. BACK PLATE 8. MIXER HANDLE 9. GRUB SCREW M5x5 10. DIVERTER SHROUD 11. O-RING 12. -
Page 4: Installation Instructions
- Installation should comply with Australian standard AS3500.1 or relevant local authority requirements. Dress Plate Diverter Shroud Failure to comply with the above may void all warranties. For details on Phoenix’s warranty policy refer to Diverter Button www.phoenixtapware.com.au Dress Button Dress Shroud... -
Page 5: Warranty Information
* Note: These warranty periods apply to Phoenix will not be liable for any claims for labour, - Isolation stop taps are not tted as stated on products purchased after 10th April 2011. - Page 6 Phoenix is responsible, Phoenix has the right to charge a service fee for each service sta attending the Owner’s premise where goods have been installed.
