  • Page 1 Einbauanweisung Parking Cooler Installation Instructions Climatiseur de toit Notice de montage autonome Condizionatore da Istruzioni di montaggio parcheggio Aire Acondicionado Instrucciones de montaje autónomo Standairco Montagehandleiding Klimatyzacja postojowa Instrukcja montażu Nezávislá klimatizácia Návod na montáž Cool Top Vario 10 E...
  • Page 2 Only genuine Webasto parts may be used. NEVER try to install or repair Webasto heating or cooling systems if you have not completed a Webasto training course, you do not have the necessary technical skills and you do not have the technical documentation, tools and equipment available to ensure that you can complete the installation and repair work properly.

  • Page 3: Table Of Contents

    Cool Top Vario 10 E Parking cooler ........

  • Page 4: General Information

    The parking cooler is mounted on top of a lorry driver's cab in place of an existing roof hatch. The Cool Top Vario 10 E parking cooler cools the driver compartment of the lorry driver's cab according to the recirculating air principle: Warm air is sucked in from the...

  • Page 5: Safety

    Make sure that the parking cooler is switched off before the driver's cab (e.g. maintenance work on the vehicle) is tilted. If the Cool Top Vario 10 E parking cooler is tilted by more than 30° out of the normal position, (for example, during...

  • Page 6: Proper Use

    In case of improper use of the parking cooler, there is a danger of injuries or damage. The Cool Top Vario 10 E parking cooler is intended for cooling lorry driver's cabs while parked. As a result, the environmentally harmful running of the engine to operate the vehicle air-conditioning system can be avoided.

  • Page 7: Installation

    Cool Top Vario 10 E 3 Installation Installation Delivery scope Fig. 1 3.1.1 Cool Top Vario 10 E Parking cooler 3.1.2 Installation kit Item Designation Quantity Item Designation Quantity Parking cooler Cabin cover Power supply cable, 5 m Mounting bar...

  • Page 8: Electrical Connection

    3 Installation Cool Top Vario 10 E Electrical connection Mechanical installation SHORT CIRCUIT AND DANGER OF FIRE ACCIDENT DANGER Always disconnect the batteries before When working on the vehicle roof there is a working on the electrical system. danger of accidents occurring from persons falling or from falling objects.

  • Page 9: Put Parking Cooler Into Operation

    • Controller offset = temperature difference CAUTION between target and actual temperature (six 1 °C If the Cool Top Vario 10 E parking cooler is steps). tilted by more than 30° out of the normal • position, at least 2 hours must be waited Memory for communication status of parking before switch-on.

  • Page 10: Setting Of The Switch-Off Limit For Low Battery Voltage (F1)

    3 Installation Cool Top Vario 10 E 3.5.1 Setting of the switch-off limit for low 3.5.2 Setting of the switch-on limit for low battery voltage (F1) battery voltage (F2) In this setting the voltage value is set at which the parking...

  • Page 11: Treatment Of Surfaces

    Cool Top Vario 10 E 3 Installation 1. Call setting F4. Treatment of surfaces 2. To change the value, press the Fan + or Fan – The outside of the parking cooler consists of a PMMA button on the control panel.

  • Page 12: Environment

    Disposing of packaging Separate the packaging materials into cardboard and plastic. Bring the sorted packaging materials to an appropriate recycling centre. Disposing of used parts Contact a specialist company for disposal of hazardous waste or contact Webasto to dispose of used parts.
  • Page 13 Bij een meertalige versie is de Duitse versie bindend. W przypadku wersji kilkujęzycznej wiążący jest tekst w języku niemieckim. V prípade nesúladu jazykových verzií je záväzná nemecká. Webasto AG Postfach 80 D - 82132 Stockdorf Germany National: Hotline: 01805 93 22 78 (€...
