Summers M104 Operator's Manual

Mounted harrow rolling choppers
Hide thumbs Also See for M104:

Advertisement

Table of Contents

MOUNTED HARROW
ROLLING CHOPPERS
IMPORTANT
THE OPERATOR IS RESPONSIBLE FOR AD-
JUSTING THE MACHINE SINCE MACHINE DOES
NOT COME "FIELD READY" FROM FACTORY.
SUMMERS MANUFACTURING CO., INC.
MADDOCK, NORTH DAKOTA 58348 ........................................................ (701) 438-2855
DEVILS LAKE, NORTH DAKOTA 58301 ................................................... (701) 662-5391
SUMMERS
Operator's
M94, M104 AND M106
WEB SITE: www.summersmfg.com
© Summers Mfg. Co., Inc. 2004
Manual
CAUTION
READ & UNDERSTAND OPERATOR'S MANUAL
BEFORE USING MACHINE.
®
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M104 and is the answer not in the manual?

Questions and answers

Related Manuals for Summers M104

Summary of Contents for Summers M104

  • Page 1 WEB SITE: www.summersmfg.com MADDOCK, NORTH DAKOTA 58348 ... (701) 438-2855 DEVILS LAKE, NORTH DAKOTA 58301 ... (701) 662-5391 Operator’s Manual M94, M104 AND M106 CAUTION READ & UNDERSTAND OPERATOR’S MANUAL BEFORE USING MACHINE. © Summers Mfg. Co., Inc. 2004 ®...
  • Page 2 Summers warrants only products of its manufacture against operational failure caused by defective materials or workmanship which occur during normal use within 12 months from the date of purchase by the end user from Summers’ dealer. Summers’ obligation is to replace free of charge any part of any product that Summers inspection shows to be defective excluding transportation charges to Maddock, ND or Devils Lake, ND and return and also excluding all transportation costs from Summers’...
  • Page 3 Safety Section ...1-5 Disk Mounted Harrow Installation Guide ... 6 Mounting Arm Assembly - M94, M104 & M106 ... 7 4-1/2’, 6’ & 7-1/2’ 3-Bar M94 Section Assembly ... 8 4-1/2’, 6’ & 7-1/2’ 4-Bar M94 Section Assembly ... 9 6’, 8’...

  • Page 4: General Safety Practices

    Defi nition of each Signal Word used in conjunction with the Safety-Alert symbol. indicates an imminently hazardous situation which, if not avoided, will result in death or serious DANGER injury. This signal word is to be limited to the most extreme situations. indicates a potentially hazardous situation which, if not avoided, could result in death or serious WARNING injury.

  • Page 5: Safety Decals

    SECTION 1 - SAFETY SAFETY DURING TRANSPORT 1. ONLY TOW at a safe speed. Use caution when making corners or meeting traffi c. 2. USE a safety chain between tractor drawbar and implement hitch when transporting on public roads. 3. ALWAYS use transport locks when transporting on public roads. 4.
  • Page 6 SECTION 1 - SAFETY 3. WING DANGER DECAL (PN 8Z0344) 4. ELECTROCUTION DANGER DECAL (PN 8Z0346) 5. PINCH POINT DECAL (PN 8Z0087)
  • Page 7 SECTION 1 - SAFETY 6. AMBER REFLECTOR (PN 8Z0800) 7. RED-ORANGE REFLECTOR (PN 8Z0805) 8. RED REFLECTOR (PN 8Z0810)
  • Page 8 GENERAL ASSEMBLY SAFETY PRACTICES YOU ARE RESPONSIBLE for the safe assembly of the machine. DO NOT ALLOW CHILDREN or other unauthorized persons within the assembly area. WEAR PERSONAL PROTECTIVE EQUIPMENT which includes a hard hat, eye protection, work gloves and steel toed boots with slip resistant soles.
  • Page 9 DISK MOUNTED HARROW INSTALLATION GUIDE Disk brackets and Spacer Tubes for M94, M104 and M106 Mounted Harrow See Pages 2.05 – 2.07 of Whole Goods Catalog for Sections Required Use one short disk bracket with sections supported by one mounting arm. Use two short disk brackets to mount a single harrow section across disk center.
  • Page 16 4. U-bolt sections to arms. (Leave 12” gap in the center, between tines.) 8H2310 8HD5250 8H1600 MNTNG DISK BRCKT –– –– (WING) 8H1505 M104 M106 SPACER, 4” 2 - 8HD5381 2 - 8HD5387 –– 4 - 8H2310 4 - 8H2310 1 - 8HD5250 1 - 8HD5250...

  • Page 20: Mounting Instructions

    INSTRUCTIONS on Cultivators, Chisel Plows and Disk Some tillage implements have close to 180 degrees of wing travel into transport position. Machines like this include short wing machines with low transport height and 5 section machines (outside wings only). This type of fold can cause interference problems with SMC Mounted Harrows.
  • Page 22 SECTION 1 BASIC LAYOUT AND ASSEMBLY; Fig. 1 Lay out all bars behind implements to determine approximate mounting locations on the frame. Position mounting brackets (A) on the implement frame so that they line up with spaces between teeth on a bar. Brackets may be positioned one, two or three teeth in from the end of a bar and may be different on both ends.
  • Page 23 Fig. 5. Attach levers to bars be removing the existing bolts and using 1/2 x 3-3/4” bolts supplies. Discard harrow tooth washer. Secure using original locknut. Attach connecting bar and adjusting bar on sides of levers as shown in fi gures. Use a 7/16 x 1-1/4” bolt on the front levers and 7/16 x 1-3/4”...
  • Page 24 SECTION 2 SPECIAL BRACKETS FOR JD1610 CHISEL PLOWS The above 29’ JD1610 chisel plow is shown with a 4 bar mounted harrow using M74 carrier arms. Two 7’ sections were used in the center and one 8’ section was used on each wing. An optional method is to use one 14’...
  • Page 25 Long (w/mounting plate & hardware) All of the above brackets are designed to be used with Summers M74, M94, M104 or M106 mounting arms. When mounting disk brackets directly on disk gangs which run at an angle, a short and a long bracket are used so harrow sections run square.
  • Page 26 SECTION 4 SPECIAL BRACKETS FOR JD235 DISKS Order mounting package PN 8H1580 for 19-26 ft. models Order mounting package PN 8H1582 for 27-31 ft. models The photo to the right shows a 30’-1” JD235 disk with a 3 bar M74 Mounted Harrow. See the fi gures and sizing chart below for harrow layout on all size models.
  • Page 27 JD235 DISK FRAME MOUNTING BRACKET SELECTION CHART Bracket 19-26 Ft. Models Bracket Description Long Hi-Clearance Modifi ed Short Univ. (See Fig. 3a) Modifi ed Short Univ. (See Fig. 4a) Modifi ed Short Univ. (See Fig. 4a) 235 Bracket & Spacer Tube (Fig. 5a) Short Hi-Clearance 3a.
  • Page 28 SECTION 5 PACKING LISTS For 2 bar attachments, order 3 bar brackets and 2 bar hardware package (PN 8H0200 – One required per pair) Description 8H1330 Side Plate, 3 Bar 8H1332 Side Plate, 4 Bar 8H1340 Mounting Plate 8H1350 Mounting Bracket 8H1362 Carrier Arm, M74 8H1368...
